Summary of Contents for REDHEAD SF5040RC

  • Page 1 Handleiding...
  • Page 2 OPERATING INSTRUCTIONS FOR FASTENER DRIVING TOOLS OPERATED BY COMPRESSED AIR Air Nailer –2 In 1 Combi Nailer IMPORTANT: Read all safety rules and operating Instructions carefully before first use it. Keep this Manual for future reference. Residual risks Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise in connection with the tool’s construction and design: Damage to lungs if an effective dust mask is not worn.
  • Page 3 2.5 Safety at work 8 Spare parts list 2.6 Triggering devices 1 Technical data Type of tool ................SF5040RC Weight (without fasteners) ............1.5kgs Activation mode ..............single sequential actuation Maximum allowable pressure ............ 8.3 bar Recommended allowable pressure range ........4.8 to 7.5 bar Noise characteristic values in accordance with EN 12549.LpA : ..
  • Page 4 2 Special references 2.1 Instructions The following standard is applicable to fastener driving tools; EN792-13:2000‖Hand-held non-electric power tools-safety requirements – Part 13: Fastener driving tools‖. This standard requires that Only those fasteners which are specified in the operating instructions (see TECHNICAL DATA) shall be used in fastener driving tools.
  • Page 6 2.7 Actuating systems Depending on their purpose, fastener driving tool is fitted with actuating system of single sequential actuation. Single sequential actuation: An actuating system in which the trigger and the safety yoke have to be activated so the only one single driving operation is actuated via the trigger after the muzzle of the tool has been applied to the driving location, Thereafter further driving operations can only be performed after the trigger has been returned to the non driving position whilst the safety yoke remains depressed.
  • Page 7: Technical Data

    4 Preparing the tool for use 4.1 Preparing a tool for first time operation Please Read and observe these Operating Instruction before using the tool. Basic safety measures should always be strictly followed to protect against damage to the equipment and personal injury to the user or other people working in the vicinity of operation.
  • Page 8 5. Maintenance Disconnect the tool from the compressor before adjusting, clearing jams, servicing &maintenance, relocating and during non operation. Regular lubrication, if your tool without using the in-liner automatic oilier, place 2 or 6 drops of pneumatic tool oil into the air inlet before each work day or after 2 hours of continuous use depending in the characteristic of work piece or type of fasteners.
  • Page 9 7. Explode Drawing (See Figure 5) Figure 5...
  • Page 10: Parts List

    8. Parts list NO K3 Code Description K3 Code Description K3 Code Description 03 04 40 128 03 04 36 099 Compressed Spring B 03 04 30 053 Flexible Bar Steel Ball(dw=2 5) 03 04 36 098 Spring A 03 04 23 101-03 Adjustable Nut II 03 04 08 107 Nose...
