- Page 1 TV WAll Mount Instruction Manual V1.0 Model: EBLTK4 Thank you for choosing this product! We strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact at JKO2YU@outlook.com (US/CA)
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Please carefully read all instructions before attempting installation. If you do not understand the instructions or have any concerns or questions, please contact our customer service at JKO2YU@outlook.com. CAUTION: Avoid potential personal injuries and property damage! • Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Supplied Parts
Tools Needed (Not lncluded) Stud Finder Tape Measure Pencil Drill Hammer 5/32 in.(4 mm) 3/8 in.(10mm) 3/8in.(10mm) Phillips 5/16 in.(8 mm) Wood Drill Concrete Drill Socket Wrench Screwdriver Wrench Supplied Parts Wall Plate Extender Wall Plate Bracket Level Bracket... -
Page 4: Supplied Hardware
Supplied Hardware Hardware for Attaching TV Brackets to TV Spacer Washer [If necessary] [If necessary] M4/M6 10mm [M-H] [M-J] [M-I] TV Bolt [M-A] [M-B] M4 x 12mm x4 M4 x 30mm x4 [M-C] [M-D] M6 x 15mm x4 M6 x 30mm x4 [M-E] [M-F] [M-G]... - Page 5 Step 1 Select TV Bolts Only one bolt size fits your TV. Step 2 Select Spacers (if needed) Note: If necessary, the spacers can be used in multi-layer. If the installation fails after trying various methods, please contact customer service at JKO2YU@outlook.com NO SPACER SPACER...
- Page 6 Step 3 Secure the TV Brackets to Your TV No Spacer With Spacer Alternate Spacer Setups Step 4 Assemble Wall Plate(optional) Option A: 16 in. (406mm) stud spacing VESA Pattern of TV: 100X100-400X400mm Option B: 18-24 in. (457mm-610mm) stud spacing VESA Pattern of TV: 100X100-600X400mm DO NOT overtighten.
- Page 7 Step 5 Attach the Wall Plate [01] or [01 and 02] to Wall For wood stud installation, follow STEP 5A For concrete installation, follow STEP 5B Step 5A Wood Stud Option WARNING: ● Avoid potential personal injury or property damage! DO NOT over-tighten the lag screws [A].
- Page 8 2 in.(55 mm) 5A-3 5/32 in.(ø4 mm) Drill 4 pilot holes using a 5/32 in.(4 mm) diameter drill bit. Make sure the depth is not less than 2 in.(55 mm). 5A-4 Install the wall plate [01] or [01 and 02] using lag screws [A]. Tighten the lag screws [A] only until they are pulled firmly against the wall plate.
- Page 9 5B-1 Position the wall plate [01] or [01 and 02] at your desired height, level the wall plate and mark the pilot hole locations. 5B-2 Drill 4 pilot holes using a 3/8 in.(10 mm) diameter drill bit. Make sure the depth is not less than 2.4 in.(60 mm).
- Page 10 Step 6 Adjust the Tilt Angle of TV 5/16 in.(8mm) Wrench Tighten Loosen Loosen the 4 tilt bolts [S] on both brackets, adjust the hooks of the bracket to the desired angle, then tighten tilt tension nuts using a wrench (not included) and the titlt bolts using a phillips screwdriver (not included) to fix the tilting angle of TV.
- Page 11 Step 8 Secure TV Press Locking Pull down and hold both cords [R], press the bottom of the TV into the wall plate [01] or [01 and 02] until the latches lock the TV in place. Remove the TV Step 9 HEAVY! You may need assistance with this step.
- Page 12 Thank you again choosing this product! All of us do appreciate your product purchase. We hope that you are as happy with your product as we designing and manufacturing it for you. We strive to provide you with the best quality products and services in the industry. If you have any JKO2YU@outlook.com (US/CA) questions please don't hesitate to contact us at...
