GUIDESMAN EasyLift 2721935 Setup & Takedown Instructions

SETUP & TAKEDOWN INSTRUCTIONS
Use for the following Models:
GUIDESMAN Easylift canopies can be set up and taken down with one person or two. Please see below.
Parts Included: Fully Assembled Frame ( ) Canopy Top ( ) Wall ( ) Wheeled Bag ( ) Stakes ( )

SECURING THE CANOPY TOP TO THE FRAME

1
2
3
Fig. 1A

SINGLE PERSON CANOPY SETUP

1
2
3
Fig. 1A
page 1
THANK YOU FOR PURCHASING A GUIDESMAN INSTANT CANOPY!
Please carefully review the following instructions and familiarize yourself with parts included
and how to operate your GUIDESMAN canopy. Reference parts list for names of each part
noted in instructions.
GUIDESMAN EasyLift POP-UP CANOPIES
SKU # 2721935 GUIDESMAN 8'x8' Easylift Pop-up Canopy
SKU # 7 9 6 GUIDESMAN
SKU # 7 9 7 GUIDESMAN
Place the canopy frame in the desired location (Fig. 1A). Position one hand on any frame leg just
below the black fastening strip and place your other hand on the lower eaves bar as shown (Fig. 1B).
Lift the frame leg slightly off the ground so all legs except the leg directly across bearing
the weight clears the ground. Take steps backwards to open the frame as much as possible (Fig. 2A).
Unfold the canopy top and place it over the open frame (Fig. 3A). Secure each corner by attaching
the corner of the canopy top to the black fastening strip (Fig. 3B). Pull all 4 corners down until
completely over black fastening strip. Attach fastening loops to the eaves of the frame as shown in (Fig. 3C)
Your canopy top is now secured to the frame.
Fig. 1B
Fig.
Place the canopy in the desired location for shade. Position one hand on any frame leg just below the black
fastening strip and place your other hand on the lower eaves bar as shown (Fig. 1A). Lift the frame leg slightly
off the ground so all legs except the leg directly across bearing the weight clears the ground. Take steps
backwards to open the frame as much as possible (Fig. 1B).
Before proceeding, make sure canopy top is over the eaves on all 4 sides as shown in (Fig. 2A). Stand in the
middle of the eaves between two legs and place your hands on the eaves and lift to gain entrance to the
underside of the canopy (Fig. 2B). Once underneath, place your hand on the black center hub as shown
in (Fig. 2C) and push up twisting the hub a ¼ turn clockwise to lock in the frame.
Each leg has height adjustments. Lift outer leg up and slide out the inner leg to desired height (Fig. 3A).
Repeat for other 3 legs. Your canopy is now set up.
Fig. 1B
TM
'x ' Easylift Pop-up Canopy
'x ' Easylift Pop-up Canopy
2A Fig. 3A
Fig. 2A
Fig. 2B
Fig. 3B
Fig. 3C
2C
Fig. Fig. 3A
