- Page 2 TABLE OF CONTENTS Introduction ..................... 1 Safety Information ................... 3 Generator Safety Warnings ................4 Know Your Pressure Washer................7 Starting Preparation ..................12 Starting the Generator ...................16 Shutting Off the Pressure Washer ..............18 Maintenance ....................19 Transportation & Storage ................24 Troubleshooting Guide ..................25 Warranty Statement ..................29...
- Page 4 For any queries on the above, please contact Gentech Industries, the official service agent for all MAXWATT pressure washers, water pumps and pressure washers. The range of MAXWATT products is safe and reliable, but incorrect usage of these products may cause personal injury and damage to the machine.
- Page 5 BEFORE STARTING UNPACKING AND DELIVERY INSPECTION You should inspect the pressure washer immediately after you receive delivery thereof. If you have any missing parts, please contact your place of purchase. DO NOT attempt to operate the pressure washer if there are any missing parts. The pressure washer is shipped without oil.
- Page 6 All fuels are flammable. Never fuel a running or hot engine. Never pump fuel directly into the engine at a petrol station – use an approved container to transfer the fuel. Ensure that there are no fuel leaks and keep sources of sparks and flames away. Wait for the engine to be cool before fuelling. ALWAYS keep a fire extinguisher rated “ABC”...
- Page 7 Use personal protection equipment. Always wear eye protection. Wear approved safety impact eye goggles, dust mask, non-skid safety shoes, hard hat and hearing protection for appropriate conditions. DO NOT overreach. Keep proper footing and balance at all times. This enables better control of the pressure washer in unexpected situations.
- Page 8 4. Receptacle damage; 5. Pressure washer misfire; 6. Excessive vibration; 7. Flame or smoke or 8. Abnormal noise This product contains or emits chemical known to the Commonwealth of Australia to cause cancer, birth defects or other reproductive harm. Avoid inhalation of exhaust. DO NOT operate the engine or handle any electrical equipment while standing in water, while barefoot, while hands are wet or while in the rain or snow.
- Page 9 Use a portable container to fill the tank. NEVER fill the engine’s petrol tank directly from the fuel pump – the engine’s tank is not grounded and the high velocity flow of petrol from a fuel pump can cause static electric build-up.
- Page 10 Poisonous fumes from its exhaust. Always make sure there is adequate ventilation when operating this equipment. EXPLOSIVE HAZARD: Fuel and its vapours are extremely flammable and explosive. Fire or explosion from these vapours can cause severe burns or even death. ROTATING PARTS: Starter and other rotating parts on this tool can entangle Loose clothing, long hair and accessories resulting in moderate to severe injury.
- Page 11 UNPACKING AND INSPECTION After opening the carton, unpack your new pressure washer and related parts and accessories. Please inspect it carefully for any damage that may have occurred during transit. If any parts are missing, please contact Gentech Industries. Check to see that all nuts, bolts and fittings are secure before putting this pressure washer into service. If you have any questions, or require assistance with damaged or missing parts, please do contact Gentech Industries.
- Page 12 Use the right tool. Use tools properly and for their intended use/task. Do not force a small tool to do the job of a heavy-duty tool. Using the right tool to do the right job will make doing the job easier and safer.
- Page 13 SYMPTOMS OF CARBON MONOXIDE POISONING Carbon monoxide (CO) is a product of incomplete combustion of fuels and occurs in exhaust fumes of fuel-burning heaters and all internal combustion engines. It collects in spaces where there is no constant air flow or ventilation. If you or anyone near you starts to feel sick, dizzy or weak due to exposure to CO while using the engine, GET FRESH AIR IMMEDIATELY.
- Page 14 Do not make contact with the muffler area while the engine is running. The muffler gets extremely hot and can cause severe burns. Exhaust gases can ignite combustible items such as clothing or structures in close proximity. Gases leaking from a worn muffler can heat up and damage the fuel tank resulting in a fire and/or explosion.
- Page 15 The wheel kit is not designed for over-the-road use. The pressure washer must be transported in a vehicle or on a trailer. The unit is heavy. Take care when lifting or moving the unit. Transport or repair with the fuel tank EMPTY to prevent an unintentional spark Igniting fuel vapours resulting in a fire and/or explosion.
- Page 16 RISK OF INJURY: The pressure washer produces fluid pressures and velocities high enough to penetrate human and animal flesh which could result in serious injury and/or amputation. Ensure all connections are tightened securely. Inspect all hoses to ensure they are not damaged or kinked.
- Page 17 The pressure washer must be run with the rubber feet resting on a flat and stable horizontal surface. The pressure washer must be used in a clean and well-ventilated area. Keep the pressure washer a minimum of 5 feet (1.5m) clearance on all sides including overhead. DO NOT place the pressure washer in an area: ...
- Page 18 Pull the handle lock pin and fully raise the handle upright. Release and snap the lock pin into its locking hole in the frame. Assemble the top and bottom gun holders (using the nuts and bolts) to the fame as shown. Tighten all mounting hardware.
- Page 19 SELECTING THE RIGHT NOZZLE FOR THE JOB The pressure washer comes furnished with five spray nozzles. Each nozzle is colour coded and delivers a specific spray pattern and pressure for a particular cleaning job. The size of the nozzle determines the size of the fan spray and the pressure out of the nozzle.
- Page 20 PREPARING THE PRESSURE WASHER PRESSURE PUMP The pressure washer is shipped with shipping oil plug to prevent oil leakage from the pump during shipping. To replace the shipping plug with the breather plug (provided), perform the following: Using a wrench, remove shipping plug from pressure pump. Discard shipping plug. ...
- Page 21 ADDING FUEL Move the pressure washer outside and place it on a flat and level surface. Remove the gas tank cap. Carefully add 87 octane (or higher) grade gasoline to the tank. DO NOT overfill. Leave room for the gasoline to expand. ...
- Page 22 Place the pressure washer on a flat and level surface and close to the working surface. Keep a minimum of 5 feet (1.5 meters) clearance on all sides of the engine including the top. Face the engine exhaust outlet away from dwellings. ...
- Page 23 Release the trigger to stop water flow. WASHING / CLEANING Firmly grip the spray gun with both hands. Point the nozzle to a safe direction and squeeze the spray gun trigger to allow the pump to purge air and impurities in the system and then redirect the nozzle to the working surface. ...
- Page 24 Lock the trigger and attach the detergent nozzle (black) to the wand. Unlock the trigger and squeeze the spray gun trigger and apply detergent to a dry surface, starting at a lower portion of area to be washed and work upwards, using long, even and overlapping strokes.
- Page 25 NEVER turn off the water supply with the engine running. This will cause the pressure pump to overheat and this will result in internal damage. The pressure washer MUST be properly stored. Refer to the next pages for proper storage instructions. MAINTENANCE Regular maintenance will improve performance and extend the life of the pressure washer.
- Page 26 Remove dipstick/oil plug from the crankcase and wipe clean. Oil level is correct if it covers the lower half of the dipstick. CHANGING THE PRESSURE PUMP OIL Place the container under the pressure pump oil drain plug. ...
- Page 27 Use a damp cloth to wipe the exterior surfaces clean. Use a soft bristle to loosen caked-on dirt or oil. Use a shop-vacuum to pick up any loose dirt and debris. STORAGE Fuel and fuel vapour are extremely flammable and explosive. Fire or explosion from misuse of fuel can cause severe burns or even death.
- Page 28 IT IS RECOMMENDED that you follow these steps to protect the internal seals of the pressure washer when storing the unit for more than 30 days and/or when freezing temperatures are expected: Obtain a funnel, six ounces of RV anti-freeze and approximately 36 inches of garden hose with a male hose connector on one end.
- Page 29 TROUBLE SHOOTING GUIDE:...
- Page 34 SPECIFICATIONS:...
- Page 35 “This is a “walk in” warranty policy and is limited to the range of pressure washers specified herein”. We recommend that you take the pressure washer to the nearest service agent for assistance. Please visit www.maxwatt.com.au for more information. To qualify for this warranty: “The warranty applies to the first purchaser and each subsequent owner during the applicable...
- Page 36 WARRANTY PROCEDURES: Take the pressure washer and your proof of purchase either to the store where purchased, or to the nearest accredited service agent. Please visit www.maxwatt.com.au for more information on where to find a list of accredited service agents.
- Page 37 Consumable parts including but not limited to keys, spark plugs, fuel and oil filters, recoil starter ropes, wheels, lubricants, oil grease and fuel. Cleaning adjustments and normal periodic maintenance work including but not limited to cleaning of the battery, carburettor, engine oil, fuel tank and injectors. Over loading resulting in the damage of the AVR, circuit breaker, stator and rotor.
- Page 38 NOT AS ADVERTSIED /INCORRECT ITEM If your order arrives and it’s not what you ordered, please contact either the store the order came from or on the online support team at customercare@maxwatt.com.au. FAULTY PRODUCT Please contact the store that fulfilled your order. Store contact details can be found on your order confirmation email.
