Summary of Contents for ICCN WP6000 Series

Page 1 WP6000 Series Switches WP6000 Series Switches WP6000 Series Switches Installation Guide Installation Guide Installation Guide Supported Models: Supported Models: Supported Models: ICC Networking Enterprise Gigabit Power-over-Ethernet Switch ICC Networking Enterprise Gigabit Power-over-Ethernet Switch ICC Networking Enterprise Gigabit Power-over-Ethernet Switch Product Model: Link6010-8POE, Link6026-24POE, and Link6012IND-8POE...
Page 2: Intended Audience
Intended audience This guide is designed to be used by network managers, IT administrators, and technicians who are responsible for installing, networking equipment in enterprise and service provider environments. Knowledge of telecommunication and internet protocol (IP) technologies is assumed. Documentation ®...
Page 3 Ethernet switches used to build high-performance and intelligent switched workgroup networks. This switch is a store-and-forward device that offers low latency for high-speed networking. The WP6000 series also features a “store-and- forward” switching scheme that allows the switch to auto-learn and store source addresses in a 8K-entry MAC address table.
Page 4 WP6000 Series Overview Link6010-8POE Package contents include the following: PoE switch AC power cord Two (2) rack-mount pallet and Six (6) screws Four (4) adhesive-backed rubber feet Support Card Link6026-24POE Package contents include the following: PoE switch AC power cord...
Page 5 Quick considerations when troubleshooting This section is intended to help solve the most common issues with the PoE Switch Incorrect connections Every port on these switches can automatically detect either straight or crossover cables when you link it with other Ethernet devices but other devices may require a specific cable type (depending on the device).
Page 6: Chapter 1 Graphical User Interface Basics
Users can access the WP6000 series to configure a variety of features including but not limited to: 1. Network: Spanning Tree, MAC Address control, port configuration, etc.
Page 7: Web Page Elements
3、Starting an initial web session To start a web user session the user must log into the WP6000 series switch by confirming the To start a web user session the user must log into the WP6000 series switch by confirming the...
Page 8 The navigation tree organizational structure is simple to use for a quick view of all possible features The navigation tree organizational structure is simple to use for a quick view of all possible features and protocols that can be adjusted by the WP6000 series switches. and protocols that can be adjusted by the WP6000 series switches.
Page 9: Error Messages
SNMP configuration allows the user to enter data into one row at a time. The very first entry will show 'New' in the Item row until data is entered. Once entered and applied the WP6000 series show 'New' in the Item row until data is entered. Once entered and applied the WP6000 series show 'New' in the Item row until data is entered.
Page 10: Status Field
Chapter 2 Quick Stats Chapter 2 Quick Stats Chapter 2 Quick Stats Status Field Status Field Status Field The most viewed section of the interface is the Port Statistics field. It's important to know the The most viewed section of the interface is the Port Statistics field. It's important to know the The most viewed section of the interface is the Port Statistics field.
Page 11: Chapter 3 Gui Configuration Options
Chapter 3 GUI Configuration Options Chapter 3 GUI Configuration Options Chapter 3 GUI Configuration Options System Configuration: System Configuration: System Configuration: （1）Basic information page （1）Basic information page （1）Basic information page Within the System Configuration folder is the Basic Information option which shows the detail about Within the System Configuration folder is the Basic Information option which shows the detail about Within the System Configuration folder is the Basic Information option which shows the detail about the installed product.
Page 12 The ICCN WP6000 series enterprise switches support multi-user access to the system; however, it The ICCN WP6000 series enterprise switches support multi-user access to the system; however, it The ICCN WP6000 series enterprise switches support multi-user access to the system; however, it is not enabled by default.
Page 13 IP ACL grouping ,and the implementation of the source IP address control, control access to the host of these services. By default, the WP6000 series telnet, GUI, and SNMP services are to the host of these services. By default, the WP6000 series telnet, GUI, and SNMP services are to the host of these services.
Page 14 This file can be used as a back-up or to duplicate to other WP6000 series switches. The WP6000 series will always keep the factory default settings within WP6000 series switches. The WP6000 series will always keep the factory default settings within WP6000 series switches.
Page 15 System reset page System reset page System reset page （8）（8）（8） The System Reset page can be used to restart the switch by simply clicking the Reset button. When The System Reset page can be used to restart the switch by simply clicking the Reset button. When The System Reset page can be used to restart the switch by simply clicking the Reset button.
Page 16: Port Configuration
The Common Configuration (port config.) page provides at-a-glance details about each port of the The Common Configuration (port config.) page provides at-a-glance details about each port of the WP6000 series switch. The port configuration page provides port controls including WP6000 series switch. The port configuration page provides port controls including WP6000 series switch.
Page 17 （3）Flow control page （3）Flow control page （3）Flow control page Flow Control information is provided as a quick view for all ports or on a per port basis. Users can Flow Control information is provided as a quick view for all ports or on a per port basis. Users can Flow Control information is provided as a quick view for all ports or on a per port basis.
Page 18 （5）Port Rate Limit （5）Port Rate Limit （5）Port Rate Limit Port Rate Limiting section is used to specify the rate at which IP data is sent and received. This is Port Rate Limiting section is used to specify the rate at which IP data is sent and received. This is Port Rate Limiting section is used to specify the rate at which IP data is sent and received.
Page 19 （7）Port Learning restrain page The WP6000 series enterprise switches are able to learn some or all of a MAC Address details. Port The WP6000 series enterprise switches are able to learn some or all of a MAC Address details. Port The WP6000 series enterprise switches are able to learn some or all of a MAC Address details.
Page 20 '0001' or '1.' WP6000 series can trunk based on source mac, destination mac, source and destination mac, source ip, destination WP6000 series can trunk based on source mac, destination mac, source and destination mac, source ip, destination...
Page 21 Once the trunk method is confirmed, the user MUST click 'Create Trunk Group' to create the trunk. A port Once the trunk method is confirmed, the user MUST click 'Create Trunk Group' to create the trunk. A port Once the trunk method is confirmed, the user MUST click 'Create Trunk Group' to create the trunk. A port cannot be added until a trunk group is created.
Page 22 IP traffic for complete monitoring. There are four (4) steps to setting up port mirroring on the WP6000 series switches. They There are four (4) steps to setting up port mirroring on the WP6000 series switches. They There are four (4) steps to setting up port mirroring on the WP6000 series switches.
Page 23 It is important to note that there are multiple options for Mirror Direction as the image below shows. It is important to note that there are multiple options for Mirror Direction as the image below shows. It is important to note that there are multiple options for Mirror Direction as the image below shows. The options allow users to customize how they obtain information via the mirror port.
Page 24: Mac Binding
MAC binding MAC binding MAC binding （1）MAC binding configuration page （1）MAC binding configuration page （1）MAC binding configuration page MAC binding configuration allows the user to reserve static IP assignments for a client. The WP6000 MAC binding configuration allows the user to reserve static IP assignments for a client. The WP6000 MAC binding configuration allows the user to reserve static IP assignments for a client.
Page 25: Mac Filtering
MAC filtering MAC filtering MAC filtering （1）MAC filtering configuration page （1）MAC filtering configuration page （1）MAC filtering configuration page MAC filtering allows network administrators to limit access to the network by enabling or not enabling MAC filtering allows network administrators to limit access to the network by enabling or not enabling MAC filtering allows network administrators to limit access to the network by enabling or not enabling specific MAC addresses.
Page 26: Vlan Configuration
The WP6000 series VLAN Information GUI provides an overview of current VLAN configurations and The WP6000 series VLAN Information GUI provides an overview of current VLAN configurations and The WP6000 series VLAN Information GUI provides an overview of current VLAN configurations and status.
Page 27 IP data traffic. The WP6000 series of enterprise switches support up to 4096 VLANs enabling a users to build large The WP6000 series of enterprise switches support up to 4096 VLANs enabling a users to build large The WP6000 series of enterprise switches support up to 4096 VLANs enabling a users to build large network segments.
Page 28 （3）VLAN port configuration page （3）VLAN port configuration page （3）VLAN port configuration page The VLAN Port Configuration page is used to configure VLAN ports, display general results, The VLAN Port Configuration page is used to configure VLAN ports, display general results, The VLAN Port Configuration page is used to configure VLAN ports, display general results, and help define the mode of each VLAN.
Page 29 Mode Section (con't) Mode Section (con't) Mode Section (con't) Ports can now be associated to a VLAN and provided different parameters based on requirements. Ports can now be associated to a VLAN and provided different parameters based on requirements. Ports can now be associated to a VLAN and provided different parameters based on requirements. By selecting a specific port in the 'Port' dropdown menu, the user is able to show the different VLAN By selecting a specific port in the 'Port' dropdown menu, the user is able to show the different VLAN By selecting a specific port in the 'Port' dropdown menu, the user is able to show the different VLAN...
Page 30: Snmp Configuration
By default, all WP6000 series switches share a Community Name called 'public.' The default Read/Write is By default, all WP6000 series switches share a Community Name called 'public.' The default Read/Write is By default, all WP6000 series switches share a Community Name called 'public.' The default Read/Write is...
Page 31 TRAPs enable network managers to be notified of events without having to check the device interface. The WP6000 series enterprise switch TRAP targets allow management check the device interface. The WP6000 series enterprise switch TRAP targets allow management check the device interface.
Page 32 ACLs can be configured based on a number of different user device parameters. WP6000 series all ACL configuration by: based on a number of different user device parameters. WP6000 series all ACL configuration by: based on a number of different user device parameters.
Page 33 （3）MAC IP ACL configuration page （3）MAC IP ACL configuration page （3）MAC IP ACL configuration page Figure 37 is the MAC IP ACL configuration page Figure 37 is the MAC IP ACL configuration page Figure 37 is the MAC IP ACL configuration page An IP MAC group can be the IP packet source and destination MAC address and source and An IP MAC group can be the IP packet source and destination MAC address and source and An IP MAC group can be the IP packet source and destination MAC address and source and...
Page 34 （4）MAC ARP ACL configuration page （4）MAC ARP ACL configuration page （4）MAC ARP ACL configuration page Figure 39 is the MAC ARP ACL configuration page. Figure 39 is the MAC ARP ACL configuration page. Figure 39 is the MAC ARP ACL configuration page. TheARP group can be the type of the operation of the ARP packet, the sender MAC and TheARP group can be the type of the operation of the ARP packet, the sender MAC and TheARP group can be the type of the operation of the ARP packet, the sender MAC and...
Page 35 （6）ACL Reference page （6）ACL Reference page （6）ACL Reference page 10. QoS Configuration 10. QoS Configuration 10. QoS Configuration （1）QoS Apply Configuration Page （1）QoS Apply Configuration Page （1）QoS Apply Configuration Page Figure 41 is the QoS Apply configuration page. Figure 41 is the QoS Apply configuration page. Figure 41 is the QoS Apply configuration page.
Page 36 （2）QoS Schedule Configuration Page （2）QoS Schedule Configuration Page （2）QoS Schedule Configuration Page Figure 42 is a QoS Schedule configuration page. Figure 42 is a QoS Schedule configuration page. Figure 42 is a QoS Schedule configuration page. 1. First select the Port in the Port dropdown menu 1.
Page 37 （2）ARP configuration and display page （2）ARP configuration and display page （2）ARP configuration and display page Figure 44 is the ARP configuration and display page. This page shows the ARP table details Figure 44 is the ARP configuration and display page. This page shows the ARP table details Figure 44 is the ARP configuration and display page.
Page 38 Figure 45 the host static route configuration page Figure 45 the host static route configuration page Figure 45 the host static route configuration page ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide...
Page 39 You can also set Radius roaming to be on or Figure 46 the Radius configuration page Figure 46 the Radius configuration page Figure 46 the Radius configuration page ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide...
Page 40 Figure 47 the 802.1x configuration page Figure 47 the 802.1x configuration page Figure 47 the 802.1x configuration page ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide...
Page 41 Doing 802.1x authentication, port access, the default maximum host number is 100. Doing 802.1x authentication, port access, the default maximum host number is 100. ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide...
Page 42 Figure 50 the PoE port configuration page Figure 50 the PoE port configuration page Figure 50 the PoE port configuration page ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide...
Page 43 Identity Description IEC60950-1 Product Safety En55022 Class A EMC/EMI En55024 Immunity EMC/EMI cTUVus 60950 Product Safety FCC part 15 Class A EMC/EMI Canada cTUVus 60950 Product Safety FCC part 15 Class A EMC/EMI ICC Networking WP6000 Series Web User Guide...
Page 44 BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), ICC SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE, LOSS OF PROFIT, LOSS OF BUSINESS, OR OTHER ICC Networking WP6000 Series Web User Guide...
Page 45 WARRANTY IS LIMITED TO THE PURCHASE PRICE OF THE PRODUCT COVERED BY THIS WARRANTY. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. ICC Networking WP6000 Series Web User Guide...
Page 46 International Communications Corporation ,Inc. All other trademarks are property of their respective owners. registered trademark of International Communications Corporation ,Inc. All other trademarks are property of their respective owners. ICC Networking WP6000 Series Web User Guide ICC Networking WP6000 Series Web User Guide...
