Resson Technologies RD-13L Operation Manual

Digital readout system
Hide thumbs

Advertisement

Quick Links

Download this manual
Technologies
The People that Always Committed to Quality, Technology & Innovation
R
RD-13L
esson
Technologies
ent
On
O
Off
RD-13L
Digital Readout System
Operation Manual
(Lathe)
Resson Technologies Co., Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RD-13L and is the answer not in the manual?

Questions and answers

Related Manuals for Resson Technologies RD-13L

Summary of Contents for Resson Technologies RD-13L

  • Page 1 Technologies The People that Always Committed to Quality, Technology & Innovation RD-13L esson Technologies RD-13L Digital Readout System Operation Manual (Lathe) Resson Technologies Co., Ltd.
  • Page 2 esson Precautions Technologies Precautions For your protection, please read these safety instructions completely before operating the appliance. ● Selection of mains voltage The Digital readout unit is supplied for 100V 230V, 50Hz/60Hz, 20W max operation. ～ Instructions prior to activation of unit 1.

  • Page 3: Table Of Contents

    Content Technologies 1 Basic Functions ..........1 REF Datum Memory ........8 3 Cone Measurement Function ......13 4 Digital Readout Setup Function ..... 17 5 RD-13L Specification ........23...

  • Page 5: Basic Functions

    Basic Functions Technologies Basic Functions RD-13L esson Technologies - 1 -...
  • Page 6 Technologies Purpose : Set the current position for that axis to zero Example : X Axis zero To set the current position to RD-13L RD-13L esson esson Technologies Technologies 286.785 0.000 25.680 25.680 Purpose : Switches between inch and metric display...
  • Page 7 Operator can then toggle between (absolute) and (incremental) coordinates without losing the work piece datum ( work piece zero position ). Example 1 : Currently in display coordinate, to switch to display coordinate RD-13L RD-13L esson esson Technologies Technologies Example 2 : Currently in...
  • Page 8 Radius/Diameter display for X axis. Example 1 ： Currently in Radius display, to switch to Diameter display RD-13L RD-13L esson esson Technologies Technologies 50.800 25.400 25.680 25.680...
  • Page 9 Dimension Preset Technologies Purpose ： Set the current position for that axis to an entered Dimension Example ： To set the current X Axis position to 45.800mm RD-13L RD-13L esson esson Technologies Technologies 286.785 45.800 25.680 25.680 Application Tips : The dimension preset function provides a very convenience way to monitor your cross feed machining, the X axis machining.
  • Page 10 Example ： To set the Z Axis zero point at the center of the work piece Step 1 ： Locate the edge finder at one end of the work piece, then zero the Z Axis. RD-13L RD-13L esson...
  • Page 11 Example 1 ： Currently in INC display coordinate, to switch to TOOL 1 display coordinate. Sdm 1 RD-13L RD-13L esson esson...
  • Page 12 esson Technologies Z axis ref mark position - 8 -...

  • Page 13: Ref Datum Memory

    esson Technologies Function ： During the daily machining process, it is very common that the machining cannot be completed within one work shift, and hence the DRO have to be switched off after work, or power failure happen during the machining process which is leading to lost of the work piece datum (work piece zero position),the re-establishment of work piece datum using edge finder or other method is inevitably induce higher machining inaccuracy because it is not possible to...
  • Page 14 ( FIND REF )function whenever they switch on the Counter. Setp 1 FIND REF ： Enter into the ref function, select the (find mark) RD-13L esson Technologies FIND REF RD-13L esson Technologies FIND REF (find ref mark)
  • Page 15 Technologies Step 3 ： Move the machine across the center of the glass grating scale until digits display in Counter start run. select Z axis in this example Z REF RD-13L RD-13L esson esson Technologies Technologies 0.000 1.250 (move towards positive direction)
  • Page 16 Technologies Step 2 ： Select the axis of which work datum (zero position) needed to be recovered select X or Z SEL AXIS Z REF RD-13L RD-13L esson esson Technologies Technologies Select all axis X,Z respectively Step 3 ： Move the machine across the centre of the glass grating scale until digits display in Counter start run, then work piece datum is recovered.

  • Page 17: Cone Measurement Function

    esson Cone- cone measurement function Technologies Cone- cone measurement function Cone angle - 13 -...
  • Page 18 Enter the cone measurement function and enter the -20 degree as the cone comparison parameter. enter incline angle (INCL ANG) enter into CONE function INCL ANG RD-13L RD-13L esson esson cone angle (INCL ANG)=-20degree Technologies Technologies -20.000...
  • Page 19 After the cone measurement angle have been entered into the readout, the X axis zero will move as the Z axis travel at -20 degree. A) zero the dial indicator on one end of the work piece ANG -20.0 RD-13L esson Technologies 0.000 0.000...
  • Page 20 CONE function cycle (swap to normal XZ display).Operation are as follows: temporarily retum to Presently in CONE cycle XZ coordinate display temporarily swap to normal XZ coordinate display ANG -20.0 ANG -20.0 RD-13L RD-13L esson esson Technologies Technologies 0.000 -78.560 0.000...

  • Page 21: Digital Readout Setup Function

    Digital Readout Setup Function Technologies RD-13L Digital Readout Setup Function RD-13L esson Technologies specifies the direction of count for each axis DIRECTIN LIN COMP permits linear error compensation to be input QUIT exits the SETUP function to proceed to normal working...
  • Page 22 Digital Readout Setup Function Technologies R D - 1 3L O R I GI N A L P AR A M E TE R R E S ET F U N C TI O N RD-13L esson Technologies Some inscrutable cases or improper operations cause the chaos of parameter, then you need to initialize the parameter to reset the system.
  • Page 23 Digital Readout Setup Function Technologies ( ) When enter into the RESET function, DRO will display ３ ： RAM TEST RAM OK RD-13L RD-13L esson esson Technologies Technologies if the RAM function is normal， display "RAM TEST" that DRO can display "RAM OK"...
  • Page 24 R D - 1 3 L S E T U P F U N C T I O N AX I S K E Y ME S SA G E W I ND O W RD-13L esson Technologies U P /D O WN K EY S...
  • Page 25 Digital Readout Setup Function Technologies 3.) Press key to select the "DIRECTN" (counting direction) function. Press key to return to the last function. SETUP DIRECTN RD-13L RD-13L esson esson Technologies Technologies Press key into the direction setting function, the 0 represents a positive, 1 represents a negative.
  • Page 26 -15μ X -(1000/500) = 30μm the compensation value is 30μm If set up the linear compensation value of X Axis = 30, through the AXIS key make a same procedure for Y Axis. ENTR.PPM ENTR.PPM RD-13L RD-13L esson esson Technologies Technologies 5.) Press...

  • Page 27: Rd-13L Specification

    RD-13L Specification Technologies RD-13L Specification : Number of axes : 、2 Reslution : 0. Display function : 8 Response speed : 60m (198.6feet)/min Quantizing error : ± 1 count Power source : AC 0V～ 0V / 50～60Hz / 20VA Temperature fange : Service:0～40℃...
