Summary of Contents for REDHEAD BN50RC

  • Page 1 Handleiding...
  • Page 2 OPERATING INSTRUCTIONS FOR FASTENER DRIVING TOOLS OPERATED BY COMPRESSED AIR AIR-POWERED BRAD NAILER IMPORTANT: Read all safety rules and operating Instructions carefully before first use it. Keep this Manual for future reference. Residual risks Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise in connection with the tool's construction and design: •...
  • Page 4 DANGER! Potential hazard that will result in serious injury or loss of life. Keep children away from the work area. Do not allow children to handle power tools. Keep air hose away from heat, oil, and sharp edges. Check air hose for wear before each use and ensure that all connections are proper.
  • Page 5 Do not carry the compressor while it is running. Do not operate the compressor if it is not in a stable position. Do not operate the compressor on a rooftop or in an elevated position that could allow the unit to fall or be tipped over.
  • Page 6: Key Parts Diagram

    KEY PARTS DIAGRAM Description Description Magazine Trigger Gun Body Air inlet plug Cylinder Cap IMPORTANT INFORMATION Compatible compressors GUIDELINES FOR PROPER USE AND OPERATION Be sure to use a proper air compressor with air powered tools. The compressor should be able to supply a minimal air delivery of 6.36SCFM @ 90PSI to ensure the compressor can run continuously with the air nailer.
  • Page 7 to the tool, which will cause reduction in power, efficiency, and general performance. For optimal performance, install a quick connector to the tool and a quick coupler on the hose, if  applicable. Verify that all of the connections in the air supply system are sealed in order to prevent air from leaking. ...
  • Page 8 OPERATING INSTRUCTIONS 4.1 Preparing a tool for first time operation Please Read and observe these Operating Instruction before using the tool. Basic safety measures should always be strictly followed to protect against damage to the equipment and personal injury to the user or other people working in the vicinity of operation.
  • Page 10 screws and caps to avoid personal injury. This should be done by an expert. Make regular inspection for free movement of trigger, Spring and safety mechanism to assure safe system is complete and functional: no loose and missing parts, no building or stocking parts. Keep magazine and nose of tool clean and free of any dirt lint or abrasive particles.
