- Page 1 SWIM SPA PRE-DELIVERY GUIDE...
- Page 2 Introduction This guide has been designed to help you plan and prepare for the delivery and installation of a Galaxy Swim Spa. There are a number of important steps, decisions and actions that must be taken prior to delivery day to ensure a smooth delivery.
-
Page 3: Table Of Contents
Above Ground or In-Ground Options, Building Regulations & Consent Out of Ground Installation In-Ground Installation (Sinking) Heat Pump Installation Guide Initial Start-Up Guide - Getting your Spa Pool Set Up for First Use Pre-Delivery Plan and Checklist - Get Ready for Your Swim Spa’s Arrival... -
Page 5: Delivery Options
HIAB Truck The most common delivery option for a swim spa is a HIAB truck. A HIAB is a large delivery truck with a crane arm that reaches a distance to 7m from where the truck can park and no higher than 2m. -
Page 6: Choosing Your Spa Placement
Does the location offer access around the entire swim spa? Full perimeter access is advised. • Do you have a view that you wish to look over while relaxing in the Swim Spa? • Is there anything else that might make your surroundings more enjoying? For example a deck or landscaping? •... -
Page 7: Fencing
If your Swim Spa will be placed above ground, this may give you the option to claim the ‘wall of the Swim Spa’ as the fence, as it’s over 1.2m high. In this case, anything that can be used to climb the wall such as steps, need to be removed when not in use. If you’re installing a heat pump, make sure the piping is kept low to the ground and the unit is installed 1.2m from the... -
Page 8: Foundation Requirements
You will require a builder to install a pad for the dimensions of the spa, wherever it is going. It is not advised for a swim spa to go on decking as it cannot support the weight when full. -
Page 9: Heat Pump Foundation
A minimum of 500mm clearance around all sides of the swim spa is required for service access. If you are planning to sink your swim spa into a deck, you will need to ensure there is sufficient space for service agents to access the panels beneath the decking surface or add a removable decking component. -
Page 10: Electrical Requirements
Measure the same entry point and drill a hole the width of the cable down through the base of the swim spa. Feed the cable up through the hole into the inside and then remove the blocks and lower the swim spa gently onto the foundation. -
Page 11: Recommended Cable Input Location
Recommended Cable Input Location CALYPSO MINOR CALYPSO AURORA OBERON ATLAS URSA PROSPERO TITAN HYPERION MERCURY TITAN MAJOR... -
Page 12: Positioning Requirements - Component Layouts And Measurements
Component Layouts and Measurements The orientation of your swim spa is an important factor when thinking about where you want to place it. Consider where the heat pump union is (if installing one) and where the electricity cable point is, as well as the orientation of the hydrotherapy seating. Personal factors should also be... - Page 13 CALYPSO MINOR Drain Control Control Valve Panel 500mm Service Area...
- Page 14 CALYPSO ATLAS Heat Pump Drain Control Control Drain Control Control Valve Panel Valve Panel Union Heat Pump Union 500mm Service Area 500mm Service Area...
- Page 15 AURORA URSA Heat Pump Drain Control Control Drain Control Control Valve Panel Valve Panel Union Heat Pump Union 500mm Service Area 500mm Service Area...
- Page 16 HYPERION MERCURY Drain Control Drain Valve Valve Swim Spa Swim Spa Drain Valve Drain Valve Control Heat Zone Pump Union Heat Pump Union Swim Zone Control Panel Control Panel 500mm Service Area 500mm Service Area...
- Page 17 TITAN TITAN MAJOR Heat Heat Pump Pump Drain Control Control Control Drain Valve Union Valve Union Panel Panel Swim Spa Drain Valve Control 500mm 500mm Service Area Service Area...
- Page 18 OBERON PROSPERO Control Heat Pump Control Heat Pump Panel Union Panel Union 500mm Service Area Control Drain Valve 500mm Service Area Control Drain Valve...
-
Page 19: Above Ground Or In-Ground Options, Building Regulations & Consent
In-Ground Installation (Sinking) This is the most common form of installation, If you choose to sink the spa or build a deck where the swim spa is placed on a concrete up around it, there are a few considerations foundation. -
Page 20: Heat Pump Installation Guide
40mm PVC pressure pipe - enough to suit the plumbing configuration of where your Connect the heat pump data cable to the heat pump sits in relation to the Swim Spa. EXP2 data socket of the Gecko controller. • 40mm hole saw for cabinet drilling... -
Page 21: Initial Start-Up Guide - Getting Your Spa Pool Set Up For First Use
We water test every single spa at our factory, so some water residue from this testing may remain in the pipework. It is important that you sanitise the swim spa prior to filling it for use. We’ve included a Step-by-Step Guide to getting your pool ready for use for the first time below! -
Page 22: Pre-Delivery Plan And Checklist - Get Ready For Your Swim Spa's Arrival
Pre-Delivery Plan and Checklist - Get Ready for Your Swim Spa’s Arrival 1. Delivery site-check? Notes: 2. Best delivery method ascertained? Notes: 3. Delivery booked? Notes:... - Page 23 Installation Example Power feed Foundation Underground. for Heat Pump Call an electrician.. Heat Pump House Foundation for Steps Spa above ground on concrete foundation Space for cover Driveway Fence Remove temporarily when spa is delivered Scale: .5m Sq...
- Page 24 Notes Scale: .5m Sq...
- Page 25 Scale: .5m Sq...
- Page 26 0800 459 772 | galaxyspas.co.nz...
