- Page 1 CX SERIES CX SERIES High Performance High Performance Full-Range Full-Range Co-Axial SpeakerS Co-Axial SpeakerS CX65.4 / CX65.2 CX65.4 / CX65.2 CX69.4 / CX69.2 CX69.4 / CX69.2...
-
Page 2: Power Handling
Cicada Audio recommends our products be professionally installed by an authorized Cicada Audio dealer to achieve the test possible system recommendation and installation. This will ensure a true Cicada Audio listening experience and sound you would expect from Cicada Audio products. In doing this you will extend your warranty from one year to two years. - Page 3 Sensitivity (1W/1M) 89dB 91.5dB Sensitivity (2.83V/1M) 94dB 95.5dB Xmax - inch 0.16 0.16 (mm) 4.6” 5.71” X 8.5” Mounting Diameter (117mm) (145.13mm X 217.13mm) 2.18” 2.65” Mounting Depth (55.4mm) (67.5mm) Grill / Trim Ring 2020 Cicada Audio All rights reserved.
-
Page 4: Installation
6. Tighten the screws until the speaker is snug in place to prevent warping the frame. Also make sure that the screws are tighten all the way around and there are no air leaks visible as this will cause serious performance issues 2020 Cicada Audio All rights reserved. -
Page 5: Speaker Mounting
SPEAKER MOUNTING CUT-OUT PHIILIPS HEAD STAINLESS STEEL SCREWS SPEAKER 2020 Cicada Audio All rights reserved. - Page 6 “POD”. Remove the push on terminals and remember which is Positive (+) and which is negative (-) PUSH-ON 0.187 SPADE STOCK HD SPEAKER PULL OUT Take your new Cicada Audio speaker and slide the wire connectors over the terminals PUSH ON CICADA CX65 2020 Cicada Audio All rights reserved.
- Page 7 1 / 2 f u e l After installing the speaker to the pod, there are alignment pins on the pod that the speaker needs to line up to ensure proper fit. 5 0 6 0 2020 Cicada Audio All rights reserved.
-
Page 8: Physical Dimensions
0.177 / 4.5mm 6.5” / 165mm 0.75” / 19.1mm CX69.4 / CX69.2 6.41” / 163.0mm 0.175” / 4.46mm 4.72” / 120.0mm 2.55” / 64.8mm 2.65” / 67.5mm 5.71” / 145.13mm 0.75” / 19.1mm 3.08” / 78.46mm 2020 Cicada Audio All rights reserved. - Page 9 LIMITED SPEAKER WARRANTY STATEMENT Cicada Audio warrants this product to be free of defects and quality workmanship for a period of one (1) year from the original date of purchase. A receipt from an authorized Cicada Audio dealer is required for warranty claim.
