Compcooler COMP-RDCS-12200-BS Operation Manual

Racing driver cooling system basic model
Hide thumbs

Advertisement

Quick Links

Download this manual
Racing Driver Cooling System
Basic Model
Model: COMP-RDCS-12200-BS
Rev. A
Operation Manual
Designed for Racing Drivers to Combat Heat in Extreme Hot Conditions!
Keeping body ready cool, extend endurance, reduce lap times.
Compcooler, keep your body cool and comfortable in harsh conditions.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the COMP-RDCS-12200-BS and is the answer not in the manual?

Questions and answers

Related Manuals for Compcooler COMP-RDCS-12200-BS

Summary of Contents for Compcooler COMP-RDCS-12200-BS

  • Page 1 Racing Driver Cooling System Basic Model Model: COMP-RDCS-12200-BS Rev. A Operation Manual Designed for Racing Drivers to Combat Heat in Extreme Hot Conditions! Keeping body ready cool, extend endurance, reduce lap times. Compcooler, keep your body cool and comfortable in harsh conditions.
  • Page 2 COMPCOOLER Introduction: Compcooler Technology specializes in working for personal cooling & heating systems for harsh conditions. Compcooler has established its resume as a manufacturer for Military, Electronic, Medical cooling equipment. The employees at Compcooler’s state of the art manufacturing facility have been producing liquid heating &...
  • Page 3 Model: COMP-RDCS-12200-BS Description: Compcooler Racing Driver Cooling System (RDCS) is a rugged vehicle-based refrigeration cooling unit and specially designed for Racing drivers body cooling in the extreme hot ambient. Maintain energy, extend endurance, ensure focus, to reduce lap times for driver ultimately.

  • Page 4: Key Features

    Unit only need one side ventilated for installation, could be installed at corner or confined space, Vehicle Power Operation Chiller unit operated by Vehicle power 12V DC, or Compcooler 12V 20A rechargeable battery. Compcooler, keep your body cool and comfortable in harsh conditions.
  • Page 5 5 pins Aero Controller Connector connector ℃ Operation Ambient ℉ Storage Temp -20 to 70 ℃ Noise Color Black and silver 356x200x217 Dimension L x W x H INCH 14x7.9x8.5 Weight Compcooler, keep your body cool and comfortable in harsh conditions.
  • Page 6 Stretch rate: 10% Cooling channel: Silicon 3x5mmCooling Zones: Four zones Manifold fitting: Aluminum one 1/4” to four 1/8” Connector: 1/4” quick fitting Dry weight: 0.5kg Size: XS/S, M/L, XL/2XL, 3XL/4XL Compcooler, keep your body cool and comfortable in harsh conditions.
  • Page 7 Compressor Speed: 4500rpm Ambient 30℃ Ambient 40℃ Ambient 50℃ Ambient 60℃ Coolant Temperature (℃) Power Consumption Curves (Compressor Speed) Power Consumption Curves 2000 3000 4000 5000 6000 Compressor Speed RPM Ambient Temp. Compcooler, keep your body cool and comfortable in harsh conditions.

  • Page 8: Operation Processes

    One power cord was provided with chiller, it is for 12V DC ONLY, voltage range 11V to 16V. User may connect it with 12V vehicle power. DO NOT plug the chiller with AC input! Compcooler, keep your body cool and comfortable in harsh conditions.
  • Page 9 User may remove or replace the controller from chiller unit by disconnect or connect 5 pins aero connector. Cooling Garment Connection User may connect the chiller with Compcooler Cooling Vest by quick release fitting. Or user may remove the quick fitting from extension hose and replace the new fittings to compatible with other cooling garment.
  • Page 10 User may press the pump to start or stop circulation. Please make sure the tubing is connected (no kinks) before circulation. Chiller Auto Control: Chiller Stop: Liquid temperature 3℃ (6℉) lower than setting Chiller Restart: Liquid temperature 1℃ (2℉) higher than setting Compcooler, keep your body cool and comfortable in harsh conditions.

  • Page 11: Clean And Maintenance

    Restart: after long term storage, please fill in clean water with less degerming agent, run system over 10 minutes with cooling vest connection. Then empty the system and re-fill in the liquid as need. Compcooler, keep your body cool and comfortable in harsh conditions.
  • Page 12 6. Please use anti-freeze liquid if temperature setting lower than 0℃ 7. Please use Compcooler battery only to run the chiller unit. 8. Please do not run the system close to fire or under water.
  • Page 13 Connection loose Remote controller can’t operate Controller LED vague or Check the unit input voltage twinkle No feedback, P1 on the Check if the connection loose or 5 Temp sensor panel Compcooler, keep your body cool and comfortable in harsh conditions.

  • Page 14: Warranty

    Compcooler agrees to correct for the original user of this product, either by repair, or at the manufacturer’s election by replacement. This warranty shall not apply if the defect or malfunction was caused by accident, neglect, unreasonable use, improper service, or other causes not arising out of defects in material or workmanship.
