Summary of Contents for MAXTRA MAX
- Page 1 MAXTRA ELECTRIC SCOOTER FOR ADULTS USER MANUAL...
- Page 2 Thank you for choosing MAXTRA! Please take a few minutes to read this user manual before using it.This manual will help you better under- stand your scooter and, with proper care, it will provide years of trouble-free use. If you have any questions, please do not hesitate to contact us.
- Page 3 Contents ................Must Read ..............Safety Warning .................. Unpack ............... Know Scooter ..............Parts Replacement ................ Specifications ................Assemble ................. Charge ................. Console ................Anti-theft ..................Fold ................ Started Riding ................Riding Tips .............. Dangerous Actions ..............Bluetooth/APP ..............Maintenance...
- Page 4 Always wear a helmet when riding your electric scooter. Make sure youre scooter has a full battery before taking it out to ride. Always be aware of local road laws，and follow them. Do not ride the scooter under the influence of drugs or alcohol. Always respect pedestrians.
- Page 5 2. Abuse - We do not cover physical damage due to negligent care and extremeriding. 3. Whenever you ride the MAXTRA scooter, you risk severe injury or even death from loss of control, collisions, and falls. Use caution and ride at your own risk.
- Page 6 You should find each of these items in your box: 1. Electric Scooter 2. 6 Connecting screws（Installation requires only 4 ） 3. 3mm Allen Wrench 4. Approved Power Adapter / Charging Unit 5. 2 Spare large screw...
- Page 7 Led Panel Disc Brake Handle Throttle #4 Grip Electronic Brake Hook Headlight Stem Anti-Theft Lock #5 Front Fork Cover Fold button Deck Cover Front Fender #3 Front Wheel #1 Lithium Batter Pack #9 Rear Fender #6 Kickstand Tail Light Charge Port #7 Reflector Motor #3Rear Wheel...
- Page 8 Part# Image Part Name Quantity Lithium Battery Charger Wheel Grip Front Fork Cover Kickstand Reflector Disc Brake Rear Fender Tool Bag...
- Page 9 3cm high working temperature 14~104°F storage temperature -4~113°F Waterproof IP54 Rated Voltage 36 VDC Max. Output Voltage 42 VDC Rated Capacity 7.8 Ah Over-current Protection，Double Protection from Battery Parameters Overcharging，Double Protection from Battery Smart Management System Over discharging，Over-current Protection，...
- Page 10 Press the fold button and lift the stem vertically Connect the wire inside the handlebar and the stem，then insert the handlebar into the stem Use screws and wrenches to secure handlebar in place...
- Page 11 Before using the scooter, you must fully charge the battery. 1.Open the charging port cover. 2.lnsert the charging plug into the port. 3.The charger box will have a green light when fully charged and a red light when- charging. 4. When you are done charging be sure cover the charging port to keep it clear ofdust and debris.
- Page 12 Panel function Brake Level Speed Level Seep Cruise Light Km/h Bluetooth Speed Mode Start Button power A. Start, Turn on/off Light, Choose Speed Level, Shut 1. Press the start button : 1.1 Press the start button for 2 seconds to start E-scooter. 1.2 One touch of the start button to turn on or turn off the light.
- Page 13 At the bottom of the stem is a built-in anti -the ft d evice in the form of asteel cable that can be locked with a nume rical code. 1.Lockin g head 2.Anti- theft cable 3.Anti- theft cable storage sp ace4.Lock 5.
- Page 14 The E-scooter could be folded to save save and convenient to carry or store. Fold the kickstand Hold the front tube with your left hand, press the folding block. Press down the front tube to complete the folding operation. Hold the front tube with your left hand, press the folding block with your right hand.
- Page 15 wear an approved helmet and other protective gear to minimize any possible injury Km/h Turn the power on, and check the electricity indicator. Stand on the base with one foot and propel yourself with the other foot. When the electric scooter begins to glide, put both feet on the deck and press the accelerator.
- Page 16 Please keep a medium or low speed (５mph) when you ride Do not ride in the rain. through speed bumps,elevator door sills, bumpy roads or other uneven surfaces Slightly bend your knee to better adjust mentioned surfaces Always steer clear of obstacles. Do not press the throttle when walking with the scooter.
- Page 18 Install the APP For Android users, scan the QR code on the left, and for IOS users, scan the QR code on the right to download the APP. Or search for "UNI SCOOTER "in the Android APP STORE/Apple APP STORE to download Turn on the scooter power, open the APP and click search.
-
Page 19: Maintenance
Cleaning and Storage Use a soft, wet cloth to wipe the mainframe clean. Dirt hard to remove can be scrubbed with a toothbrush and toothpaste, then cleaned with a soft, wet cloth. NOTE Do not wash your scooter with alcohol, gasoline, acetone, or other corrosive/volatile solvents. - Page 20 When used at room temperature (70°F [22°C]) the battery range and performance is at its best; whereas using it at temperatures below 32°F (0°C) can decrease range and performance. Typically, at -4°F (-20°C) range can be half that of the same battery at 70°F Typically, a fully charged battery should retain power for 120-180 days.
- Page 21 FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. ...
