Summary of Contents for AOCHUAN Master M20
- Page 1 Wireless Remote Control Electric Tripod Quick Start Guide...
-
Page 2: Product Overview
Product Overview 1/4, 3/8 screw interfaces Graduated scale Leveling instrument Sponge Remote controller Fixed knob Fixed buckle Type-C charging port Power button Power indicator... -
Page 3: Extended Status
Extended status 540mm 890mm 1265mm 1565mm... -
Page 4: Product List
Product list Before use, please check and ensure that the kit consists of all following items. In case of deficiency, please contact the customer service or your local agent. 电动遥控三脚架 Electric Remote Control Tripod 快速入门手册 Quick Start Guide Tripod×1 User manual×1 Remote Type-C controller×1... - Page 5 Function Introduction Charging the tripod Low battery: Red indicator flickers. Normal battery: Solid green indicator is on. Charging: Solid red indicator is on. Finish charging: Green indicator flickers. * If the tripod runs out of battery, its extension rod will automatically fold itself.
- Page 6 Function Introduction Bluetooth Connection and Use Indicator Ascending button Descending button Pause button Camera button Connect the Bluetooth 1.Hold down the camera button on the remote for over five seconds, the Bluetooth is opened and the blue indicator flickers. Open the Bluetooth setting on your mobile phone.
- Page 7 Using Scenario 1/4, 3/8 screw interfaces may fix the mobile phone, camera, hydraulic gimbal, fill-light, etc. Mount the mobile phone Mobile phone clip Mount the camera Camera...
- Page 8 Using Scenario 1/4, 3/8 screw interfaces may fix the mobile phone, camera, hydraulic gimbal, fill-light, etc. Mount the hydraulic gimbal Hydraulic gimbal Mount the fill-light Fill-light...
- Page 9 Tripod parameters Master M20 Product size 113*600*102mm （folded size） Product weight 1.3kg Max. weight capacity Max. weight capacity of the hook 10kg Battery Life 200 times (max. Weight capacity) Charging time About 3 hours Operation voltage 3.7V Power input 5V/1A Operation temperature -10~50℃...
- Page 10 Cautions 1. Do not put the tripod into the fire or near hightempera- ture objects; 2. The tripod may be broken by dropping or crashing. Please use it with care; 3. Do not place the tripod near liquid or clean it with cleanser.;...
- Page 11 Cautions My company shall not be responsible for the loss, injury and any legal liability caused by the direct or indirect use of the product. The user shall follow but not limited to all safety guidelines mentioned herein. This user instruction is for reference only, which isn’t any form of commitment.
-
Page 12: Warranty Services
Warranty Services: Warranty Clauses 1.In case of poor performance or problems on the product within 7 days to the date of receipt, users may ask for replacement or money refund as per the invoice; 2.In case the product occurs quality problems within 12 months, users can enjoy free maintenance;...
