ROBB Smarrt Instructions page 2

Operation
1.This ZigBee Dim remote is a wireless transmitter that communicates with a variety of ZigBee
compatible systems. This transmitter sends wireless radio signals that are used to remotely control a
compatible system.
2.This ZigBee remote supports 4 groups for binding max. 30 lighting devices and enables to control
single color ZigBee lighting devices.
3. Zigbee Network Pairing through Coordinator or Hub (Added to a Zigbee Network)
Step 1: Remove the remote from
previous zigbee network if it has
already been added to it, otherwise
pairing will fail. Please refer to the
part "Factory Reset Manually".
Step 3: Press and hold down both
buttons until LED indicator turns on.
Note: 1) After pairing successfully, the remote information will appear on the controller or hub interface.
2) No remote information will appear on the hub interface if pairing to Philips Hue Bridge.
4. TouchLink to a Zigbee Lighting Device
Step 1: Set the zigbee lighting
device to start TouchLink
commissioning, please refer to its
manual to learn how.
Step 3: Short press ON button of
group 1/2/3/4 to choose a group
that you would like to pair the
device to.
Step 4: Press and hold down both
buttons until LED indicator turns on.
Note: 1) Directly TouchLink (both not added to a ZigBee network), please first factory reset both the
remote and device, each remote can link with max. 30 devices, please make sure the first linked
device is always powered on when touchlink the remote with 2nd device and more devices.
2) TouchLink after both added to a ZigBee network, each device can link with max. 30 remotes.
3) To control by both remote and hub, add both remote and device to network first then TouchLink,
after TouchLink, the device can be controlled by the linked remotes and Zigbee hub together.
5. Removed from a Zigbee Network through Coordinator or Hub Interface
LED indicator
Step 2: From your zigbee
controller or hub interface, choose
to add device or accessory and
enter Pairing mode as instructed
by the controller.
Step 4: Immediately short press to
search nearby network, indicator
flashes every 1 second, 20 seconds
timeout if there is no network.
Indicator will then blink 5 times
quickly for successful pairing.
LED indicator Step 2: Bring the remote within
10cm of the lighting device.
< 10cm
ZigBee Lighting Device
Step 5: Immediately short press to
start TouchLink commissioning of
the remote. LED indicator flashes
fast for 3S, then flash 6 times slowly
to indicate successful pairing to the
device and the light connected to
the device will blink twice.
6. Factory Reset Manually
Step 2: Immediately short press 5
times continuously, indicator
flashes 3 times quickly to indicate
successful reset.
7. Remove a Touchlink Paired ZigBee Lighting Device
Step 1: Set the Touchlink paired
zigbee device to start TouchLink
commissioning, please refer to its
manual to learn how.
Step 3: Short press ON button of
group 1/2/3/4 to choose a group
that the device was touchlink
paired to.
Step 4: Press and hold down both
buttons until LED indicator turns on.
From your ZigBee controller or hub
interface, choose to delete or reset
the remote as instructed, indicator
flashes 3 times quickly to indicate
successful removing.
LED indicator
Note: All configuration
parameters will be reset after the
remote is reset or removed from
the network.
Step 1: Press and hold down both
buttons until LED indicator turns on.
LED indicator
Step 2: Bring the remote within
10cm of the lighting device.
< 10cm
ZigBee Lighting Device
Step 5: Immediately short press
twice to start TouchLink removing of
the remote. LED indicator flashes
fast for 3S, then flash 6 times slowly
to indicate successful removing.
