2020
WXL
AA1XLPE Devices
Quick Install
Guide
INSTALLER TEST CODE:
Recommended Wire Guide
18 gauge stranded - up to 25 ft
16 gauge stranded - up to 50 ft
12 gauge stranded - up to 60 ft
CODE WILL STOP WORKING AFTER 10 USES.
Technical Support: 972-231-1999 option 2
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
Advertisement
Related Manuals for CellGate Watchman WXL
Summary of Contents for CellGate Watchman WXL
- Page 1 2020 AA1XLPE Devices Quick Install Guide INSTALLER TEST CODE: Recommended Wire Guide 18 gauge stranded - up to 25 ft 16 gauge stranded - up to 50 ft 12 gauge stranded - up to 60 ft CODE WILL STOP WORKING AFTER 10 USES. Technical Support: 972-231-1999 option 2 FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
- Page 2 WATCHMAN **Recommended wiring: 18/6 shielded for main device, and 18/4 shielded for optional wiegand devices** Items Included in Kit ❶ ❻ WXL Unit Bolts ❷ ❼ 12 Volt DC Power Supply Quick Install Guide ❸ ❽ Magnetic Read Switch Activation & Test Process ❹...
- Page 3 WATCHMAN Interface Wiring Diagram (Oriented the same as the Watchman install) ❷ ❸ ❶ ❹ 6-Wire Installation Instructions ❶ Wire main power from the transformer to the power connector on the circuit board. ❷ Connect gate trigger wires from the Normally Open (NO) Common (C) to the free-exit or exit terminals on the gate operator.
- Page 4 WATCHMAN Installation Testing Enter the Testing Code, then tap the Enter Button. Home Call List Enter a Code Enter Button Code will activate Relay 1 (the gate should open). Locate a Callgroup and tap on it to call it. An automated message will play confirming the call was successful.
- Page 5 WATCHMAN External Camera Installation • If you’re installing an External Camera, call CellGate Technical Support for testing. • Technical Support: (972) 231-1999 option Customer Information Leave the following items with the Customer: • Customer Information Packet • WXL - Key...
