REV.247 REV900 Assembly Manual

PACKING LIST

Frame
Column
Short feet
End pipe
U shape end pipe
Outer pipe
Connection pipe
Cable clamp
Rubber grip
Rubber washer
Hole cap
Control Box / Hand control
Hand control
AC cable
Motor extension cable

Screws

Screw for motor house / Outer pipe, M6x16mm
Screw for feet, M10x16mm
Screw for tabletop, Ø5x20mm

Tightening torque

Tailstock
Screw for motor house and outer pipe
Screw for feet and tabletop
Screw for hand control
Make sure all screws are tightened, also after a period of use!
Reset the desk before use
Press both up and down buttons at the same time for 3 seconds.
Continue pressing the buttons until both columns are in lowest
position. When finish reset, the control box makes a sound and the
buttons can be released. Now the system is operational.
WARNING
Carefully arrange all the cables not to be damaged by tabletop screws.
pcs

Step 1

1
1
1
1
2
2
4
2
9
2
pcs
1

Step 2

1
1
pcs
4
4
9
Maximum 6Nm
Maximum 10Nm
Maximum 10Nm
< 6Nm
Step 4
www.rev-247.com | 800.743.7738
REV900 - ASSEMBLY MANUAL
Step 3
Step 5
5A
5B
1
