- Page 1 Vineyard & Orchard Spreader Model SF5 Operator’s Manual THIS MANUAL MUST BE READ AND UNDERSTOOD BEFORE ANYONE OPERATES THIS MACHINE!
- Page 2 YOU MUST FILL OUT YOUR WARRANTY REGISTRATION TO ACTIVATE YOUR WARRANTY AND TO QUALIFY FOR PARTS AND SERVICE!! To the Owner; Thank-You for choosing a quality spreader from Pequea Machine, Inc. We strive to give you the best equipment and the best level of service of any company.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Serial Number Specifications SAFETY General Safety Guidelines Safety Decals and Reflectors HITCHING Tractor Requirements Attaching to the tractor TRANSPORT Field Transport Road Transport OPERATION General Operation MAINTENANCE General Maintenance Wheel & Tire Maintenance Wheel Bearing Maintenance Grease Fitting Lubrication Apron Chain Maintenance Hydraulic System Maintenance... -
Page 4: Introduction
INTRODUCTION Thank-You for choosing a Pequea Spreader. Your spreader is the result of years of research and development work. This Operator’s Manual will familiarize the operator with the safety and operation of the machine. Included are complete instructions for safe and efficient operation, lubrication, and maintenance procedures. -
Page 5: Safety
SAFETY General Safety Guidelines This symbol precedes specific safety instructions throughout this manual. When read- ing the manual pay close attention to the information that follows this symbol FAILURE TO FOLLOW INSTRUCTIONS IN THIS MANUAL COULD RESULT IN PERSONAL INJURY OR DEATH. READ ENTIRE MANUAL BEFORE OPERATING THE MACHINE! Keep hands, feet, and clothing away from all moving parts. -
Page 6: Safety Decals And Reflectors
SAFETY Safety Decals and Reflectors Decals and reflectors are for the protection of yourself and others. If they are missing, faded, or not readable, get replacements from your dealer immediately. Shown below are some of the warning decals used on your spreader. -
Page 7: Hitching
HITCHING Tractor Requirements Your spreader is equipped with a 540 RPM PTO hydraulic pump and must be matched with a tractor that meets this requirement. Attaching to the tractor Line up the hole in the tractor draw bar with the hitch on the spreader and insert an approved hitch pin with a locking device or safety clip. -
Page 8: Transport
TRANSPORT Field Transport Never allow passengers on the spreader or the tractor. Avoid tight turns to reduce the risk of loss of control. Remain fully aware of the width and length of the spreader in relation to the objects you are pass- ing, either stationary or moving. -
Page 9: Operation
OPERATION General Operation The apron and attachment functions on the spreader are driven hydraulically by the hydraulic pump run by the tractor PTO. The spreader is equipped with a hydraulic manifold with precision hydraulic valves (Figure 4) to fine- tune both the attachment and apron chain speed to accommodate a wide range of spread patterns, material density and much more. -
Page 10: Maintenance
The axle can be adusted by removing the bolts that hold the axle hanger in place. Before adjusting the axle, make sure the spreader is safely supported on both sides. Keep in mind the weight of the spreader. Always keep at least 6 bolts in to secure the axle hanger in place. -
Page 11: Grease Fitting Lubrication
MAINTENANCE Grease Fitting Lubrication The spreader is designed to require minimal lubrication. However, the importance of sufficient and proper lubrication cannot be over emphasized as it is the best insurance against unnecessary repairs and will greatly increase the life and performance of the machine. Lubricate all the grease fitting every six months or after 50 loads, whichever comes first. -
Page 12: Hydraulic System Maintenance
MAINTENANCE Hydraulic System Maintenance Recommended Oil Level The hydraulic system is virtually maintenance free since it is a fully self contained system. However, you may need to add oil to the res- ervoir to keep it at the proper level. See Figure 7 below for recommended oil level. -
Page 13: Options And Attachments
OPTIONS AND ATTACHMENTS Dual Conveyer Attachment The side conveyer option is to be used as a double row fertilizer applicator. The speed of the conveyer belts determines the distance the material is thrown out beyond the end of the convey- ers. -
Page 14: Oil Cooler Option
OPTIONS AND ATTACHMENTS Oil Cooler Option The Grape Spreader is equipped with a large capacity oil reservoir that is sufficient to keep the oil cool in most climates. However, if the spreader is being used in an extremely warm, sunny climate the oil cooler option will help keep the oil temperature at a safe level. Dual Spinner Attachment The spinner attachment is used to distribute material evenly over a wide area behind and on both sides of the spreader. -
Page 15: Warranty
WARRANTY Pequea Machine’s Limited Warranty Pequea Machine Company warrants to the original Purchaser all Machinery, Equipment, or Trailers manufactured by it, to be free from defects in material and workmanship under normal use and ser- vice. Its obligation under this Warranty shall be limited to replacement or repair of any parts thereof, free of charge to the original Purchaser, at its place of business, provided, however, that the part(s) to be replaced or repaired, shall within one (1) year after delivery to the original Purchaser, be dem- onstrated to be defective;... -
Page 16: Notes
NOTES... - Page 18 200 Jalyn Drive P.O. Box 399 New Holland PA 17557 Phone: 717-354-4343 Fax: 717-354-8843 E-mail: pequea@pequeamachine.com www.pequeamachine.com...
