Table of Contents o i t i f i o i t i f i o i t o i t i f i o i t 7. Exterior Parts Identification 8. Interior Parts Identification 9. Actuator Nameplate information 10. Actuator Mounting Flange 11. - Page 3 NOAH ACTUATION CO.,LTD. 1. Caution Electrical shock hazard To avoid serious personal injury, property damage or death, turn off all power to the actuator before removing the cover. Before installation, verify the nameplate information to insure the correct model number and voltage of the actuator.
- Page 4 SERIES MANUAL 2. Storage The actuator must be stored in a clean, dry and temperature controlled area. The actuator shall be stored with the cover installed and with the conduit openings sealed. Storage must be off the floor. Care must be taken to guard the actuator from condensation during extreme temperature variation. The heater should be energized as soon as the actuator is installed.
- Page 5 NOAH ACTUATION CO.,LTD. 3. Actuator Specification The SA-series actuator has been designed for the automation of 90-degree rotating equipment. The actuator is well suited applications requiring a torque of less than 5kg·m, 9kg·m (50N·m, 90N·m). Typical applications are ball valves, butterfly valves and dampers.
- Page 6 SERIES MANUAL 4. Standard Specification Enclosure Weatherproof Enclosure IP67 Nema 4 and 6 Ambient Temperature -20℃ to +70℃ 120℃ / 1hr DC12V, DC24V, AC24V Power Supply AC110 / 220V 50/60Hz Limit Switches Open / Close + Dry Contact Open / Close Stall Protection Thermal Protection ( Open 120℃) Travel Angel...
-
Page 7: Exterior Parts Identification
NOAH ACTUATION CO.,LTD. 7. Exterior Parts Identification SA005, SA005L / SA009, SA009L Window Top Cover Cover Bolts Body ▼ Cable entries Manul Operation Earth SA005, SA009 SA005L, SA009L Base L-Wrench http://www.emico.co.kr... -
Page 8: Interior Parts Identification
SERIES MANUAL 8. Interior Parts Identification SA005, SA005L / SA009, SA009L Full Open,Close LED Lamp Auxiliary Contact Micro Switch Open Limit Switch Open Limit Switch Auxiliary Contact Close Limit Switch Close Limit Switch Indicator Terminal Condenser Motor Heater... -
Page 9: Actuator Nameplate Information
NOAH ACTUATION CO.,LTD. 9. Actuator Nameplate Information. Before Installation or use, verify the nameplate information to insure that you have the correct model number, voltage and options. ⓐ Type Torque Motor Supply ⓒ ⓑ ⓔ ⓓ S.N. ⓖ ⓕ WARNING Do Not Open When Energized ⓗ... -
Page 10: Actuator And Valve Assembly
SERIES MANUAL 11. Actuator and Valve Assembly ※ If the Valve is supplied by the user, the delivery is available after NOAH ACTUATION mounts the actuator to the valve and calibrates the limit switch settings. 11-1 Butterfly Valve Assembly 11-1-1 Confirm that the valve mounting dimensions match the actuator ISO mounting. - Page 11 NOAH ACTUATION CO.,LTD. 11-1-4 Secure the actuator and valve together using stud bolts and nuts or hex bolts. Firmly tighten the assembly and confirm that there is no gap between the actuator and valve. Overtightening the bolts to close the gap may dam- age the assembly.
- Page 12 Ball Valve Assembly ※ If the Valve is supplied by the user, the delivery is available after NOAH ACTUATION mounts the actuator to the valve and calibrates the limit switch settings. NOAH ACTUATION can also provide a complete valve mounting kit if required.
- Page 13 NOAH ACTUATION CO.,LTD. 11-2-3 Remove the manual over ride lever provided on the actuator base, and with power off, open the actuator counter-clockwise. Also, open the valve that is to be mounted. L-Wrench 11-2-4 Apply a light coating of grease to the valve stem and actuator drive.
- Page 14 SERIES MANUAL 11-2-5 Secure the actuator and valve together using stud bolts and nuts or hex bolts. Firmly tighten the assembly and confirm that there is no gap between the actuator and valve. Overtightening the bolts to close the gap may damage the assembly. Confirm that the valve stem and mounting bolts are Mount the valve Bolts...
- Page 15 NOAH ACTUATION CO.,LTD. 12. Actuator Installation When installing an actuator, proper clearance around the actuator is required to ensure that the cover can be removed to allow for maintenance. Model A(mm) SA005 SA005L SA009 SA009L Ground 13. Limit Switch Setting...
- Page 16 SERIES MANUAL 14. Indicator Setting The position of the valve is indicated by the visual dome indicator. Bolt Window Indicator LED Lamp LED lights illuminate to allow for easy visual confirmation of valve position. ※ If the position of the indicator is not aligned correctly, an adjustment can be made by simply loosening the bolt and manually turning the indicator to the proper location, then re-tightening the bolt.
- Page 17 NOAH ACTUATION CO.,LTD. 16. Electric Wiring 16-1 Remove the actuator cover by loosening the four captive cover bolts. 16-2 Confirm that the wiring diagram located in the actuator and the wiring number on the nameplate match with each other. 16-3 Confirm that the main power and supply described on the nameplate of the actuator match with each other.
-
Page 18: Warranty Information
In addition to the above described mechanical / electrical failures, other causes may be the reason for a failure based on the site conditions. For more information please contact NOAH ACTUATION for consultation. For faster service, please have all of the nameplate information available when calling the factory. - Page 19 NOAH ACTUATION CO.,LTD. 20. Dimension SA005, SA009 14 DP25 Base P.C.D A: ISO5211 F03 (Φ36 M5TAP DP9) B: ISO5211 F05 (Φ50 M6TAP DP11) C: ISO5211 F07 (Φ70 M8TAP DP13) Drive Insert (Option) MANUAL OPERATION SA005L, SA009L 14 DP25 Base P.C.D A: ISO5211 F03 (Φ36 M5TAP DP9)
