Summary of Contents for Purlette PL400G
- Page 1 Reverse Osmosis Water Filtration System Owner’s Manual Model # PL400G Scan QR code for installation video or visit www.purlette.com...
- Page 2 Congratulations! You are now the owner of a Purlette System! Purlette is an under-the- sink water filtration system that makes tracking your water quality and keeping it clean and drinkable simpler than ever before. Using the accompanying mobile app you can monitor the potability of your water, know at all times exactly how much life your filter has left in it, and even order replacement filters directly through the app.
- Page 3 Introduction System Features Operation Touch Panel Before Installation What is in the Box Installation Three-Way Valve Drinking Faucet Drain Saddle How to Install an Air Gap Connect Water Line System Connection Diagram How to Install a Partition Flushing the Filters Maintenance Replacing and Resetting the Filter Safety...
-
Page 4: Auto-Cleaning
Reverse Osmosis Filter The Purlette system will regularly enter auto-cleaning mode. This is based on usage and will take place at random. The Purlette system will make an audible sound when it is in auto- cleaning mode. Carbon Block Filter... -
Page 5: Operation Panel
All indicator lights will be off during energy saving mode. When the drinking water faucet is used, an operation panel button is pushed, or the system enters auto-cleaning mode the Purlette system will exit energy saving mode and indicator lights will illuminate automatically. -
Page 6: Before Installation
Before Installation Operation Parameters INDOOR USE ONLY we recommend that the Purlette system installed under the kitchen sink. However, you may install the Purlette system in any suitable indoor location away from direct exposure to the environment, with adequate space for the Purlette system to stand upright. -
Page 7: What Is In The Box
What is in the Box Purifier Dust Lid RO Filter Hybrid Filter Drinking Water Thread Faucet Seal Tape and Parts Three-Way Drain 1/4” Color Coded Locking Quick Feed Water Saddle PE Tubes Clips Connectors Ball Valve... -
Page 8: Installation
Installation Step 1: Install the three-way feed water ball valve Locate the cold water supply stop valve under the kitchen sink. Turn the incoming cold water off (typically by turning the valve in clockwise direction). Turn on the kitchen faucet to release any pressure in the pipes and to make sure the water has stopped before proceeding to the next step. - Page 9 Then slide the locking clip into place to secure the tube. Tug on the water line gently to ensure that it is secure. Close Do not connect the other end to the Purlette system at this time...
- Page 10 Once secured, slide the locking clip into place. Certain faucet models may not be equipped with a quick-connect fitting. Do not connect the other end to the Purlette system at this time...
- Page 11 PE tube in place. Do not connect the other end to the Purlette system at this time Align the holes of the drain saddle and drain pipe with a drill bit.
- Page 12 How to install an air gap While Purlette can operate without the need for an air gap, your local plumbing code may require one to be installed. Use a Dual Air Gap for Dishwasher and Reverse Osmosis Filters if necessary.
- Page 13 Installation Step 5: Connect water lines to Purlette system Attach quick-connectors to all three water lines and make sure to push in to the marked line until you feel it stop. Slide the locking clip in to secure the water line.
- Page 14 Now it’s time to check the system to make sure that Connection Diagram there are no leaks! Do not plug in the Purlette system at this time. Turn on the cold water supply and open the three-way feed water ball valve. Check each connection point for any leaks.
- Page 15 Installation How to properly install a partition We recommend the power-supply receptacle for the Purlette system be installed in a cabinet or on a wall adjacent to the undercounter space in which the purifier is to be installed. There shall be an opening through the partition between the compartments specified in that is large enough for the power plug to pass through.
- Page 16 Installation Step 7: Plug in the Purlette system Now it is time to plug in the Purlette system. Insert the power plug into the 110 V GFCI outlet socket. The indicator lights will blink for 5 seconds signaling that the system is starting.
-
Page 17: Maintenance
15 mins. Purlette system to are aligned to the hear a pop sound. initialize. hear a beep. make sure there are ports. - Page 18 Maintenance Replacing filter when indicator light is not blinking When replacing the filter without being prompted to by the system, you have to manually reset the filter. Follow steps 2-12 on the previous page to replace the filter. Then follow these next steps to manually reset the filter: RESET RESET HYBRID...
- Page 19 • Do not use wet hands to plug or unplug the power cord. • Do not allow flammable/volatile substances near the Purlette system. • Do not allow the Purlette system to be in contact, or close to, the source of heat or open fire.
- Page 20 • The Purlette system is only intended for indoor installation and use. • If you plan not to use the Purlette system for an extended period of time, please disconnect power and close the three-way feed water ball valve. Run the water 3–5 minutes before use when you restart the Purlette system.
- Page 21 FCC Supplier’s Declaration of Conformity: Purlette / PL400G This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 22: Performance Data
Performance Data PL400G system tested and certified by WQA to NSF/ANSI 58 for cadmium, trivalent chromium, lead, and TDS, and NSF/ANSI 372 for low lead, as verified and substantiated by test data. This system has been tested according to NSF/ANSI 58 for reduction of the substances listed below. - Page 23 Performance Data Test Parameters: Temperature, Pressure, Turbidity, TDS, and pH analyses were conducted at WQA’s Performance Laboratory. Chlorine free deionized water was used which has a conductivity of less than or equal to 1μS/cm. Sodium chloride (NaCl) was then added to the test water to achieve a TDS challenge concentration within range. The following conditioning was performed with water: 1-hour flush, 10-hour soak, 1-hour flush, 12-hour soak, 1-hour flush, 7.5-hour soak, then 5 to 10-minute flush.
-
Page 24: Troubleshoot
1-800-928-7624. Please do not attempt to disassemble and repair the Purlette system, as such action could result in damage to the system and void of warranty. - Page 25 Purlette system to check for internal leaking. • If leakage is internal, water would drain out from the base. Please contact our customer support team and do not try to disassemble and repair the Purlette system. • The water leakage detector is triggered.
-
Page 26: Three Year Limited Warranty
To obtain repairs or replacement within the terms of this warranty, please contact us at 1-800-928-7624 (open Monday to Friday, 8 am to 5 pm Pacific Time); or mail PURLETTE/VISINI USA INC., 136 N. Grand Ave., #330 West Covina, CA 91791. - Page 27 Purlette/VISINI USA INC. West Covina, CA 91791 1-800-928-7624 support@purlette.com...
