Summary of Contents for Club Cannon MICRO JET MKII
- Page 1 VERSION 1.0 User Manual AUG 2021...
-
Page 2: Table Of Contents
TABLE OF CONTENTS MICRO JET MKII INTRO ..............1 - OVERVIEW ..................1 - FEATURES ..................1 INCLUDED ITEMS ................2 SAFETY GUIDE .................3 - SAFETY RADIUS ................4 - SAFE MOUNTING .................5 HARDWARE OVERVIEW ..............6 - UNIT REAR ..................6 HARDWARE SPECIFICATIONS ............7 CO2 REQUIREMENTS ..............8 CO2 SETUP ..................9... -
Page 3: Micro Jet Mkii Intro
MICRO JET MKII INTRO Congratulations on your purchase of the Micro Jet MKII. This manual will provide an overview of the Micro Jet MKII’s functions, capabilities, and instructions for proper operation. If you have questions outside the scope of this manual, feel free to contact us directly. -
Page 4: Included Items
INCLUDED ITEMS The following items are included with the purchase of each Micro Jet MKII. If you need replacement items, contact Club Cannon, 888-804-8175 / info@clubcannon.com. MICRO JET MKII TRUE1 CABLE CO₂ HOSE Now with DMX Control 6’ Edison to True1 cord CGA-320 x Quick Connect 5 - CO₂... - Page 5 SAFETY GUIDE DANGER WARNING NOTICE CAUTION This icon signifies that severe This icon signifies that severe This icon signifies that mild This icon signifies product bodily harm or death will bodily harm or death may to moderate injury may malfunction or damage may occur if instuctions are not occur if instructions are not occur if instuctions are not...
-
Page 6: Safety Guide
SAFETY GUIDE SAFETY RADIUS The Micro Jet MKII can produce a plume of fog upwards of 30FT/9M. Images below outline the necessary safety radius, which must be observed at all times. 30FT 10FT 10FT 10FT 10FT Under no circumstance should any person or object be placed inside the displayed safety radius while system in under pressure. -
Page 7: Safe Mounting
SAFETY GUIDE SAFE MOUNTING TOTUM MOUNTING DMX ADDRESS • KEEP A SAFE DISTANCE FROM AUDIENCE • DO NOT SHOOT DIRECTLY AT PEOPLE • ONLY USE IN WELL VENTILATED AREAS • AFFIX BARREL SECURELY WITH WRENCH • NEVER PLACE OBJECTS IN BARREL •... -
Page 8: Hardware Overview
HARDWARE OVERVIEW UNIT REAR CLUB CANNON BARREL WITH BUILT IN SILENCER DMX ADDRESS ADJUSTMENTS DMX ADDRESS 3 CHARACTER • KEEP A SAFE DISTANCE FROM AUDIENCE VENT HOLES • DO NOT SHOOT DIRECTLY AT PEOPLE LED DISPLAY • ONLY USE IN WELL VENTILATED AREAS •... -
Page 9: Hardware Specifications
HARDWARE SPECIFICATIONS 9.11 3.11 9.13 6.00 5.00 WEIGHT: 6.85 LBs VOLTAGE: US - 110-220v AC 50-60hz 3.11 KGs EU - 220-240v AC 50-60hz DIMENSIONS: 8.5” x 5.88” x 6” CONSUMPTION: 25W MAX WITHOUT BARREL 215.9 mm x 149.35mm x 152.4mm CO₂... -
Page 10: Co2 Requirements
CO₂, which comes from a non-siphon CO₂ tank, will not create the desired fog effect. The siphon tube feeds the Club Cannon product liquid from the bottom of the tank, while a standard CO₂ tank draws gas from the top of the tank (see illustration). -
Page 11: Co2 Setup
After attaching and tightening all fittings, turn on your CO₂ tank and check for any leaks. If a leak is present, cease use immediately and contact Club Cannon. Trigger the unit each time you want to release CO₂. Note: After use, close the valve on the CO₂ tank. Clear the remaining gas through the product, depleting all pressure in the system. -
Page 12: Quick Start Dmx Guide
BOOT MICRO JET MKII The Micro Jet MKII accepts AC power through the TRUE1 connector on the rear of the product. Verify correct supply voltage prior to use. Incorrect voltage may cause damage to unit. Rated voltage is marked above the power inlet. -
Page 13: Quick Start Power Guide
INSERT POWER MODE ADAPTER The Micro Jet MKII includes a 1/4” TS mono plug that can be inserted into the 3 pin XLR port output. When inserted, jet will act as a power controlled jet when powered on until removed. -
Page 14: Home Screen
HOME SCREEN This unit features quick access to setting the DMX address. This is the default screen that is shown when the Micro Jet MKII is first powered on. DMX ADDRESS 001 . KEEP A SAFE DISTANCE FROM AUDIENCE DO NOT SHOOT DIRECTLY AT PEOPLE... -
Page 15: Purge Lines
LINES Line purging can be used as a convenience feature at the end of a show. To use this feature, DMX must be disconnected from the Micro Jet MKII. Before purging, warn anyone nearby. Press and hold 2 outer buttons. -
Page 16: Device Troubleshooting
Unit does not power on • Supplying incorrect voltage will cause permanent damage. • If issue persists, contact Club Cannon directly. No user serviceable parts inside. If your issue is not listed, or the suggested solution did not solve the issue, contact Club Cannon. -
Page 17: Included Warranty
WARRANTY INCLUDED The Micro Jet MKII includes a 1 year parts & labor warranty against manufacturer defects. Warranty does not cover damage caused by accident, misuse, abuse, alteration, or unauthorized repair. To make a warranty claim, contact Club Cannon directly. - Page 18 Page left blank intentionally.
-
Page 19: Terms & Conditions
When using the Products, make sure you are in an open field or a well-ventilated area and are at least fifteen (15) feet away from people or other living things. Never hold a Club Cannon® Product by the barrel, especially after it has been used as it becomes extremely cold. Once the Product is attached to the CO₂... -
Page 20: Contact Us
CONTACT CONTACT 874 Via Esteban STE B, San Luis Obispo, CA 93401 888-804-8175 info@clubcannon.com ● www.clubcannon.com © CLUB CANNON 2021...
