FIXINGS *P - These screws must only be used for frame only configuration or when using a desktop without metal screw inserts. COMPONENT LIST A - Desk Legs B - Under-desk Support Arm C - Cross Beam D - Feet E - Power supply lead F - Control switch (Basic or Memory) G - Power supply lead...
Page 4
Insert screws but do not tighten. Gap needed for ‘L’ x4 frame and brackets in steps 4 and 5. CAUTION Components are heavy – take care when handling Feed leg motor cables through centre hole...
Page 5
Fully tighten screws. ‘L’ x4 Do not tighten: Keep loose for step 5.
Page 6
Fully tighten screws. It may be necessary to use a soft headed mallet to fit tight fitting support arm onto the leg / frame.
Page 8
Hand tighten fully into foot. ‘S’ x4 NOTE Check desktop for any delivery damage before commencing this stage. Basic control switch Memory control switch NOTE Carefully unpack the desktop leaving it face down on the packaging supplied so as to protect the work surface.
Page 9
NOTE Insert switch into aperture by applying firm, even pressure. Ensure correct orientation of switch within the aperture. Basic control has ‘UP’ stamped on the rear, position ‘SWITCH’ this furthest from the front edge. CAUTION Frame is heavy – take care when positioning it. Carefully lower the frame onto the underside of the desktop.
Page 10
Omit screws if fitting cable tray Fully tighten screws. Fully tighten screws. ‘N’x16 ‘P’x16 ‘N’x14 when NOTE Use P x16 only if using desktop Cable Tray Used without metal screw inserts...
Page 11
NOTE Double check all screws are now tight ‘R’x8 NOTE Fit the plastic caps to exposed frame screw heads. Press hard to locate the caps onto the screws and tap home securely using a mallet The caps are designed to mould onto the screws through force.
Page 12
NOTE All leads MUST be plugged into the control box before connecting power lead and switching the power on. Failure to comply could result in damage to the unit. ‘N’x2 Fully tighten screws. SWITCH...
Page 13
‘H’x5 NOTE For ease of assembly, fit Use cable clips 'H' optional cable tray before turning to keep cables tidy. desk over to upright position Desk is now ready to use. Turn upright and perform reset procedure - see p. 18. CAUTION - Desk is heavy - 2 person operation...
Page 14
OPTIONAL CABLE TRAY NOTE! When mounting the cable tray on a 600mm deep top and using a monitor arm assembly, the cable tray will have to be mounted inside of the desktop support arms and fixed directly to the desktop with woodscrews to allow clearance of the monitor arm fixing bracket.
Page 15
Omit screws to fit Cable Tray. ‘T7’ x4 Fully tighten screws.
RESET PROCEDURE IMPORTANT! A reset procedure MUST be carried out immediately following assembly of the desk. • Lower the desk to its lowest position by pressing the down arrow on the hand control. • Release the button. • Press the button again and keep it pressed for 10 seconds •...
Page 19
SAVING A MEMORY POSITION Select desired height using the 'UP/DOWN' button. Press the 'SAVE' button followed by the memory number.
