Summary of Contents for ASC Global IPCOM-4G
- Page 1 IPCOM-4G 2G/3G/4G/IP COMMUNICATOR INSTALLER AND USER’S GUIDE Version: 1.1...
-
Page 2: Table Of Contents
IPCOM-4G TABLE OF CONTENTS Introduction........................................ 3 System overview......................................3 Module buildup......................................4 Installation steps......................................5 LED Indicators......................................6 General recommendations..................................7 Programming......................................7 Programming with PC........................................7 Remote programming........................................9 Communication......................................9 AES Encryption..........................................10 Channel settings...................................... 10 Ethernet............................................10 Mobile data (GPRS/3G/4G).......................................10 SMS report..........................................10... -
Page 3: Introduction
SMS to one phone number, moreover, the module is capable of sending a message to the monitoring station as well. Also, we can link zones to the inputs. The IPCOM-4G is able to translate the contact ID codes, which were sent by the alarm panel, to SMSs. -
Page 4: Module Buildup
IPCOM-4G Module buildup Figure 1: the buildup of the module Figure 2: Series diagram wiring terminal Figure 3: SIM card inserting Page 4... -
Page 5: Installation Steps
Number identifying of caller and at call initiations has to be checked. This function at certain service providers must be enabled formerly. 5. The average mobile data usage of the IPCOM-4G communicator is estimated at 5-6 MB/month. This value can depend on the frequency of the test (keep-alive) signals. Please, use a SIM card with at least 5-10MB/month data plan. -
Page 6: Led Indicators
IPCOM-4G LED Indicators Signals give essential information of the module, of GSM signal strength and the actual error codes. By blinking we mean flashes between two longer pause. • LED-1 Power/Signal LED: In case of proper power supply, the LED-1 lights continuously, and... -
Page 7: General Recommendations
General recommendations The IPCOM-4G communicators can report to AMS servers via the Ethernet and/or GPRS/3G/4G network. A primary and secondary reporting channel for all communication media. Furthermore, SMS sending is available for notification purposes. - Page 8 IPCOM-4G The programming steps are as follow: 1. Connect the IPCOM-4G communicator to the PC with a mini-USB cable. 2. Start the Terminal, then in the file menu with the „open” button search and chose the IPCOMM.et device file.
-
Page 9: Remote Programming
IPCOM-4G When required options parameters have been set, these donwloaded to the device by clicking on Communication / Write. 8. The commonly used settings may be worth to save on the PC as a template for programming communicators. This can be done at File / Save menu. The previously saved settings can be reloaded later by using File / Open menu. -
Page 10: Aes Encryption
IPCOM-4G 1-2-3-4 Pass-Through mode This mode is very similar to the first one, but with an important difference. In this mode, the event received over telco interface will be acknowledged to the control panel after the event has been successfully reported to and acknowledged by the server. -
Page 11: Gprs Settings
I/O settings Input settings The IPCOM-4G has two I/O ports. In case we use it as an input, we can give the type of the input (NO/NC), the event code, and the restore code. Moreover, the input sensitivity can be modified between 10ms and 2550 ms. -
Page 12: Testing Ams Server Connection
IPCOM-4G connected to the telco interface of a security control panel, the following might be considered: Telephone communication should be enabled for the security control panel: • DTMF (Tone) dialing must be set • A telephone number must be set for reporting •... -
Page 13: Troubleshooting
IP address on the LAN. Check if router supports 10-Base T communications. SYMPTOM: the settings of IPCOM-4G seem to be ok, but no communication goes through to the AMS central. SOLUTION: Check the IP address and port settings for the AMS server. Check the APN settings. Turn off PIN request at the SIM card, using a mobile phone. -
Page 14: Sms Programming
1354 012 99 = Ethernet cable is not connected 1354 034 99 = SIM card not present 1354 999 99 = Comm Trouble between the IPCOM-4G and the control panel 1354 001 99 = Comm Failure on channel IP #1 (Ethernet) - Page 15 IPCOM-4G within 30 seconds. Sets the test code globally, or by The number of the test-code #1234* tc=1603 individual channels. Please, take channel care to program a valid Contact-ID code. The device will restart within 30 seconds. Can be used to control the on-...
-
Page 16: Technical Data
Inputs / Outputs 2 programmable Output type / rating OC / max. 50 mA Ethernet connection 10 Base-T IPCOM-4G: Quectel EG91 LTE FDD - B1/B3/B7/B8/B20/B28A X Mobile modem WCDMA - B1/B8 GPRS/EDGE - B3/B8 Antenna Event buffer Up to 64 events Operating temperature -10 °C / 50 °C...
