- Page 1 Digital Display User Manual (DDT; DAB; DDW)
-
Page 2: Table Of Contents
Contents Remote Control General Setting Play Setting Subtitles Setting Clock Setting Display Setting Storage Manage Clone Parameters With USB Additional... -
Page 3: Remote Control
User Manual Remote Control keys Power Power on and off Mute Silence the totem Fast-forward by 3 seconds Fast rewind by 3 seconds PLAY/PAUSE Move the pointer up Move the pointer left Move the pointer right Move the pointer down Menu Enter settings menu Vol +... -
Page 4: General Setting
Setting Menu The main menu is as follows: General Setting... -
Page 5: Play Setting
1. OSD language: Choose the language you wish the totem to display. English: the language is English Korean: the language is Korean 简体中文: the language is simplified Chinese 繁体中文: the language is traditional Chinese 2. Local ID: To set the ID of the machine, press the menu key then use the up and down keys to change the number. - Page 6 1. Photo Show Time: Set the amount of time before changing into the next picture when displaying a slideshow. 2. Play Type: a. Picture: Only play the picture files from the root of the catalogue. b. Picture-Music Sync: Play the pictures with the background music repeatedly.
-
Page 7: Subtitles Setting
Choose the Split Mode: a. User: play the split file in the “split” folder which has been created by the split tool. b. Mode1-Mode4: Choose from the four pre-designed split modes shown when selected. The maximum amount of images that can be shown is five at any one time. -
Page 8: Clock Setting
6. Subtitles Position: Show subtitles at the top, in the center or at the bottom of the screen. Clock Setting 1. Time Setting: Set the time of the machine and press “Save The Time” to update. 2. Time Position: Set the time display position on the screen. 3. - Page 9 f. Prohibit Manual Off: Prohibit power off in IR & keypad when the timer is on. Within Timer 1-5 Settings: a. Timer mode: Set when you wish the timer to be active. If this is set to off, the timer will be disabled.
-
Page 10: Display Setting
b. Power on timing: Set the time for the totem to power on. c. Power off timing: Set the time for the totem to power off. Note: The power off time should be longer than power on time. The time options should be in order, from the earliest to the latest time. -
Page 11: Storage Manage
a. Brightness: Adjust the brightness. b. Contrast: Adjust the contrast. c. Saturation: Adjust saturation levels. d. Sharpness: Adjust sharpness levels. e. Colour Temperature: Select the colour temperature. Storage Manage... - Page 12 1. File Manage: This allows you to view the files in storage. Use the remote to navigate and select a file. Press the play button to play the file or DEL to delete the file. 2. Update Storage: a. Del.Old Files: Delete the files in storage then copy new files from the USB.
-
Page 13: Clone Parameters With Usb
a. The max size of “T10_PLAYLOG.TXT” is 100MB, if the file is larger than 100MB, “T10_PLAYLOG.TXT” will be deleted and it will record again. You can delete the log file or export it to USB. b. Export play log file: Make a file named “T10_EXPORT_PLAYLOG.TXT” on your USB, then connect the USB to the machine, choose “export play log”... -
Page 14: Additional
Additional Scroll caption making Make a file named SCROLL.TXT (in capitals), copy the display contents into the file, which must support 450 characters, then “save as” with the same name, mentioning that the coding is “UTF-8”. Usb Copy & File requirements The file name can contain numbers (0-9), capital letters and lowercase letters. - Page 15 5. Password Setting: Set a user password. a. Password Setting: If set to on, it will show an input password window when first operating the machine. The system will be locked again after three minutes of no usage and you will be required to re- enter the password.
- Page 16 File Formats Photo Format: Format Max resolution Colour Size Attribute jpg/jpeg 1920*1080 <8M Baseline standard 1920*1080 <8M No interleaving Audio Format: mp3, wav, wma, mp2 Video Format table: Extension Video Resolution Frame Audio name Format Rate Rate Mpeg4 1920*1080 25fps 18M/s Mp2,Mp3 Divx3,4,5,6...
