Description of the Wi-Fi relay

A member of the Smart4house product family, the Wi-Fi relay is designed for remote control of

one or more devices with inputs for potential-free contacts, viz. via the Smart4house application

in your Smartphone or tablet. Requests for output relay connection/disconnection are

transmitted from the Smartphone/tablet to the cloud, from where they are transmitted to the Wi-

Fi relay through your AP – Access Point and the Wi-Fi 802.11b/g/n network. The same path is

then used by the Wi-Fi relay to send information about implementation of the request. The Wi-Fi

relay is equipped with a pair of output relays with switching contacts. The output relay status is

indicated by LED controls. The output relay either may be operated in the on/off mode or a 1-

second switch-on pulse may be generated. The information transmitted is secured by

encryption.

Two Wi-Fi relay versions differing in their power supply are marketed:

a) Model S4H-RE-00:

a) Model S4H-RE--10:

Note: The source for powering from USB is not included in the delivery.

Installation manual

Fasten Wi-Fi relay 1 to a dry, smooth and firm surface with 2 screws and wall plugs (included in

the delivery) or with a double-sided adhesive tape. To access the holes for the screws, remove

cover 2 by sliding it in the direction of the arrow. Connect the device to be controlled to the Wi-Fi

relay via screw terminals in terminal box 3.

Wi-Fi relay electronics include components which are susceptible to

electrostatic charge. Do not touch any component except the terminal box

screws and the initialising button when installing the product.

S4H-RE-00, S4H-RE-10

Wi-Fi Relay

Models S4H-RE-00, S4H-RE-10

Installation and Operating Instructions

powered with 5 VDC from a Micro B USB

powered from a 12-24 V AC/DC supply

Need help?

Do you have a question about the Smart4house RE-00 and is the answer not in the manual?

Questions and answers

Summary of Contents for SPEL Smart4house RE-00

Page 1 Wi-Fi Relay Models S4H-RE-00, S4H-RE-10 Installation and Operating Instructions Version for Smartphones and tablets with iOS operating system Description of the Wi-Fi relay A member of the Smart4house product family, the Wi-Fi relay is designed for remote control of one or more devices with inputs for potential-free contacts, viz. via the Smart4house application in your Smartphone or tablet.
Page 2 S4H-RE-00 S4H-RE-10 The Wi-Fi relay must be located within the reach of the AP/router (Access Point) signal with which the relay will communicate and to which it will be configured. Test the AP signal quality in the future Wi-Fi relay location on the Wi-Fi communication screen of your smartphone/tablet. The Wi-Fi relay should be located at a well accessible site for easy initialisation, in areas with no water vapour condensation, temperature 0°C to 50°C (32°F to 122°F).
Page 3 Connect the devices to the Wi-Fi relay via terminal box 3. RE-00 Connect the external 5 VDC power supply to the relay via Micro B USB and plug the supply to the RE-10 network Connect the 12 – 24 V AC/DC power supply voltage to terminal box 4, terminals 9-10. The output relays are fitted with break-make contacts: NO means that the contact is open in the rest state.
Page 4 You will need the Wi-Fi relay's MAC address for setting the relay up: you will find this information (twelve-character combination of digits and letters), identified as Device MAC, on the label inside the removable cover 2. You will also need the name of your home network (SSID) and the password to your Wi-Fi network.
Page 5 3.2.b. Enter the name of your Wi-Fi relay in the Enter device name box. It is advisable to select a name identifying the location (e.g. boiler room, garage …), or the system controlled by the relay (gate, pump …). Enter the WiFi relay MAC address (see 3.1) in the Enter MAC box and click Save.
Page 6 3.3. Wi-Fi relay initiation LED 1 – orange, indicates closing of Re1 (first relay) LED 2 – orange, indicates closing of Re2 (second relay) LED 3 – multicolour (red, orange, green), its illumination/colour indicate the relay initialisation steps and Wi-Fi relay connection status during use Tl 1 –...
Page 7 Now return to the application by clicking on the icon and press Next to view the next screen Connection of the Wi-Fi relay to your smartphone/tablet is indicated by LED 3 flashing red. The duration of this connection is limited to 3 minutes, during which you must send the initialisation data from your smartphone/tablet to the Wi-Fi relay.
Page 8 LED 3 lights during RE initialization: 3.3.b. The relays can be controlled from this screen. No background colour button means that the relay is OFF. The button with green background informs about the current status – the second relay is ON. symbol next to the 1: button informs us that this relay is set to the pulse mode.
Page 9 3.3.c. The mode of the given relay can be selected here. Normal is the ON/OFF mode. In the Pulse mode the relay generates a 1-second pulse on pressing the activation button on screen 3.3.b. The active mode is indicated by blue background. Note: The relay must be off to be switched to the pulse mode.
Page 10 3.3.d. Open this screen to view the control history and current status of the outputs. The pulse generation time is displayed if the output is in the pulse mode. 3.3.e. Use this screen to change the device name or to pass to the screen for Wi-Fi AP setting reconfiguration.
Page 11 4.a. Click on the Settings icon on the bottom bar. 4. b. Click on Email notification to get to the next screen. 4.c. This screen enables you to enable/disable sending notifications by e-mail and, if you wish, remove your e-mail address from the cloud.
Page 12 4.d. To remove your e-mail address from the cloud, enter your e- mail address and press Remove. You will receive a confirmation message in your e-mail box. Use the link in it to remove your address from the cloud. This e-mail address removal procedure should be used in situations involving reinstallation of the application or replacement of your smartphone/tablet.
Page 13 Notes 6.1. The Wi-Fi relay maintains constant connection to the cloud for its performance. This connection uses many tools that are beyond your view control and can suffer from failures with various durations (AP, Ethernet, servers, etc.). If the Wi-Fi relay connection to the cloud is lost, the Wi-Fi relay will pass to its safe state: the output relays are either switched off or remain in the last state selected (see setting 3.3.c).
Page 14 The orange circle around the button symbol will flash if a relay status change request is sent. This flashing will stop once the execution of the request is acknowledged. A green backlit button indicates that the relay is ON. If the button is pressed now, the reverse sequence will run.
Page 15 8.1. Overview of Wi-Fi relay states and LED 3 lights Colour Light Meaning Mode Orange Illumin. Wi-Fi relay attempts to connect to AP Initialisation/operation Orange Flashing Wi-Fi relay establishing connection to AP Initialisation Illumin. Wi-Fi relay formed AP S4H for 3 min Initialisation Flashing Data transmission from smartphone to...
Page 16 In case of any trouble contact the manufacturer at www.smart4house.net 12.a. Technical data: Wi-Fi relay model S4H-RE-00, USB power supply SPEL a.s., Třídvorská 1402, 280 00 Kolín, Czech Republic Manufactured by: Size: 90 x 103 x 21 mm (3.54 x 4.06 x 0.82 in) Weight: 90 g (3.6 oz.)
Page 17 12. b. Technical data: Wi-Fi relay model S4H-RE-10, 12 – 24 V AC/DC power supply SPEL a.s., Třídvorská 1402, 280 00 Kolín, Czech Republic Manufactured by: Size: 90 x 103 x 21 mm (3.54 x 4.06 x 0.82 in) Weight: 90 g (3.6 oz.)
Page 18 a) CE Declaration of Conformity. b) ABEGU test report No. P/13/01/51. c) The Wi-Fi relay meets FCC requirements, certificate QOQWF121. d) The Wi-Fi relay meets IC requirements, certificate 5123A-BGTWF121. Photograph of the product S4H-RE-00, S4H-RE-10...
