Ezee-On 4600 DISC Owner's Manual

Heavy duty tandem 3 section frame
Hide thumbs

Advertisement

Quick Links

Ezee-On
MODEL 4600 DISC
HEAVY DUTY TANDEM
3 SECTION FRAME
OWNER'S MANUAL
c/w
ASSEMBLY INSTRUCTIONS
- (for S/N 51376 and later)
and
Parts List
- (for all Serial Numbers)
Manufactured
Vegreville, Alberta
Ezee-On Manufacturing
by
Canada
721F
Printed in Canada

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4600 DISC and is the answer not in the manual?

Questions and answers

malcolm longbottom
February 17, 2025

How much does a 4600 weight kg

0

Subscribe to Our Youtube Channel

Related Manuals for Ezee-On 4600 DISC

Summary of Contents for Ezee-On 4600 DISC

  • Page 1 Ezee-On MODEL 4600 DISC HEAVY DUTY TANDEM 3 SECTION FRAME OWNER'S MANUAL ASSEMBLY INSTRUCTIONS - (for S/N 51376 and later) Parts List - (for all Serial Numbers) Manufactured Vegreville, Alberta Ezee-On Manufacturing Canada 721F Printed in Canada...
  • Page 2 INTRODUCTION Thank you for deciding to purchase this Ezee-On product. In addition to having traditional Ezee-On reliable and durable disc, your new implement incorporates a number of operational and safety features. We urge you to familiarize yourself with the operation and maintenance of your implement by reading this manual carefully.
  • Page 3 SAFETY RECOMMENDATIONS WATCH FOR THIS SYMBOL. IT IDENTIFIES IMPORTANT SAFETY MESSAGES. WHEN YOU SEE THIS SYMBOL, READ THIS SAFETY MESSAGE CAREFULLY. GENERAL SAFETY 1. Never allow anyone to ride on the tractor drawbar, or on the disc. The person(s) riding may fall and be seriously or fatally injured. 2.
  • Page 4 MAINTENANCE SAFETY 1. Do not loosen or disassemble hydraulic components when there is pressure within those components. Hydraulic components under pressure may cause parts and hydraulic fluid to fly out at a high velocity, which could cause serious injury. Always relieve the pressure in the hydraulic system before making adjustments to the hydraulic system.
  • Page 5 TRANSPORT SAFETY CONTINUED: 5. When transporting the disc with the wings folded (UP), be sure there is sufficient clearance under all power lines and other overhead obstructions. Serious injury or death can result from contact with electrical lines. Use care to avoid contact with electrical lines when moving or operating the disc.
  • Page 6 SPECIFICATIONS APPROX. NO. OF GANG BEARING WING LIFT CYLINDER APPROX. APPROX. TYPE WING BLADE CUTTING NO. OF GANG TRANSPORT TRANSPORT MODEL WIDTH SPACING WIDTH BLADES BEARINGS WIDTH HEIGHT STD. SIZE 4600 - 66SN Super Narrow 9" (230 mm) 24-1/2' (7.5 m) T2-215 4"...
  • Page 7 GENERAL OPERATING INSTRUCTIONS 1. Before operating disc, refer to Safety Precautions on pages 2 to 4. Review disc safety items applicable to road transport and field operation of disc. 2. This machine is a primary tillage tool designed to bury crop residue. The following recommendations (paragraphs A to J) will enhance the discs performance: (A) When lowering wing to field position, be sure wing lift cylinders are fully extended.
  • Page 8 General Operating Instructions Continued: REPHASING ROCKSHAFT CYLINDERS - Periodically, the hydraulic lift cylinders on wing frame will not be synchronized with center frame cylinder. This will cause uneven cutting depth. If this happens it will be necessary to rephase the lift cylinders. Rephasing is done by lifting disc completely out of the ground and holding the hydraulic control lever until all (3) three rockshaft cylinders are fully extended.
  • Page 9 GENERAL OPERATING INSTRUCTIONS CONTINUED: To keep disc level transport wheels must be riding on ground gauging desired discing depth, as shown in Fig. 3. If conditions are such that disc can not penetrate to maximum depth, do not raise transport wheels off ground as shown in Fig. 2. Raised transport wheels may cause front of disc to drop causing front gangs to cut deeper than rear gangs.
  • Page 10 GENERAL OPERATING INSTRUCTIONS CONTINUED: See Fig. 4. When transporting disc, always place hydraulic lockup valves in closed position. Lockup valves are located at the front end of centre frame. CAUTION: WHEN TRANSPORTING DISC ALWAYS PLACE BOTH HYDRAULIC LOCKUP VALVES IN “CLOSED POSITION”.
  • Page 11 HYDRAULIC LEVER WAS ACCIDENTALLY OPERATED, WING COULD FALL CAUSING SERIOUS INJURY OR DEATH. See Fig. 7. Install the "SMV" emblem (not supplied by Ezee-On) in the "SMV" bracket welded to the R.H. rear centre frame before transporting the disc CAUTION: USE THE "SMV"...
  • Page 12 GENERAL OPERATING INSTRUCTIONS CONTINUED DANGER: WHEN TRANSPORTING DISC WITH WINGS RAISED, BE SURE THERE IS SUFFICIENT CLEARANCE UNDER ALL POWER LINES AND OTHER OVERHEAD OBSTRUCTIONS. SERIOUS INJURY OR DEATH CAN RESULT FROM CONTACT WITH ELECTRICAL LINES. USE CARE TO AVOID CONTACT WITH ELECTRICAL LINES WHEN MOVING OR OPERATING DISC. MODELS EQUIPPED WITH FOLDING GANG BEAMS MUST HAVE THESE BEAMS FOLDED TO GIVE MINIMUM TRANSPORT HEIGHT.
  • Page 13 ADJUSTMENTS 1. LATERAL ADJUSTMENT OF THE FRONT AND REAR GANGS a) FRONT GANGS - See Fig. 8. Loosen bearing hanger U-bolts and adjust front gangs so that leading edge of inside blades are, arrow 1, approximately 2-1/2" (63.5 mm) past centre of disc.
  • Page 14 ADJUSTMENTS CONTINUED: LEVELLING WING FRAMES - See Fig. 11. Before this adjustment is made, be sure centre frame is level from front to rear. After adjustments are complete tighten nuts on cylinder I-Bolt. For even blade penetration, outside of wing frames must be level with centre frame or even 1/2"...
  • Page 15 Page 14...
  • Page 16 MAINTENANCE 1. LUBRICATION See Fig. 12 - All grease lubricating points on disc are marked with arrow G. The oil lubrication points are marked with arrow O. G1) GANG BEARINGS - for 410 Series - Lubricate every 20 hours of operation with 6 to 10 strokes of hand grease gun. Use a high quality SAE multi-purpose grease.
  • Page 17 (d) Lubricate all grease points. (e) Check disc for worn or damaged parts. Replace damaged parts during the off season. (f) Touch up any scratches with EZEE-ON paint. CAUTION: ALWAYS RELIEVE THE PRESSURE IN HYDRAULIC SYSTEM AND CLOSE BOTH HYDRAULIC LOCKUP VALVES WHEN DISC IS NOT BEING USED.
  • Page 18 MAINTENANCE CONTINUED: 10. TIRE MAINTENANCE AND SAFETY: a) Keep the pressure equal on all wheels. See specifications on page 5 for correct tire pressure. b) Do not inflate tires above recommended pressure. c) Only experienced personal should attempt to repair a tire or mount tire on a wheel. d) Do not weld or heat tire and wheel assembly when tire is inflated.
  • Page 19 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE REMEDY OUTSIDE BLADES OF FRONT WINGS - wheels raised off ground causing front of - lower wheels to ground so they gauge discing ARE CUTTING TOO DEEP CAUSING disc to drop depth, see section L of general operating instructions DISC TO RIDGE AT OUTSIDE on page 8 - tire pressure is low on outer wheels...
  • Page 20 - scrapers are too far from blades - adjust scrapers so they are contacting blades - thrash conditions too heavy for your - contact your Ezee-On Dealer machine cylinder(s) WHEN RAISING DISC OUT OF - piston seals on wing rockshaft cylinder(s)
  • Page 21 ASSEMBLY INDEX DESCRIPTION PAGE Assembling Main Frame Assembling Hitch and Levelling Crank Attaching Main Frame Gang Beams Attaching Wing Frame and Wing Frame Gang Beams Attaching Rockshaft Cylinders and Wing Lift Cylinders Attaching Hydraulic Hoses to Rockshaft Cylinders & Wing Cylinders How Main Lift Hydraulic System Works Attaching Gang Assemblies Warning Light Kit Assembly (Optional)
  • Page 22 ASSEMBLY INSTRUCTIONS 1. See Fig. 20. Fasten L.H. main frame, arrow 1, and R.H. main frame half, arrow 2, together as shown. Main frame halves are fastened with four (4) 1" x 3-1/4" (25.4 mm x 82.6 mm) hex. bolts c/w nuts and lockwashers at the front, rear and inner connecting plates, arrow 3. Do not tighten bolts at this time.
  • Page 23 ASSEMBLY INSTRUCTIONS CONTINUED: WARNING: SUPPORT MAIN FRAME SECURELY BEFORE ASSEMBLING COMPONENTS. INADEQUATE SUPPORT MAY RESULT IN THE HEAVY COMPONENTS FALLING AND CAUSING SERIOUS INJURY TO YOU OR PERSON(S) NEARBY. 6. INSTALLING HUB ASSEMBLIES Walking Beam Type. See Fig. 20. Install four (4) eight bolt hub and spindle assemblies, arrow 9, into walking beam tubes, arrow 8. Fasten each spindle to the tube with one (1) 1/2"...
  • Page 24 ASSEMBLY INSTRUCTIONS CONTINUED: 8. See Fig. 23. Attach hitch assembly, arrow 1, to hitch lugs on main frame with two (2) 1-1/2" dia. x 5" (38.1 mm dia. x 127 mm) pins. Secure each pin with one (1) 7/16" (10.9 mm) lynch pin. 9.
  • Page 25 ASSEMBLY INSTRUCTIONS CONTINUED: 13. ATTACHING MAIN FRAME GANG BEAMS - See Fig. 24 and 25. NOTE: Determine front and rear main frame gang beams by appearance and length. Main frame gang beams have clevis ends as shown in Fig. 24. The front gang beams are longer than the rear gang beams. For gang beam lengths refer to chart on page a) Attach front gang beams, arrow 1, to mount brackets, arrow 2, welded to inside and outside frame members.
  • Page 26 ASSEMBLY INSTRUCTIONS CONTINUED: 14. See Fig. 26. Raise wing frame assemblies, arrow 3 and 4, approximately 36" (914 mm) from ground and block securely. Locate one (1) wing frame on each side of main frame. Wing frames are L.H. and R.H. and must be positioned as shown. 15.
  • Page 27 ASSEMBLY INSTRUCTIONS CONTINUED: 17. See Fig. 26. Fasten L.H. and R.H. wing rockshafts, arrow 10 and 11, to bottom of L.H. and R.H. wing frames. Be sure correct rockshaft is used. Wheel leg points forward with cylinder arm on top. Secure each rockshaft to two (2) bearing brackets, arrow 16, with two (2) sets of 5-1/2" (139.7 mm) rockshaft bearings, arrow 17.
  • Page 28 ASSEMBLY INSTRUCTIONS CONTINUED: 21. See Fig. 27. Fasten one (1) 4" x 24" (101.6 mm x 610 mm) lift cylinder, arrow 1, to main frame and rockshaft arm. Fasten barrel end to cylinder lug, arrow 2. Position so ports face L.H.S. Fasten shaft end to cylinder arm, arrow 3, on rockshaft. Fasten each end of cylinder with one (1) 1- 1/4"...
  • Page 29 Page 28...
  • Page 30 ASSEMBLY INSTRUCTIONS CONTINUED: 25. See Fig. 29. Place two (2) hydraulic lockup valves, arrow 1 and 2, in bracket, arrow 3, welded to front centre of main frame. Valves are assembled L.H. and R.H. Position valves as shown so handle moves out when closing valve (as shown) and forward when opening valves.
  • Page 31 HYDRAULIC SYSTEM FOR DISCS WITH WIDE WING FRAMES Page 30...
  • Page 32 ASSEMBLY INSTRUCTIONS CONTINUED: g) See Fig. 28. Install one (1) 1/4" x 54" (6.35 mm x 1372 mm) hydraulic hose, to the shaft end port of the L.H. 5" x 36" (127 mm x 914 mm) wing lift cylinder, and fasten opposite end to one (1) 3/8" x 3/8" x 3/8" (9.39 mm x 9.39 mm x 9.39 mm) tee. Fasten one (1) 1/4" x 54" (6.35 mm x 1372 mm) hydraulic hose, to the shaft end port of the R.H.
  • Page 33 ASSEMBLY INSTRUCTIONS CONTINUED: i) See Fig. 30. Install one (1) 3/8" x 90 degree (9.39 mm) swivel street elbow into the barrel end port of the front R.H. 5" x 36" (127 mm x 914 mm)wing lift cylinder. Install one (1) 3/8" x 90 degree (9.39 mm) street elbow, into the shaft end port of front R.H. 5" x 36" (127 mm x 914 mm) wing lift cylinder.
  • Page 34 ASSEMBLY HYDRAULIC CONTINUED: 30. NOTE: Before filling lift cylinders with oil, remove clevis pin from shaft end of each cylinder so that the cylinders may be extended and contracted WITHOUT ACTUATING rockshafts. Support cylinders so shafts pass over rockshaft arms and frame components. See Fig.
  • Page 35 Page 34...
  • Page 36 ASSEMBLY INSTRUCTIONS CONTINUED: 32. ATTACHING GANG ASSEMBLIES - See Fig. 31. NOTE: Find gang pattern for your disc on pages 41 to 52. NOTE: Remove scraper assemblies and bundling tie bars from gang assemblies. The scraper assembly that is bundled with each gang will be assembled together on the disc.
  • Page 37 ASSEMBLY INSTRUCTIONS CONTINUED: b) See Fig. 31. Position each scraper assembly on REAR side of it’s gang with scraper placed against concave side of blades. Fasten scraper assembly to gang beam with ONE (1) scraper mount plate for each bearing hanger in the gang. Position outer scraper mount plates as close as possible to the end of the scraper bar.
  • Page 38 FIG. 34 AMBER AMBER MAIN FRAME R.H.S. 2-3" LAMP SUPPORT 2-3" BRACKET WING WING GANGS GANGS 1/2" x 9" N.C. (12.7mm x 228.6mm) BOLT (2) LAMP SUPPORT LAMP SUPPORT BRACKETS BRACKET LAMP 94" (2388mm) FRONT SIDE VIEW OF MAIN FRAME 37.
  • Page 39 WARNING LIGHT INSTALLATION CONTINUED: F) INSTALL ELECTRICAL WIRING AS FOLLOWS: F1) See Fig. 35- Run four (4) wire cables (brown, white, yellow, and green) from tractor socket receptacle to rear of disc. Split off green wire and run it to the R.H. amber lamp. Next, run white wire to amber lamp on L.H. side, then run yellow wire to L.H. amber lamp and run brown wire to red lamp on L.H.
  • Page 40 FIG. 36 38. REFLECTOR DECAL INSTALLATION - See Fig. 36 NOTE: Before installing decals, clean the area they will be placed on. a) Place one 2" x 9" (50.8 mm x 228.6 mm) red reflector decal on rear side of each rear gang beam. Locate decals approximately 1" (25.4 mm) from end of gang beam.
  • Page 41 GANG BEAM CHART (Model 4600 Disc) 9" (230 mm) SPACING L.H. & R.H. L.H. & R.H. L.H. & R.H. L.H. & R.H. DISC FRONT CENTRE REAR CENTRE FRONT WING REAR WING FRAME BEAM FRAME BEAM FRAME BEAM FRAME BEAM 66B (Super Narrow Wing) 86-1/2"...
  • Page 42 DISC GANG PATTERN - 9" (230 mm) SPACING - Super Narrow Wing 66 BLADE FRONT APPROX. WIDTH 25 ft. (7.62 m) 20 BEARINGS DISC GANG PATTERN - 9" (230 mm) SPACING - Super Narrow Wing 70 BLADE FRONT APPROX. WIDTH 26 ft.
  • Page 43 DISC GANG PATTERN - 10-1/2" (266 mm) SPACING - Super Narrow Wing 58 BLADE FRONT APPROX. WIDTH 25 ft. (7.62 m) 20 BEARINGS DISC GANG PATTERN - 10-1/2" (266 mm) SPACING - Super Narrow Wing 62 BLADE FRONT APPROX. WIDTH 27 ft.
  • Page 44 DISC GANG PATTERN - 12" (304 mm) SPACING - Super Narrow Wing 50 BLADE FRONT APPROX. WIDTH 24 ft. (7.31 m) 20 BEARINGS DISC GANG PATTERN - 12" (304 mm) SPACING - Super Narrow Wing 54 BLADE FRONT APPROX. WIDTH 26 ft.
  • Page 45 DISC GANG PATTERN - 9" (230 mm) SPACING 74 BLADE FRONT APPROX. WIDTH 28 ft. (8.53 m) 22 BEARINGS ___________________________________________________________________________________ DISC GANG PATTERN - 9" (230 mm) SPACING 86 BLADE FRONT APPROX. WIDTH 32-1/2 ft. (9.90 m) 24 BEARINGS Page 44...
  • Page 46 DISC GANG PATTERN - 9" (230 mm) SPACING 94 BLADE FRONT APPROX. WIDTH 35-1/2 ft. (10.82 m) 28 BEARINGS __________________________________________ DISC GANG PATTERN - 9" (230 mm) SPACING 102 BLADE FRONT APPROX. WIDTH 38-1/2 ft. (11.73 m) 32 BEARINGS Page 45...
  • Page 47 DISC GANG PATTERN - 9" (230 mm) SPACING 106 BLADE FRONT APPROX. WIDTH 40 ft. (12.19 m) 34 BEARINGS ___________________________________________________________________________________ DISC GANG PATTERN - 9" (230 mm) SPACING 110 BLADE FRONT APPROX. WIDTH 41-1/2 ft. (12.64 m) 32 BEARINGS Page 46...
  • Page 48 DISC GANG PATTERN - 10-1/2" (267 mm) SPACING 66 BLADE FRONT APPROX. WIDTH 29 ft. (8.83 m) 22 BEARINGS ___________________________________________________________________________________ DISC GANG PATTERN - 10-1/2" (267 mm) SPACING 74 BLADE FRONT APPROX. WIDTH 32 ft. (9.75 m) 24 BEARINGS Page 47...
  • Page 49 DISC GANG PATTERN - 10-1/2" (267 mm) SPACING 82 BLADE FRONT APPROX. WIDTH 35-1/2 ft. (10.82 m) 28 BEARINGS ___________________________________________________________________________________ DISC GANG PATTERN - 10-1/2" (267 mm) SPACING 90 BLADE FRONT APPROX. WIDTH 38-1/2 ft. (11.73 m) 32 BEARINGS Page 48...
  • Page 50 DISC GANG PATTERN - 10-1/2" (267 mm) SPACING 94 BLADE FRONT APPROX. WIDTH 40-1/2 ft. (12.34 m) 34 BEARINGS _____________________________________________________________________________________________________________ DISC GANG PATTERN - 10-1/2" (267 mm) SPACING FRONT 98 BLADE APPROX. WIDTH 42 ft. (12.80 m) 34 BEARINGS Page 49...
  • Page 51 DISC GANG PATTERN - 12" (305 mm) SPACING 58 BLADE FRONT APPROX. WIDTH 28-1/2 ft. (8.64 m) 22 BEARINGS ___________________________________________________________________________________ DISC GANG PATTERN - 12" (267 mm) SPACING 66 BLADE FRONT APPROX. WIDTH 32-1/2 ft. (9.90 m) 24 BEARINGS Page 50...
  • Page 52 DISC GANG PATTERN - 12" (305 mm) SPACING 74 BLADE FRONT APPROX. WIDTH 36-1/2 ft. (11.13 m) 34 BEARINGS ___________________________________________________________________________________ DISC GANG PATTERN - 12" (267 mm) SPACING 78 BLADE FRONT APPROX. WIDTH 38-1/2 ft. (11.73 m) 34 BEARINGS Page 51...
  • Page 53 DISC GANG PATTERN - 12" (305 mm) SPACING 82 BLADE FRONT APPROX. WIDTH 40-1/2 ft. (12.34 m) 32 BEARINGS ___________________________________________________________________________________ DISC GANG PATTERN - 12" (305 mm) SPACING 86 BLADE FRONT APPROX. WIDTH 43 ft. (13.11 m) 34 BEARINGS Page 52...
  • Page 54 PAGE 53 HAS BEEN LEFT OUT INTENTIONALLY Page 53...

  • Page 55: Table Of Contents

    4600 DISC PARTS INDEX (w/HANGER MOUNTED SCRAPER BAR) PAGE Frame & Gang Beam Assembly Decals and Paint Hitch & Leveling Crank Assembly Rockshaft & Wheel Assembly - w/Main Frame Walking Beam Rochshaft & Wheel Assembly - w/Off Highway Tires Hydraulic Assembly - Narrow Wing...
  • Page 56 MODEL 4600 DISC Page 55...

  • Page 57: Frame & Gang Beam Assembly

    MODEL 4600 DISC FRAME & GANG BEAM ASSEMBLY REF. PART REF. PART DESCRIPTION REQ’D DESCRIPTION REQ’D DF13018 L.H. Main Frame half less rockshaft bearing cap & spring cushion assembly 9" (230mm) SPACING L.H. Rear Wing Gang Beam (Solid Type) - 89" (2260mm) long DF13019 R.H.

  • Page 58: Hitch & Leveling Crank Assembly

    PART NO. DESCRIPTION QTY. REQ’D DF13000 4600 Decal (3-1/4" (82.6mm) x 11" (279mm)) DF13002 Ezee-On Decal (2-1/2" (63.5mm) x 15" (381mm)) DF9507 Danger Decal (3-1/2" (88.9mm) x 14-7/8" (311mm)) DF13001 Hydraulic Lockup Decal (2-5/8" (66.7mm) x 7" (178mm)) DF7152 Maintenance Decal (2-1/2" (63.5mm) x 9" (229mm)) DF9506 Danger, Caution Decal (2-1/4"...

  • Page 59: Rockshaft & Wheel Assembly - W/Main Frame Walking Beam

    MODEL 4600 DISC ROCKSHAFT & WHEEL ASSEMBLY - w/MAIN FRAME WALKING BEAMS REF. PART. NO QTY. REF. PART. QTY. DESCRIPTION REQ’D DESCRIPTION REQ’D DRA13092 Main Frame Rockshaft DRA13093 L.H. Narrow and Wide Wing Rockshaft - 41" (used after Sept/01) DR118...
  • Page 60 MODEL 4600 DISC ROCKSHAFT & WHEEL ASSEMBLY (AUSTRALIA ONLY) REF. PART. QTY. REF. PART. QTY. DESCRIPTION REQ’D DESCRIPTION REQ’D DRA13107 Main Frame Rockshaft (Australia Only) BW20010618F 2" O.D. x 1-1/16" I.D. x 3/16" (50.8mm x 26.9mm x 4.6mm) Flatwasher DRA13108 L.H.

  • Page 61: Hydraulic Assembly - Narrow Wing

    MODEL 4600 DISC HYDRAULIC ASSEMBLY - NARROW WING REF. PART. QTY. REF. PART. QTY. DESCRIPTION REQ’D DESCRIPTION REQ’D 4" x 24" (101.6mmx 610mm) Hydraulic Cylinder P4336 3/8" x 24" (9.39mm x 610mm) Hydraulic Hose c/w 3/8" 3-1/2" x 24" (88.9mm x 610mm) Hydraulic Cylinder (9.39mm) End &...

  • Page 62: Hydraulic Assembly - Wide Wing

    MODEL 4600 DISC HYDRAULIC ASSEMBLY - WIDE WING REF. PART. QTY. REF. PART. QTY. DESCRIPTION REQ’D DESCRIPTION REQ’D 4" x 24" (101.6mmx 610mm) Hydraulic Cylinder P4342 3/8" x 20" (9.39mm x 508mm) Hydraulic Hose c/w 3/8" 3-1/2" x 24" (88.9mm x 610mm) Hydraulic Cylinder (9.39mm) End &...
  • Page 63 MODEL 4600 DISC DISC GANG (WITH STANDARD HANGERS FOR EZ410N BEARINGS) - 9" & 10-1/2" (230mm & 267mm) SPACING (used on earlier Models Only) REF. PART QTY. REF. PART QTY. DESCRIPTION REQ'D DESCRIPTION REQ'D DG76 24" (610mm) x 9/32" (7mm) Plain Blade GANG BOLT FOR 9"...
  • Page 64 MODEL 4600 DISC DISC GANG (WITH STANDARD HANGERS FOR T2-215 BEARINGS) - 9" (230mm), 10-1/2"(267mm) & 12" (305mm) SPACING (used with Hanger Mounted Scraper Bars - used prior to S/N 51463) REF. PART QTY. REF. PART QTY. DESCRIPTION REQ'D DESCRIPTION REQ'D Refer to Ref.
  • Page 65 MODEL 4600 DISC DISC GANG (WITH STANDARD HANGERS FOR T2-215 BEARINGS) - 9" (230mm), 10-1/2"(267mm) & 12" (305mm) SPACING (Independently Mounted Scraper Bar - used after S/N 51462) REF. PART QTY. REF. PART QTY. DESCRIPTION REQ'D DESCRIPTION REQ'D Refer to Ref. No. 1 on Page 63 for Plain Blades Refer to Ref.
  • Page 66 MODEL 4600 DISC STONE FLEX HANGER FOR EZ410N BEARINGS (OPTIONAL) (used on Earlier Models Only) REF. PART QTY. DESCRIPTION REQ'D DG5364 EZ410N Series Greaseable Bearing (1-9/16" (39.6mm) Wide) DG96 Housing - EZ410N Bearing DG5324 Standard Mounting Bracket For EZ410N Bearing DGA5376 1-1/2"...

  • Page 67: Stone Flex Hanger For T2-215 Series Bearings (Optional)

    MODEL 4600 DISC STONE FLEX HANGER FOR T2-215 SERIES BEARINGS (OPTIONAL) (Hanger Mounted Scraper Bar - used prior to S/N 51377) REF. PART QTY. DESCRIPTION REQ'D DGB9900 T2-215 Bearing Assembly (See Page 53 for T2-215 Bearing Breakdown) DGA10570 Standard Mounting Bracket DGA10575 2"...
  • Page 68 MODEL 4600 DISC STONE FLEX HANGER FOR T2-215 SERIES BEARINGS (OPTIONAL) (Independently Mounted Scraper Bar) REF. PART QTY. DESCRIPTION REQ'D DGB9900 T2-215 Bearing Assembly (See Page 53 for T2-215 Bearing Breakdown) DGA10570 Standard Mounting Bracket DGA10575 2" (50.8mm) Offset Mounting Bracket DCA10576 3-1/2"...
  • Page 69 MODEL 4600 DISC STANDARD SCRAPER AND SCRAPER BAR ASSEMBLY (Hanger Mounted Scraper Bar - used prior to S/N 51463 for Std Hangers and prior to S/N 51377 for Stone Flex Hangers) REF. PART QTY. DESCRIPTION REQ'D DG5300 Scraper - Front L.H. & Rear R.H. (5/16" (7.8mm) x 4" (101.6mm)) DG5301 Scraper - Front R.H.
  • Page 70 MODEL 4600 DISC HEAVY DUTY SCRAPER AND SCRAPER BAR ASSEMBLY (Hanger Mounted Scraper Bar - used prior to S/N 51463 for Solid Hangers and prior to S/N 51377 for Stone Flex Hangers) REF. PART QTY. DESCRIPTION REQ'D DG13010 Heavy Duty Scraper - 1/2" x 4" (12.7 x 101.6mm) - Front R.H. & Rear L.H.
  • Page 71 MODEL 4600 DISC STANDARD SCRAPER AND SCRAPER BAR ASSEMBLY (Independently Mounted Scraper Bar - used after S/N 51462 for Solid Hangers and after S/N 51376 for Stone Flex Hangers) REF. PART QTY. DESCRIPTION REQ'D DG5292 Scraper (Std) - Front L.H. & Rear R.H.
  • Page 72 MODEL 4600 DISC HEAVY DUTY SCRAPER AND SCRAPER BAR ASSEMBLY (Independently Mounted Scraper Bar - used after S/N 51462 for Solid Hangers and after S/N 51376 for Stone Flex Hangers) REF. PART QTY. DESCRIPTION REQ'D DG13215 Heavy Duty Scraper - 1/2" x 4" (12.7 x 101.6mm) - Front L.H. & Rear R.H.
  • Page 73 MODEL 4600 DISC WARNING LIGHT KIT (OPTIONAL) - (used 2001 and Prior) REF. NO. PART NO. DESCRIPTION QTY. REQ’D D13101 Light Bracket D13102 Backing Plate D13103 Light Mount Plate D13104 Light Fixture - L.H. Amber/Red (Amber on L.H.S.) D13115 Light Fixture - R.H. Red/Amber (Amber on R.H.S.) DG5308 1/2"...
  • Page 74 MODEL 4600 DISC WARNING LIGHT KIT (OPTIONAL) - (used 2002 to Sept. 2005) REF. NO. PART NO. DESCRIPTION QTY. REQ’D LK6403 Light Bracket LK6404 Backing Plate D13102 Light Mount Plate LK6422 Amber Lamp c/w Washers and Nut LK6401 Red Lamp c/w Washers and Nut DG5308 1/2"...
  • Page 75 MODEL 4600 DISC WARNING LIGHT KIT (OPTIONAL) - (used After Sept. 2005) REF. NO. PART NO. DESCRIPTION QTY. REQ’D LK6411 Light Bracket LK6422 Amber Lamp c/w Washers and Nut LK6401 Red Lamp c/w Washers and Nut BO50085 1/2" (12.7mm) x 8-1/2" (216mm) N.C. Hex Bolts (Plated) BN050 1/2"...
  • Page 76 MODEL 4600 DISC MAIN ROCKSHAFT CYLINDER - 4" (101.6mm) x 24" (610mm) CYLINDER - #306 REF. NO. PART NO. DESCRIPTION QTY. REQ’D 40TU10 Tube Assembly - 4" (101.6mm) x 24" (610mm) 10SH60 Shaft - 2" (50.8mm) x 24" (610mm) 10OR18 1"...
  • Page 77 MODEL 4600 DISC WING LIFT CYLINDER - 4" x 36" (102 x 914mm) CYLINDER - #248 - 5" x 36" (127 x 914mm) CYLINDER - #242 QTY. REQ’D REF. NO. PART NO. DESCRIPTION Cyl. #242 Cyl. #248 50TU8 Tube Assembly - 5" x 36" (127 x 914mm) 40TU8 Tube Assembly - 4"...
  • Page 78 MODEL 4600 DISC MAIN ROCKSHAFT CYLINDER - 4-1/2" (114.3mm) x 24" (610mm) CYLINDER - #330 REF. NO. PART NO. DESCRIPTION QTY. REQ’D 45TU1 Tube Assembly - 4-1/2" (114.3mm) x 24" (610mm) 10SH60 Shaft - 2" (50.8mm) x 24" (610mm) 10OR18 1"...
