- Page 1 Stainless Steel Mechanical Keyless Entry Lock Series MKS www.elemakelocks.com...
- Page 2 Elemake keeps on working hard to provide customers top-grade quality hardware at affordable price. Grace customer's door with the stylish design and excellent craftwork since 1976. Elemake are always beside you to make your life more safe and stylish. Series-MKS is aproducts family of the high grade stainless steel mechanical keyless door lock.
-
Page 3: Table Of Contents
Content: Structure and dimension Component List Assembly Drawing Drilling Holes Dimension Installation Instruction Step 1: Change the user code(Optional) Step 2: Prepare the door for installation with the drilling template Step 3: Install the latch/front cover/back cover/cover plate How to operate the lock Open the door from exterior when locked Open the door from interior when locked Lock the door... -
Page 4: Structure And Dimension
1. Structure and dimension 1.1 Components List Item# Component Name Quantity Front Cover Back Cover Latch 2-3/4" Latch 2-3/8" Cover Plate Combination Tumblers Non-Combination Tumblers Spindle Strike Plate Striker Machine Screw M4*50 Machine Screw M4*50 Wood Screw Threaded Tube Allan Wrench User's Manual Set Screw Tweezer... -
Page 5: Assembly Drawing
1.2 Assembly drawing... -
Page 6: Drilling Holes Dimension
1.3 Drilling Holes Dimension... -
Page 7: Installation Instruction
2. Installation Instruction 2.1 Step 1: Change the user code(Optional) If you wish to change your code, see below instructions----- 1) Pull up the front cover handle to make the tumblers to protrudefrom tumbler cavities on front cover. 2) Initial combination is “123678” 3) To change the combination, please put the code-tumblers(golden colored)into expected... -
Page 8: Step 2: Prepare The Door For Installation With The Drilling Template
Use the tweezer to add/remove the tumblers on the front cover Step 2: Prepare the door for installation with the drilling template 1) Place template (supplied) on door and fold along door’s edge. 2) Drill holes as instructed.(see Figure 2) NOTE: For Pre-Prepped 2 1/8”... -
Page 9: Step 3: Install The Latch/Front Cover/Back Cover/Cover Plate
Step 3: Install the latch/front cover/back cover/cover plate 1) Install the latch onto the door. Using a screwdriver, secure the latch to the door with the wood screws.(See Figure 3) 2) Align the colored mark on the top of the square hole of latch. Figure 3 3) Install the front cover, put the spindle through the square hole of the latch, prior to it, the spindle’s facet A(the facet with the black font)should... - Page 10 4) Then,install the back cover from interior of the door, put the long machine screws on the position 1 n and 4 on back cover, and use the screw driver to tighten them, and use the allan wrench(supplied) to tighten the set screw on the handle.(See Figure 5) Install the cover plate, tighten it with the long machine screw on 2 and 3...
- Page 11 6) Test the combination and function(prior to finish this step, don’tclose the door) A. Pull up the handle, then press the handle from exterior, if cannot be pressed down, it’s good, then move to next step. B. Press the handle from interior, the latch can be moved back, it’s good, move to next step.
-
Page 12: How To Operate The Lock
3. How to operate the lock. (Figure 7) Open the door from exteriorwhen locked---Input the correct combination, then user will be able to press down the handle, it will be unlocked. If input the incorrect combination, the handle will not be able to be pressed down, it will stay locked. -
Page 13: The Lock Will Stay Unlocked
input the correct combination, then the handle can be pressed down to unlock The lock will stay unlockeduntil the handle is lifted. Initial Combination For all the new lock, the pre-set initial combination is “123678” Change the combination(User’s code)----- If the user want to change the combination. Untighten the #2, #3 screws on back cover, take the cover plate off. -
Page 15: Quality Policy
Return/replacement Policy 4.1 If you want to return/replace the goods for any reason. Please contact us directly for returning/replacement, In this way, EleMake will be able to pay for the returning shipping cost to avoid loss to any customers. 4.2 What if out of return/replacement window, or out of warranty time? - Page 16 EleMake Lock Products. Online customer service---- Facebook #:csservice168@163.com Skype #: customerservice@products Email-address: customerservice@elemakelocks.com Customer service center address: Eastern: 25752 W.143rd,St,Plainfield,IL,US,60544...
