Omegawave COACH User Manual

Hide thumbs Also See for COACH:
Table of Contents

Advertisement

Quick Links

Download this manual
COACH
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COACH and is the answer not in the manual?

Questions and answers

Related Manuals for Omegawave COACH

Summary of Contents for Omegawave COACH

  • Page 1 COACH USER GUIDE...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ............................1 WELCOME ................................2 QUICKSTART GUIDE ............................... 4 GETTING STARTED EMAIL ............................. 5 LOGGING IN TO THE APPLICATION ........................6 CREATING ATHLETES ............................. 7 ALLOCATING LICENSES TO ATHLETES ......................... 9 INVITING ATHLETES ............................. 11 GROUPING ATHLETES ............................

  • Page 3: Welcome

    WELCOME Thank you for purchasing the Omegawave Coach! Let’s start by reviewing what is inside your package: Omegawave Bluetooth Low Energy (BLE) sensor. Model name: OW-CB2. • Simultaneously measures both an electrocardiogram (ECG) and Direct Current (DC) Potential of the Brain.
  • Page 4 In order to use the Omegawave Coach App, you will need to have an iPad with iOS 8.0 or a newer and have downloaded the Omegawave App from the App Store. Please check the following: Ensure that your iPad has an active Internet connection via WLAN or mobile data (3G/4G).

  • Page 5: Quickstart Guide

    QUICKSTART GUIDE To start using Omegawave Coach follow the next steps to setup your team 1. Check the getting started email a. The email contains instructions about downloading the Omegawave app, setting your Omegawave password and logging into the app 2.

  • Page 6: Getting Started Email

    GETTING STARTED EMAIL After purchasing the Omegawave Coach, you will receive an email containing instructions on how to get started. Open the email with your iPad’s Mail application if possible. 1. Set your Omegawave account password Click the link Complete your account and type in the password you want to use with your Omegawave account.

  • Page 7: Logging In To The Application

    Open the Omegawave application and tap the Start button. Use your email address and password to log in. NOTE! If you forget your Omegawave account password, you can request a new one from the login screen by tapping Forgot your password.

  • Page 8: Creating Athletes

    This will open an empty athlete profile view. Fill in the personal data for an athlete. Email field is optional. Athlete will get an email that allows him/her to set Omegawave account password and automatic log in link to Omegawave application. Email is sent after a license has been given to athlete.
  • Page 9 See the next chapter on how to allocate licenses. IMPORTANT! Omegawave’s algorithms need to know the athletes’ gender, date of birth, weight and height in order to calculate certain results. It is important that you always keep their personal data up to date.

  • Page 10: Allocating Licenses To Athletes

    ALLOCATING LICENSES TO ATHLETES The athlete will need a license before he/she can complete measurements. You are also not able to measure the athlete with your iPad before the license is given. From the athlete’s profile tap the Give button to assign a license. After the license has been successfully given, you will see the athlete’s license status changed from No license to License set, note that your available licenses will have decreased by one.
  • Page 11 When the license has been given, a getting started email is sent to the athlete’s email address. The email contains instructions on how to set an Omegawave password, install the Omegawave application and log into the application. IMPORTANT! If you mistyped the athlete’s email address and thus the athlete did not receive the getting started email, do the following: Enter the correct email address in the athlete’s profile view and tap Save...

  • Page 12: Inviting Athletes

    When you invite an athlete, the data sharing relationship is established between the athlete and you, not with your team. This means that the other coaches in your team cannot see the athlete. If other coaches want to see the same athlete, they will have to separately invite the athlete from their Coach app.
  • Page 13 Fill in the athlete’s email you want to invite to your team. You can also write a personal message which is included in the invitation email the athlete receives. When ready, tap Send invitation. The invited athlete will receive an email containing the invitation request. If the athlete accepts the invitation, you can see him/her under your team.

  • Page 14: Grouping Athletes

    • You can assign one or more tags for each athlete. • IMPORTANT! Tags are coach-specific, only you can see the tags you have created and assigned to athletes • You cannot modify an existing tag name • You cannot delete a created tag •...
  • Page 15 How to manage existing tags? When you open the athlete’s profile, you will see all of the tags you have created for your athletes. Highlighted tags are the ones assigned to the athlete, e.g. Injured in the example below. If you want to remove a tag from the athlete, tap on the remove button inside the tag.

  • Page 16: Removing Athletes

    REMOVING ATHLETES You can remove created and invited athletes from your team by opening the athlete profile page and making sure that the athlete does not have a team athlete license. Tap Remove from Team button to remove the athlete from your team. IMPORTANT! If you remove an athlete, you are not able to undone this action.

  • Page 17: Managing Your Subscriptions And Licenses

    You can see your subscriptions’ from the team view by tapping the settings button On the right side of the settings view you can see all subscriptions connected to your Omegawave account. If you are the main subscription owner for your team, you should see separate subscriptions for athletes and coaches.
  • Page 18 Managing athlete licenses Each athlete needs to have a valid license before he/she can use the Omegawave app to conduct assessments himself/herself and/or to be directly measured using your iPad. From the team Overview you can see information about the status of the athletes’ license.
  • Page 19 The athlete icon provides information about the status of the athletes’ license: The team athlete license is assigned The athlete is using a license given by another coach or the athlete is using his/her own Omegawave Personal license No license is assigned You can manage athlete’s license by selecting individual athlete from the team view and then opening...
  • Page 20 But you can give your team’s athlete license to him/her if needed. You might need to do this e.g. if the athlete’s personal license does not allow DC Potential measurement. Managing coach licenses If you want to add a coach to your team or remove a coach from your team, contact us by sending an email to: support@omegawave.com...

  • Page 21: Changing Between Teams

    CHANGING BETWEEN TEAMS If you have a coach role for multiple teams, you will see a small arrow next to your team name. You can switch between your teams by tapping the team name and selecting a team. When you are performing the data sync, it will sync only the team which is currently selected.

  • Page 22: Using The Measurement Hardware

    USING THE MEASUREMENT HARDWARE ECG measurement An ECG recording is used to assess the athlete’s cardiac and metabolic state. The sensor should be attached to the ECG chest strap and must be placed at the bottom of the sternum. Soak the ECG chest strap electrode pads with water. The micro-USB port on the sensor needs to be facing down;...
  • Page 23 The DC Potential cable with a head symbol connects to the athlete’s forehead. The DC Potential cable with a hand symbol connects to the base of the thumb of the athlete’s dominant hand. The DC Potential cable connects to the micro- USB port of the sensor.
  • Page 24 IMPORTANT! Follow this protocol when dressing the chest strap, sensor and DC electrodes to avoid bending the micro-USB connector: 1. Thoroughly wet the chest strap electrodes and wear it 2. Attach the DC electrodes to the hand and the forehead 3.

  • Page 25: Pairing The Sensor With Your Ipad

    PAIRING THE SENSOR WITH YOUR IPAD You need to pair the Omegawave sensor before you are able to conduct assessments with your iPad. NOTE Before proceeding with the following steps, please put on the chest strap and attach the sensor to the strap as previously described.
  • Page 26 3. The Omegawave sensor should now become visible in the device list. Select the sensor from the list by tapping the line saying OW-CB2 in order to complete the pairing process. Now the Omegawave BLE sensor is paired to the application.

  • Page 27: Measuring - Quick Guide

    If measuring after exercise, wait at least 30 minutes. • Measurement instructions Pair the Omegawave sensor in the application (needs to be done only once). Thoroughly wet the ECG chest strap pads with water and only use new gelled electrodes. Attach the belt and sensor as instructed.

  • Page 28: Measuring - Details

    1. Make sure that you have an active Internet connection via Wi-Fi or mobile data. 2. Make sure that your device has the volume switched on. 3. Make sure you have paired the Omegawave sensor in the application. 4. Make sure that the athlete is correctly wearing the chest strap, sensor and electrodes as previously described.
  • Page 29 The application will automatically find the paired Omegawave sensor. If the sensor does not appear, tap “Troubleshoot connectivity problem” on the screen to review possible reasons, see screenshots below. The most common reason is that the ECG chest strap electrodes have not been properly moistened.
  • Page 30 7. While getting ready for the measurement, you will probably still be moving around. Any movement, talking, coughing, sneezing or other such activities will disrupt the signal being received from the sensor. Under such a scenario, you will be notified on-screen and through voice guidance (which can be muted).
  • Page 31 9. There may also be other reasons why the Start measuring button is not turning green, check the messages under the ECG and DC sensor to review possible reasons. 10. When the sensor is ready to start a measurement, the Start button will turn green. To begin the measurement, tap Start measuring.
  • Page 32 12. If the signal quality is very poor, the measurement will be cancelled and you will be required to start again. This is because a good quality signal is required to complete the sophisticated data analysis performed by Omegawave. 13. You will hear a sound when the measurement is complete. Please ensure that your iPad’s volume is switched on.
  • Page 33 If the athlete maintains a resting position and you initiate a new measurement without following this protocol, the athlete’s functional state will change from active to reduced wakefulness. Omegawave’s algorithms are designed to analyze an athlete’s functional state at an active level of wakefulness.

  • Page 34: Measurement Troubleshooting Tips

    If the potential solution listed for the case doesn’t work, try the other ones one-by- one until you have tried all of them. If you are still experiencing difficulties, please reach out to Omegawave so that we can investigate the issue further (support@omegawave.com). Source of...

  • Page 35: Team Analysis - Overview

    Electrical Electrical interference in the immediate vicinity Avoid completing interference of the user may cause electric ‘noise’, thereby measurement right next to sources (from disrupting the ECG signal. of electrical interference. refrigerators, fluorescent lights, etc.). TEAM ANALYSIS – OVERVIEW The team Overview provides a snapshot of all your athletes based on their latest measurements: Your athletes are automatically sorted into three groups: excellent, moderate and poor.

  • Page 36: Team Analysis - Detailed View

    This view also gives information about the status of the athletes’ licenses. You can select an individual athlete for analysis by tapping the athlete’s name. TEAM ANALYSIS – DETAILED VIEW The detailed view allows comparisons to be made between athletes based on their Central Nervous, Cardiac, Energy Supply systems and Overall Readiness scores.

  • Page 37: Athlete Analysis

    NOTE! For a more in-depth discussion on interpreting results and utilise them for athlete preparation, refer to the Coach’s Handbook. You will find a link to the handbook in the getting started email.
  • Page 38 Windows of Trainability™ represents an innovative approach to athlete preparation, one that can be easily integrated into any system of training. Omegawave’s approach centers on the concept that the amount of the load should not be the primary focus of the training process, but rather the timing of when the load is applied.
  • Page 39 If you want to see the textual conclusion of the Windows of Trainability™ scale, tap the paragraph symbol If you want to see the definition of each physical quality, tap the individual hexagon. If you want to see the training advice of each physical quality, tap the individual hexagon and scroll down until you see the “Training advice”...
  • Page 40 Training zones The graph in the middle of the screen shows both the athlete’s resting heart rate and the suggested heart rate training zones as those levels relate to cardiac and metabolic training. The numerical heart rate values in these training zones can change from one measurement to the next, reflecting changes in the athlete’s current functional state.
  • Page 41 Functional state In this graph, Overall Readiness is divided into two subsystems: Central Nervous and Cardiac systems. The measurement results will determine the color and completeness of the circles. The color scale for these circles is the same as that of the hexagons in the Windows of Trainability™ scale: green, yellow, and red.
  • Page 42 Readiness Breakdown By swiping up/down from the main screen you will be able to access a detailed view of each physiological system and sub-system assessed: Central Nervous System (CNS) System Readiness • DC Potential • DC Curve •...
  • Page 43 Cardiac system System Readiness • Resting heart rate • Recovery pattern • Stress • Adaptation reserves • Autonomic balance • Cardiac System – HRV 1 Detailed breakdown of your Heart Rate Variability •...
  • Page 44 Cardiac System – HRV 2 Further analysis of your Heart Rate Variability and a tool of viewing your ECG (can be magnified • by tapping the icon zoom icon...
  • Page 45 Energy Supply System System Readiness MRI (metabolic reaction index) Aerobic readiness Anaerobic readiness Each data point on the graph represents one measurement. Tap the data point to see the • associated index values. Analyze your full measurement history by swiping the graph left or right. •...
  • Page 46 Other functions The following icons are visible on the application title bar when you are in athlete analysis view: Delete a measurement: Delete currently selected measurement If you delete a measurement, you are not able to undo this operation. If you accidentally deleted a measurement, please contact customer support.

  • Page 47: Faq

    When the sensor’s Bluetooth is activated, the LED starts to blink a blue light at a fast pace. When the sensor is connected to the Omegawave App and is ready for a measurement, the LED blinks slower.
  • Page 48 To calculate and see results, make sure that you have a working Internet connection and then tap the sync button An athlete has done a measurement but his/her results are not updated to the Coach app? Tap the sync button to fetch measurements from the Omegawave cloud and verify that you have a working Internet connection.
  • Page 49 In this case, contact Omegawave support for further assistance: support@omegawave.com Can the ECG chest straps be washed? Yes, and it’s recommended to do so regularly inside a washing bag. The washing recommendations are printed on the strap care label (40°C / 104°F, no fabric softener).

  • Page 50: Regulatory Information

    REGULATORY INFORMATION OMEGAWAVE HAS NOT APPROVED ANY CHANGES OR MODIFICATIONS TO THIS DEVICE BY THE USER. ANY CHANGES OR MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. OMEGAWAVE N’A APPROUÉ AUCUNE MODIFICATION APPORTÉE À L’APPAREIL PAR L’UTILISATEUR, QUELLE QU’EN SOIT LA NATURE.
