REV.247 REV1200 Assembly Manual

PACKING LIST
Frame
Column
Long feet
End pipe
Outer pipe
Connection pipe
Cable clamp
Rubber grip
Rubber washer
Hole cap
Screws
Screw for motor house / Outer pipe, M6x16mm
Screw for feet, M10x16mm
Tailstock for connection pipe, M10x20mm
Screw for tabletop, Ø5x20mm
Screw for hand control, Ø4x22mm
Tightening torque
Tailstock
Screw for motor house and outer pipe
Screw for feet and tabletop
Screw for hand control
Make sure all screws are tightened, also after a period of use!
Reset the desk before use
Press both up and down buttons at the same time for 3 seconds.
Continue pressing the buttons until both columns are in lowest
position. When finish reset, the control box makes a sound and
the buttons can be released. Now the system is operational.
WARNING
Carefully arrange all the cables not to be damaged by tabletop
screws.
PACKING LIST
pcs Frame
2 Column
2 Short feet
2 Short Outer pipe
4 Outer pipe
2 Connection pipe
8 Cable clamp
4 Rubber grip
18 Rubber washer
4 Hole cap
pcs Control box / Hand control
8 AC cable
8 Motor Extension cable
8 Hand control
14 Control box
2 Screws
Screw for motor house / Outer pipe, M6x16mm
Screw for feet, M10x16mm
Maximum 6Nm Tailstock for connection pipe, M10x20mm
Maximum 10Nm Screw for tabletop, Ø5x20mm
Screw for control box, M4x6mm
Maximum 10Nm
< 6Nm
Step 1
www.rev-247.com | 800.743.7738
REV1200 - ASSEMBLY MANUAL
pcs
Step 2
1
1
2
2
2
6
2
6
2
pcs
1
Step 3
1
1
1
pcs
4
4
6
8
2
Step 4
1
