SURE SHOT
PORTABLE COURT SYSTEM
MODEL 513 ST. LOUIS
ASSEMBLY INSTRUCTIONS
YOUR BEST SHOT !
FAILURE TO READ INSTRUCTIONS COMPLETELY BEFORE
ASSEMBLY COULD RESULT IN SERIOUS INJURY !!!
BEFORE BEGINNING ASSEMBLY READ INSTRUCTIONS
COMPLETELY AND CHECK TO SEE IF ALL PARTS WERE
INCLUDED USING THE PARTS LIST PROVIDED.
WARNING !!!
TO PREVENT THE PORTABLE COURT
SYSTEM FROM TIPPING. DO NOT ATTEMPT
TO STAND THE UNIT UP WITHOUT FIRST
FILLING THE BASE WITH SAND.
THE UNIT COULD FALL OVER WITHOUT SAND
IN THE BASE THIS COULD CAUSE DAMAGE
OR INJURY
DO NOT ALLOW CHILDREN TO ADJUST.
CLIMB ON OR HANG FROM ANY PART
OF UNIT.
DO NOT PERFORM SLAM - DUNK PLAY
ON THIS UNIT
THE PORTABLE UNITS ARE NOT DESIGNED
FOR THIS TYPE OF EXTREME USE.
DO NOT USE THE UNIT DURING WINDY
CONDITIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the 513 ST. LOUIS and is the answer not in the manual?

Questions and answers

Summary of Contents for SURE SHOT 513 ST. LOUIS

  • Page 1 SURE SHOT PORTABLE COURT SYSTEM MODEL 513 ST. LOUIS ASSEMBLY INSTRUCTIONS YOUR BEST SHOT ! FAILURE TO READ INSTRUCTIONS COMPLETELY BEFORE ASSEMBLY COULD RESULT IN SERIOUS INJURY !!! BEFORE BEGINNING ASSEMBLY READ INSTRUCTIONS COMPLETELY AND CHECK TO SEE IF ALL PARTS WERE INCLUDED USING THE PARTS LIST PROVIDED.
  • Page 2: Part List

    PART LIST Tension Bar 45×8mm 50×8mm 38×8mm 50×8mm 110×8mm 110×8mm 153×10mm 153×10mm 44×12mm 30×12mm Plastic Caps for Nut Pipe Top Cap Round Round Steel Strip with two holes 45×35mm Qty. - 2 Nos. Steel Strip with Ground Anchor one hole 45×35mm Ground Anchor Sleeve Qty.- 4 Nos.
  • Page 3 POLE INSTRUCTIONS BE SURE TO CORRECTLY IDENTIFY THE POLE SECTIONS BEFORE BEGINNING ASSEMBLY TOP POLE SECTION MID POLE SECTION BOTTOM POLE FOUR ROUND HOLES NO HOLES TWO ROUND HOLES AT THE BOTTOM AND TWO ROUND HOLE AT THE MID POINT NOTE : ALL POLES HAVE A SMALL HOLE AT THE TOP THIS IS FOR MANUFACTURING PURPOSES ONLY.
  • Page 4 Required Material and tools 1. 8×25kg sand bags 4. 13mm Wrench/socket 2. Adjustable wrench 5. Large screwdriver 3. Hammer 6. 2 block wood approx. 10×10×3cm NOTE : Bolt kit check list is included in the bolt kit. Be sure to check contents prior to assembly.
  • Page 5 BEFORE CONTINUING ASSEMBLY Backboard and goal should be assembled at ground level. Assembly at top of pole could result in injury. Attach ring (P2) with backboard (P3) at the same time attach back STEP-5 support (P4) using nut & bolt (B-50×8mm) and at the top of backboard support use nut &...
  • Page 6 STEP-9 Attach small & big extension tubes (P5) with backboard (P3) back support (P4) using nut & bolt (G-153×10mm) and tighten Round tube (I-44×12mm) it with the help of two spanners. between back support (P4) STEP-10 Insert internal tube pipe to the tension bar (P8). Make sure that the spring rod hole match to hole of extension bar pipe (P8).
  • Page 7 STEP-13 Cover the top pole with plastic cap (L ) & also cover the nut with plastic cap (K) before pole is in playing potion Use the large loops of the net install onto the ring "no-ties" STEP-14 Part (O) FOR ADDITIONAL STABILITY Part (O) Steel Strip (N)
  • Page 8 This routing will prolong the life of your pole. If your pole becomes scratched and rust begins to appear, repair by using rust proof gloss black paint ( follow instructions on paint can). THANK YOU FOR BUYING SURE SHOT !!! Page-8...
