HEXBEAM MARK III HD
HEX-BEAM SP7IDX TECHNOLOGY ANTENNA is a broad band hex
antenna operating in PLUG AND PLAY system, its assembly time is 1-1,5h for
one person. Its installation doesn't require any additional tuning. Thanks to
its small and compact structure its turning requires only a small light rotor.
The antenna works properly even when it's installed relatively low over the
ground.
Both antennas are equipped with all parts, required for a one, five or
six bands beam in range from 6 to 20 meters. The HEXBEAM SP7IDX
TECHNOLOGY offers mounted on the ground gain for front – to – back huge
amplify. The antenna offers the same values as a full size YAGA antenna. Has
unique shape: is much smaller, stiffly and makes less noise than typical
beams, it is lighter, easier to montage.
Please see its possible assembly methods on:
http://sp7idx-hexbeam.eu/hexbeam/mounting-suggestion
The antennas are tested at 7,3m height with analyser RigExpert AA-
55 ZOOM + MetroVNA Pro Touch Deluxe
24,8 m AIRCELL 7 + RG400/U HEW-Kabel GmbH Germany Filial Nordic-
Örebro-Cable
Test connections conducted with transceiver Flex Radio System
6600M + Electraft K-3s
PA Team SPE EXPERT 1,3K + 2K
It is helpful if you completely read through the instructions a couple of time before
.
you start
The antenna is assembled intuitively, but please
Please pay special attention to the red inscriptions.
&
HEXBEAM MARK III Light
Ver 05.018
READ
the manual carefully.
HEX – BEAM SP7IDX TECHNOLOGY
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MARK III HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HEX-BEAM SP7IDX MARK III HD

Summary of Contents for HEX-BEAM SP7IDX MARK III HD

  • Page 1 HEXBEAM MARK III HD HEXBEAM MARK III Light Ver 05.018 HEX-BEAM SP7IDX TECHNOLOGY ANTENNA is a broad band hex antenna operating in PLUG AND PLAY system, its assembly time is 1-1,5h for one person. Its installation doesn't require any additional tuning. Thanks to its small and compact structure its turning requires only a small light rotor.
  • Page 2 Parcel Arrived...

  • Page 3: Part List

    PART LIST Three types of spreders (poles)  6 pieces - small ones + kevlar lines with S-hooks (6x 1m diameter 12,7mm) #4/8  6 pieces - medium (6x 1,35m diameter 17mm) #5/8  6 pieces - large (6x 1,35m diameter 22mm) #6/8 HEX –...
  • Page 4 Set of hol dres (wire cleat set):  Size 5 - 6 set  Size 7 - 24 set  Size 9 - 6 set  STORE + Insulating tape - 1 piece – (option) #2/8  Screw 8 x 20 - 4 pieces for hub clamp on rure with centerpost...
  • Page 5 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 6 Down centerhub - mast...
  • Page 7 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 8 6 sets of electric component (driven+reflector+spacer cords) 6-10-12-15-17-20m #2/8...
  • Page 9 Center post + balun (option) -1set #3/8 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 10 do not change the position of the screw and do not tighten it !!!
  • Page 11 Normal situation centerpost Center plate-1set #1/8 # 7/8 ( or 8/8) polyamide element block clamps 6 set HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 12 #8/8 (or 7/8) sleeve 6 art...
  • Page 13 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 14 Centerhub complet +centerpost...
  • Page 15 bottom part centerhub HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 17 ASSEMBYL INSTRUCTION Step 1. Fix holders on spreaders with 2, 3, 4, 5 and 6 symbols so that they look like on spreaders no.1  6 small poles (1m - 12,7mm) + holders no. 5 - 1 piece per pole ...
  • Page 18 Attention ! correct wire tension adjust with black handle fixing left or right, Do not tighten the wire too much, The wires should be a little slack do not screw it tightly, not the wheel from the car !!! Only minor adjustment is required if any, for proper tension of the wires. Not to tight, not to much sag of the wires.
  • Page 19 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 20 Attention correct wire tension adjust with black handle fixing left or right, Do not tighten the wire too much, do not screw it tightly, not the wheel from the car !!!
  • Page 21 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 23 Step 2. Place the centre post inside the centre plate so that the UC1 socket was facing the log. As an additional protection against the self-turning of the whole structure the upper HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 24 flange is equipped with an additional passer-by screw - tight it up carefully! Block the centre plate by turning two set screws located in both flanges - upper and bottom one.
  • Page 25 Step 3. Place the poles in pipes in the centre plate following their numbers on fibreglass spreaders and pipes in the centre plate. Pay attention to places with cut-outs which are inserted into locks in pipes from the centre plate. The poles are marked with numbers and those with the same ones should be stored together.
  • Page 27 / Block rivet / HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 29 Step 4. The assembly and tightening of lines. We start with Kevlar line with S-hook should be fixed in the center post in closed loop. After 6 lines have been fixed in the center post, fasten lines around the perimeter - one to the other - in clockwise direction.
  • Page 31 Step 5. HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 32 The fixing of bands should begin with the lowest band, i.e. 6M - which is the closest to the centre post. Then 10M, 12M, 15M, 17M and 20M. numbers on centerpost and band 1-20m 2-17m 3-15m 4-12m 5-10m 6-6m The leads have the same band symbols as the centre post. Fix the closed loop on one side of the lead on screw in centre post, then keep putting it through holders on poles until you reach the second screw in the centre post.
  • Page 33 Pay attention to the type of applied washer! Pay much attention during this stage - electric lines cannot be overtightened. You need to feel that they're a bit loose when you touch them, they need to hang down to avoid their breakage during strong wind or snow. To correct the lead tension - loosen or tighten one of the lead holders, two or three pieces - this doesn't affect proper operation of a given band.
  • Page 35 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 36 There needs to be a small backlash, the lines should hang down a bit. DO NOT TIGHTEN THEM !!!
  • Page 37 DO NOT MAKE THE WIRES TOO TIGHT. Also too l ose and the wire will drop down and touch the wire below. This is als o not good and will cause the SWR of those two to not be right. You want to kee p the spacing between wires.
  • Page 38 This is how properly bent poles look like...
  • Page 39 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 40 HEXBEAM SP7IDX TECHNOLOGY is very light...
  • Page 41 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 42 Step 5. When the assembly of the antenna is over place it on a mast or other structural work. Please see exemplary installations on my website : http://sp7idx-hexbeam.eu/hexbeam/mounting-suggestion Depending on the target height of the antenna it is advised to use at least one pair of guy ropes which will stabilize the whole structure.
  • Page 43 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 44 For the purpose of outside operation there is a special small mast for HEXBEAM of 7,10 m length.
  • Page 45 For tests and antennas control - MAX6 antenna analyser HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 46 Both products are included in my offer on my website, you’re welcome to visit it. The photos can differ a bit from the actual structure due to implemented structural improvements. If you have any additional questions or think that the structure should be changed or improved, please send me a message.
  • Page 47 DO NOT transmit, even with the aid of a tuner, outside the designed bands. This can cause excessive voltage and arching of the terminals on the center post and replacement is not covered by any warranty. That's it, the assembly is over. Have a nice work with HEX-BEAM SP7IDX TECHNOLOGY Waldi SP7IDX sp7idx@interia.pl www.sp7idx-hexbeam.eu...
  • Page 48 Enclosed you will find my measurements with the MetroVNA Pro Touch Deluxe + RigExpert AA-55 ZOOM through 24,8 m Aircell7. Hexbeam was real 7 + 4,5m above the ground. Remember that this beam is broad-banded so the SWR will remain quite low across each band –...
  • Page 49 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 51 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 53 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 55 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 57 HEX – BEAM SP7IDX TECHNOLOGY...
  • Page 59 HEX – BEAM SP7IDX TECHNOLOGY...

  • Page 61: Warranty

    Warranty Antennas HEXBEAM MARK III HD and Light condition for receiving a plenary indulgence and full warranty! if there is no opinion issued, the warranty tration right! it is only 2-3 minutes devoted to me Sorry to bother you but it is necessary.
