Touch Of ECO CAROLITE PRO Solar Candles Instructions

Advertisement

Available languages

Available languages

PACKAGE INCLUDES:

• Two Solar Window Candles
• Two Plastic Mounting Plates
• Four Suction Cups
• Pre-installed batteries
• Instructions

CONTROL SETTINGS:

The settings switch is located at the base of the candle. There are three settings: "OFF", "ON" and "FLICK." To control
each settings slide the switch up & down. To have lights turn on automatically each night leave in "ON" or "FLICK."
1) OFF - For "OFF" mode: the LED will not illuminate
2) ON - For "ON" mode: the LED will automatically illuminate at night (when light is not detected)
3) FLICK - For "FLICK" mode: the LED will automatically illuminate at night (when light is not detected)

IMPORTANT:

Please note that the light is designed to work in the dark. If there are strong light sources nearby then the LED may be very dim
or not work at all. Although the manufacturer has charged the battery, the charge levels will have dropped when you receive it.
Please charge the solar panel for a full day to optimize performance. To charge the solar panel, place the solar panel in direct
sunlight with the unit in the "ON" position. The surface of the solar panel must be kept clear, if not, this will influence the
efficiency of charging. Keep both the suction cups, as well as the inside and outside of the windows clean/clear at all times.

OPERATION:

Following the initial charge, move the setting switch to "ON" or "FLICK". Choose a window/location that receives at
least 6-8 hours of direct sunlight a day. The performance will be dependent on the amount of direct sunlight received.
1) Turn On - Switch toggle switch to "ON" or "FLICK"
2) Insert Suction Cups - Press/slide both suction cups into their holes on the top and bottom of mounting bracket
with suction cups facing out. Once inserted rotate the suction cups 90 degrees to lock in place.
3) Mounting to Window - Choose desired window location and make sure the window is clean. Dampen the suction
cups then press them onto the window for 5 seconds to make sure they stick.
4) Leave in "ON" or "FLICK:
NOTE: Following initial installation, remount the candle onto the window every fifteen days to ensure the candle is securely mounted.
INSTRUCTIONS
Leave the switch in either position to automatically illuminate at night!
