- Page 1 Let’s build a Wallbed together! www.murphywallbedsystems.com Universal Desk/Table for All Sizes of Alpha Panel Wall Beds Assembly Instructions ** LIFETIME WARRANTY ** Designed to Exceed International ISO 9002 Standards for Residential Specifications - Patent Pending - Issue:041414...
- Page 2 Exploded Assembly Hinges and Hinge Clips to Back and Bed Face Panel (3pc) 2”x3”Black Hinge (3pc) Hinge Clips (27pcs) Flat Head Self tapping Screw#5x16mm INSERT 16mm DESK LEG PACKER TO BE FIXED BETWEEN LEG PIVIOT BRACKET & WALLBED END PANEL USING 28MM WOOD SCREWS (10pc) #8x40mm Wood Screws...
- Page 3 Pre Assembled KIT (2pc) M8x16mm Bolt Upper Bracket (2pc) Black Steel Washer Ø8.5xØ20mm (Left and Right) Legs to Upper Brackets Washers stop friction between Legs, Upper and Lower Brackets (4pc) Black Nylon Washer Ø13xØ30mm Leg (2) Pivot Bracket (Left and Right) Legs to Pivot Brackets (2pc) M6x40mm Bolt (4pcs) Black Steel Washer Ø7.0xØ16.0mm...
- Page 4 Steps to Complete the Project NOTE: If the Panel Bed is slightly too heavy too open and close without the Studio Desk/Table mounted, you should add one Spring to the right and to the left to assist in balance. An odd number of Springs right and left may be used to get balance.
- Page 5 Drawing #1: Upper Bracket Back Desk/Table Top Drawing #2: Hinges to Back The short Hinge leaf attaches to the Back, the long Hinge leaf attaches to the Bed Face Back Back...
- Page 6 STEP 2: Install Pivot Brackets and Desk Leg Packers Install the left and right Pivot Brackets as shown in Drawing #3. Insert Desk Packers between pivot bracket and end panel of the cabintery. This will square up the legs with the cabintery. Mount the Brackets exactly 25mm inside of the Cabinet vertical.
- Page 7 Clips to ensure that the desk will be level. Secure all three Hinge Clips. See Drawing #5. Bring the Studio Desk/Table back up to the Bed Face and place the long Hinge leaves in the Hinge Clips .
