S O L O T A B L E S
A s s e m b l y I n s t r u c t i o n s
tabletop 1 ×
1
2
Mattiazzi srl
Via Sottorive, 19 /2
foot 1 ×
column 1 × with metal rod inside
33048 S. Giovanni al Natisone (UD) Italy
screws 1 ×
Unscrew the metal rod that is
inside the column.
Place the tabletop on a
protected, f lat and clean surface.
It is suggested to use our carton
box and plastic sheet.
Screw the metal rod onto the
tabletop.
T + 39 0432 75 74 74
F + 39 0432 75 65 72
segment 1 ×
info@mattiazzi.eu
www.mattiazzi.eu
Advertisement
Table of Contents
Related Manuals for Mattiazzi Solo MC5
Summary of Contents for Mattiazzi Solo MC5
- Page 1 It is suggested to use our carton box and plastic sheet. Screw the metal rod onto the tabletop. Mattiazzi srl Via Sottorive, 19 /2 33048 S. Giovanni al Natisone (UD) Italy T + 39 0432 75 74 74 F + 39 0432 75 65 72 info@mattiazzi.eu...
- Page 2 Screw the column onto the rod (the nut inside the column fac- ing upwards). Put the segment on top. Mattiazzi srl Via Sottorive, 19 /2 33048 S. Giovanni al Natisone (UD) Italy T + 39 0432 75 74 74 F + 39 0432 75 65 72 info@mattiazzi.eu...
- Page 3 A s s e m b l y I n s t r u c t i o n s Put the foot on top. Fix everything with the screw. Tighten hard using a 6mm key. Mattiazzi srl Via Sottorive, 19 /2 33048 S. Giovanni al Natisone (UD) Italy T + 39 0432 75 74 74 F + 39 0432 75 65 72 info@mattiazzi.eu...
