- Page 1 MANUAL DE USUARIO Serie Deslizables GPST www.frimax.mx...
-
Page 2: Table Of Contents
ÍNDICE INFORMACIÓN GENERAL RECOMENDACIONES DESCRIPCIÓN Y OPERACIÓN DE LOS CONTROLES DISPOSITIVOS DE SEGURIDAD ATENCIÓN AL DESLIZAR ASEGURAR LA CARGA CAPACIDAD CARGA DEL CAMIÓN TRANSFERENCIA DE CARGA DE UN VEHÍCULO A OTRO REPARACIÓN DE ELEMENTOS DE RODAMIENTO... -
Page 3: Información General
INFORMACIÓN GENERAL General information You have decided to purchase a top Slidelift. The Maxon Slidelift is very easy to use and to maintain. It is equipped with maintenance and grease-free bearings, and does not require greasing throughout its entire lifetime. The Maxon Slidelift is only to be used for lifting and lowering of loads, which have to be placed on the platform in accordance with the loading diagram. -
Page 4: Recomendaciones
RECOMENDACIONES Recommended checks and maintenances every year: 1. Oil change. Clean oil suction filter and air breather filter. Fill up with recommended oil. 2. Hydraulic hoses. Change every four years, or if damages appear. 3. Electric motors. Check carbon brushes, and clean with compressed air. 4. -
Page 5: Descripción Y Operación De Los Controles
DESCRIPCIÓN Y OPERACIÓN DE LOS CONTROLES Switching on the "Slidelift" A key switch is located in the control panel and must be pushed in prior to operating lift. Control panel Using the control panel, both hands must be used to operate. SLIDE-OUT SLIDE-IN TILT-UP... - Page 6 DESCRIPCIÓN Y OPERACIÓN DE LOS CONTROLES The foot controls are connected so that they only work when pushed in a specific order. To lift and tilt up Step 1 - activate foot control button for lowering Step 2 - activate foot control button for lifting To lower and tilt down Step 1 - activate foot control button for lifting Step 2 - activate foot control button for lowering...
- Page 7 DESCRIPCIÓN Y OPERACIÓN DE LOS CONTROLES Switching on the "Slidelift" A key switch is located in the control box and must be pushed in prior to operating lift. Control Box Using the control box, both hands must be used to operate control box.
-
Page 8: Dispositivos De Seguridad
DISPOSITIVOS DE SEGURIDAD Riding on the platform As only one person at a time is allowed to ride on the platform, the operator must ensure to avoid any endangering of other persons (especially children) while operating the Slidelift. Description of the security devices Hose bursting valves If a hose, a tube or a fitting should burst, the lift will lower in a controlled manner, without exceeding the maximum allowed speed, as long as one of the functions of the hand control box is... -
Page 9: Atención Al Deslizar
ATENCIÓN AL DESLIZAR Parallel to the sliding fram No contact between sliding frame and platform Contact sliding frame overloaded Riding on the platform When loading the platform, please leave enough space to ensure that the operator can ride and operate the platform safely. -
Page 10: Asegurar La Carga
ASEGURAR LA CARGA Rolling and shifting loads must be secured on the platform. On request, Maxon Slidelifts can be equipped with cart stops, securing rolling loads with the Security instructions when operating the Slidelift Securing the loads Secure the loads against tipping and slipping! Caution at loading docks... -
Page 11: Capacidad
CAPACIDAD In addition to the operating instructions, the Slidelift loading diagram is also shown on its identification plate. The load's centre of gravity should be in the middle between the lift arms. The greater the distance of the load from the end of the flatbed, the lower the loading capacity. Model GPST 33 X1 inch... - Page 12 CAPACIDAD In addition to the operating instructions, the Slidelift loading diagram is also shown on its identification plate. The load's centre of gravity should be in the middle between the lift arms. The greater the distance of the load from the end of the flatbed, the lower the loading capacity. The maximum loading capacity specified in the loading diagram must not be exceeded.
-
Page 13: Carga Del Camión
CARGA DEL CAMIÓN Loading from the truck or trailer onto the platform It is not possible to protect the Slidelift against loads brought from the vehicle to the platform, that are heavier than its rated capacity, nor against loads which are brought onto the platform at the wrong loading distance. - Page 14 CARGA DEL CAMIÓN Do not use a forklift. Only when the Slidelift is retracted under the vehicle. Despite the kind of loading performed, the vehicle has to be secured against unintentional movement (use hand brakes or wedges) Loading and unloading at a dock Only when the Slidelift is retracted under the vehicle.
-
Page 15: Transferencia De Carga De Un Vehículoa Otro
TRANSFERENCIA DE CARGA DE UN VEHÍCULO A OTRO Load transfer from one vehicle to another During load transfer, do not use the platform as a bridge plate. Service, maintenance, verification and repair Before starting any maintenance work, the Slidelift must be secured against unforeseen movement. -
Page 16: Reparación De Elementos De Rodamiento
REPARACIÓN DE ELEMENTOS DE RODAMIENTO Repairing bearing elements Repairs on bearing elements of the Slidelift can only be performed in an authorized service dealer, must be verified by an expert and have to be recorded in the control book. Defective under ride energy absorbers can not be repaired and must be replaced. For any malfunctioning, first check voltage level Troubleshooting Problem... - Page 17 REPARACIÓN DE ELEMENTOS DE RODAMIENTO Problem possible cause 5. Slidelift tilts down Switch S4 does not respond instead of lowering. Cable defective Mechanical damage at lift cylinder Solenoid valves on tilting cylinder defective 6. Platform tilts down alone without operating that function.
- Page 18 MANUFACTURA FRIO VAN SERVICIO TÉCNICO servicio técnico partes GARANTÍA VENT .frimax.mx...
