Installing
Automatic Cover Lifter & SpaEase 200
For Video Instruction Manual go to:
ConvertALift.com
To install a ConvertALift and a SpaEase 200 System
on a hot tub requires 2 items.
1. ConvertaLift System
2. SpaEase 200 Lifter
Disregard the manual in the SpaEase 200
Lifter and follow this manual.
If you have any questions,
please call us at 860 469 2580
Hot Tub Products, LLC
2 Toelles Road, Suite 13, Wallingford CT
Email:
info@hottubproducts.com
Hot Tub Products, LLC
• 2 Toelles Road, Suite 13, Wallingford CT 06492 • Phone: 860-469-2580 • www.hottubproducts.com
1
