- Page 1 Waistpack ICE Water Cooling System Model: COMP-BWCS-7415V Rev. B Operation Manual Compcooler Technology Jan. 2021 COMPCOOLER, PERSONAL THERMAL TECHNOLOGY...
- Page 2 COMPCOOLER Introduction: Compcooler Technology specializes in working for personal cooling & heating systems for harsh conditions. Compcooler has established its resume as a manufacturer for Military, Electronic, Medical cooling equipment. The employees at Compcooler’s state of the art manufacturing facility have been producing liquid heating &...
- Page 3 Reduction in heart rate, improve mental acuity Reduction in sweat rate, maintain physical performance COMPCOOLER Personal ICE Water Circulation Cooling System (PICS) PICS includes a liquid circulation unit and liquid cooling garment. Mini pump circulates the cold ICE water from bladder to micro-tubing cooling channel embedded on the liner of garment, it continuously flows around the body to reduce body core temperature and keep user at a comfortable cool range in hot conditions.
- Page 4 Model: COMP-BWCS-7415V Description: Compcooler Waistpack ICE Water Cooling System (WICS) is made up of waistpack, 1.5L detachable bladder, On/Off pump unit, battery and liquid cooling vest. Pump unit circulates cold water from bladder to cooling channel embedded on the vest liner, continuously flow around the body to reduce body core temperature, it keeps user at a comfort and safety range to against heat stress.
- Page 5 Fabric: Nylon Stretch Mesh Liner: Mesh Color: Black, Green, Blue Zipper: YKK Cooling Channel: Silicon Tubing Manifold: aluminum Connector: CPC male quick fittings Sides adjustable device: stretch Velcro Dry weight: 0.5kg Size: XS/S, M/L, XL/2XL, 3XL/4XL COMPCOOLER, PERSONAL THERMAL TECHNOLOGY...
- Page 6 Battery operation: 8 hours Noise: 45dBA Dry Weight: 1.5KGS Ambient Temperature: 0-65℃ Optional Components 1. Pump unit Flow control mode, 3 levels pump control Level I 200ml/min Level II 350ml/min Level III 500ml/min 2. Battery 7.4V 5A Rechargeable battery COMPCOOLER, PERSONAL THERMAL TECHNOLOGY...
- Page 7 Step II-After bladder is frozen, fill small amount circulation water into the roll top. Step III-Connect ICE bladder to cooling unit, Outlet and Inlet. Step IV-Start circulation with ON/OFF switch or Temp controller. COMPCOOLER, PERSONAL THERMAL TECHNOLOGY...
- Page 8 User may press On/Off switch to start cold water circulation or stop circulation. Please make sure vest be connected before circulation. 4. Extend cooling time User may replace the frozen bladder to extend cooling time. User may fill in ICE cubes for quick cooling operation. COMPCOOLER, PERSONAL THERMAL TECHNOLOGY...
- Page 9 3. Pump: user may purchase flow control pump unit to replace On/Off pump unit. 4. Cooling vest: user may purchase cooling T-shirt or cooling garment to replace the cooling vest, all Compcooler cooling garments are compatible with waistpack circulation unit.
- Page 10 Compcooler agrees to correct for the original user of this product, either by repair, or at the manufacturer’s election by replacement. This warranty shall not apply if the defect or malfunction was caused by accident, neglect, unreasonable use, improper service, or other causes not arising out of defects in material or workmanship.
