Console Buttons and Status Lights

A: Amplifier inputs
B: Run
C: Pause/Preview
D: Stop/Check Impedance
E: Toggle Safety Light/Set Safety Light Intensity
F: Warming Table Power Indicator
G: Warming Table Below Temperature Indicator Light
H: Warming Table Above Temperature Indicator Light (error state)

Dimensions and Weight

Celeris (height to table top): 15.7 x 6.9 x 5.3 inches (399 x 175 x 135 mm)
Celeris heating table: 6.1 x 4.0 inches (155 x 102 mm)
Celeris weight: 10 lbs (4.5 kg)
14770-A || ECN # 844 ||
Mice, rats, gerbils and guinea pigs
•
2-channel, fully differential, 32-bit amplifiers have 1 nV resolution over a
4V input range, which provides the highest resolution in the industry
•
Ultra-low noise
•
5V input range, ensures amplifier will not saturate
•
Common mode rejection ratio (CMMR): >100 dB
Temperature: 99°F / 37° C, ± 1°C
Red (670 nm) and infrared (940 nm) LEDs
Exports natively to .csv, .txt, or to clipboard for easy import into data processing
software such as Excel, S
IGMA
Flat tabletop covered with waterproof membrane makes cleanup simple and easy
Infrared camera available
Photopic and Scotopic ERG testing
Scotopic Threshold Testing
Flash VEP
Pattern ERG
Bright: .0003 cd.s/m through 700 cd.s/m
2
Dim: 10 cd.s/m through 10
-7 2
Windows 10 Professional
ECN Date: 28 July 2017
P , or MATLAB
LOT
(extended range available)
2
cd.s/m
-1 2
Figure 1 - Console control buttons and status lights
