Summary of Contents for Havospark Orca H9
- Page 1 Orca H9 The Lifesaving Watercraft HOVERSTAR FLIGHT TECHNOLOGY CO.,LTD. Room 203/205, Bantian Group Building, 8 Shibei Road, Longgang District, Shenzhen City, Guangdong Province, China User Manual +86-755-33138076 info@hoverstar.com www.havospark.com Version 1.0...
-
Page 2: Table Of Contents
It is adaptive to swift water and also narrow, flooded areas in inner cities. The Havospark Orca H9 is a powerful, fast and easy to use hi-tech equipment for emergency water rescues. -
Page 3: Cockpit Controls Diagram And Operation
When the power is off, hold both buttons (B-LEFT and B-RIGHT) for 3 seconds until the LED display screen shows a signal such as in Figure 4, which indicates the Orca H9 is starting up, as the screen says INITIALIZING (as shown in Figure 5) -
Page 4: Battery Level Warning
Choose the desired depth level and press Press B-LEFT & B-RIGHT to scroll through B-Right to confirm. To exit, press B-Left. the text. The settings are completed by now. Press T-RIGHT to accept and proceed to home screen. - The higher the power level limit, the faster the speed. -
Page 5: Faults Handling
POWER MANAGEMENT SYSTEM Figure 20 MOTOR TEMPERATURE CRITICAL the Orca H9 is equipped with a power management system to prevent accidentally running Usually caused by excess loading or partial out of battery charge during use: jet-blockage. Turn off immediately & allow to •... -
Page 6: Care & Maintenance
20. Never drop or throw the Orca H9 into water from a height greater than 50cm or jump from Only suitable for confident swimmers over 16 years of age who are fit and healthy. If you elevated location holding the Orca H9. -
Page 7: Charger Information
C H A R G I N G P R O F I L E S 100% Connect the male connector on the lead to the female connector on the the Orca H9 unit. Switch on the charger. When batteries are fully charged (standard charger full charge = approximately 6 hours &... -
Page 8: Operation Of The Orca H9
D. Adjust your position so the Orca H9 will run true and horizontal on the water’s surface. Default depth limit = 2m E. Diving with the Orca H9 requires little effort by pushing the nose down, it will run horizontal at Default power limit = 3 all depths without much effort.
