- Page 1 Instruction Manual Dehumidifier Please keep this instruction manual for future potential usage.
-
Page 2: Table Of Contents
Contents Please take some time to read this instruction manual and keep it for potential usage. Page Warnings----------------------------------------------------1 Specification------------------------------------------------2 Working principle------------------------------------------3 Working environment--------------------------------------4 Important Safety Measures--------------------------------5 Body of machine--------------------------------------------6 Operation Method-----------------------------------------7-9 Wi-Fi Instructions ---------------------------------------- 10-13 Drainage---------------------------------------------------- 14-15 Maintenance------------------------------------------------16 Storage------------------------------------------------------17 Problem shooting------------------------------------------18-19 Safety Instructions-----------------------------------------20-23 Appendix----------------------------------------------------24-30... -
Page 3: Warnings
Warnings This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 4: Specification
Specification Description Juro-Pro Perla II 25L WiFi Model Power 220-240V/50Hz Test Environment DB 30 C, RH 80% Dehumidifying Capacity 25 L/day *Power input/Amp 270W C, RH 60%) Compressor rotation Refrigerant R290 Working range 5 ~ 35 4.1 L Water tank capacity 160/200 m³/h... -
Page 5: Working Principle
Working Principle This product is multifunctional dehumidifier, which can be set humidity level according to your different requirements. Through to the machine’s settings, the damp air flows through the body of the evaporator and radiator, and then the relative humidity of the room could be controlled: the excessive moisture air flow through the evaporator, the air will condenses into water and then exhaust to the water tank, after that the dry air flow through the radiator to warm up and then back to the room. -
Page 6: Working Environment
Working environment This is a multi-functional dehumidifier, and you can set the room humidity according to your requirements. It could create a healthy and comfortable environment. The machine usually be used in basement, wine cellar, storage, and closet. It also could be used in kitchen, library, showroom, computer room, archives, living room and bedroom. -
Page 7: Important Safety Measures
Important Safety Measures 1. Keep the machine upright on the floor. 2. After be transported or tilted (caused by cleaning), the machine need to be stopped for an hour and then you can plugged it into power. 3. Make sure there’s 25CM distance around the machine. 4. -
Page 8: Body Of Machine
Body of machine 1． Handle for whole machine. 2． Control Panel 3． Air Outlet 4． Air Inlet 5． Frame of Filter 6． Drainage 7． Water Tank 8． Power wire 9． Handle of water tank 10． Caster... -
Page 9: Operation Method
Operation Method Operation Instruction ON/OFF 1. Connecting to the power (refer to nameplate sticker on the power requirements), press “ ” button to turn on the machine, then the power indicator lights. The display system shows the acquiescent setting models and corresponding indicators light. - Page 10 excluded). Starting timing, timing indicator lights. And when setting time out, machine will be turned on automatically. Humidity setting Acquiescent setting humidity of machine is RH55％, press “ ” button, displaying the current setting of humidity, press “ ” button again to set humidity at the range of RH40％～80％（5% for one level），CO is continuous.
- Page 11 When tank is full, alarm buzzing, corresponding indicator lights and machine stops working. Shift of air purification and dehumidification You can press the “ air purification mode or dehumidification ” to choose mode. When the purifying indicator light is on, it means the machine is working in the air purifying mode and the fan is running while the compressor stops.
-
Page 12: Wi-Fi Instructions
WIFI configuration After the WIFI connection is successful, the appliance can be remotely controlled by the mobile phone. As long as the mobile phone can access the Internet, no matter where you are, it is convenient to perform a series of settings on the machine, and the home humidity is under your control. - Page 13 4. The device powered After confirming that the machine is connected to the power supply, select the device with power on the APP interface and click Next. 5. Configure network Press the machine "on key" for more than 3 seconds until you hear a click, the power indicator flashes at a faster frequency, select the WiFi network to which the device is connected, enter the password, and click Next to configure the...
- Page 14 networking is also displayed on the APP. 7. Configure network success After the networking is successful, if it is in the power-on state, the power indicator light is on for one second and off for five seconds; if it is in power-off state, the power indicator is off.
- Page 15 Dismiss the network According to your actual situation, if you no longer need to control the machine through the mobile phone, you can forcibly release the binding between the machine and the APP and the network. The specific operation is as follows: long press the “wind speed”...
-
Page 16: Drainage
Drainage When water in tank is full, machine will alarm and stop working automatically, then indicator light turns red, remind3ing user pour out water in the tank: 1． Take bar of tank, pull out gently. 2. After pouring out water, bring tank back to original position. Then machine works again. - Page 17 Fault identification code 1. Coil temperature sensor failure: When the coil temperature sensor fault is detected, the compressor stops, the fan stops, the LED light goes out, the button is invalid, and the humidity display window displays “E1”. After the coil temperature sensor returns to normal, the machine works normally.
-
Page 18: Maintenance
Maintenance Pull off power plug from socket before maintaining or washing. Cleaning 1. Clean machine by soft cloth 2. Do not clean machine by volatile chemicals, gasoline, detergent chemical processed cloth or other cleaning solution, which may be harmful to machine. -
Page 19: Storage
Storage When machine does not run for long time, please do as follows: 1. Turn off machine, cut off power and sort out power cord. 2. Pour out tank water and wipe it. 3. Clean the filter. 4. Cover up machine and place it in one position unexposed to sun... -
Page 20: Problem Shooting
Problem shooting Before calling for service, please make following check： Problems Possible causes Whether plug in the power? Machine does not work Whether electrical wires indoor in the power? Whether full water indicator is lit? （If lit, water tank is possibly full of water or not placed in correct position）... - Page 21 Problem shooting The following symptoms are not failure: Symptoms causes Noise gets bigger when machine When compressor starts, noise of starts compressing gets bigger. Machine will pump out musty Temperature of heat exchanger taste in first use rises suddenly, leading temporary strange smell or musty taste.
-
Page 22: Safety Instructions
Safety Instructions Warning Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater.) ... - Page 23 The maximum dosage of refrigerant is 65g Notes: The dehumidifier is only suitable for indoor use, and is not suitable for other applications. Place the machine in a flat and dry place and keep a distance of above 50cm between the machine and the surrounding objects or walls.
- Page 24 (Except for the humidifier with person responsible for their safety. CE-MARKING) Children should be supervised to ensure that they do not play with the appliance. (Except for the humidifier with CE-MARKING) The appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 25: Appendix
The fuse mode is 4T or 4F or 334 or L3CT, the specification is AC250V, 3.15A Appliance is filled with flammable gas R290, and the maximum charge of refrigerant is 65g. GWP value of R290refrigerant is 3. Any repairs you need, contact the nearest authorized Service Centre and strictly follow manufacturer’s instruction only APPENDIX... - Page 26 1. Information on servicing 1) Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimized. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
- Page 27 be displayed. 7) Ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
- Page 28 That capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking. That there no live electrical components and wiring are exposed while charging, recovering or purging the system. That there is continuity of earth bonding. 2.
- Page 29 vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans. 5. Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks.
- Page 30 Evacuate. Purge again with inert gas. Open the circuit by cutting or brazing. The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall be “flushed” with OFN to render the unit safe. This process may need to be repeated several times.
- Page 31 reclaimed refrigerant. It is essential that electrical power is available before the task is commenced. Become familiar with the equipment and its operation. Isolate system electrically. Before attempting the procedure ensure that: Mechanical handling equipment is available, if required, for handling refrigerant cylinders.
- Page 32 for the recovered refrigerant and labeled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete with pressure relief valve and associated shut-off valves in good working order. Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs. The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants.
