MANUAL DE USUARIO

Serie Ocultas

TE-20 TE-25 TE-30

www.frimax.mx

Table of Contents

Need help?

Do you have a question about the MAXON Ocultas TE-20 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Frimax MAXON Ocultas TE-20 Series

Page 1 MANUAL DE USUARIO Serie Ocultas TE-20 TE-25 TE-30 www.frimax.mx...
Page 2: Table Of Contents
ÍNDICE TABLE OF CONTENTS SUMMARY OF CHANGES: M-16-34 REV C ......4 WARNINGS ................5 RECOMMENDED DAILY OPERATION CHECKS ..... 7 DECALS ................... 10 FORKLIFT ADVISORY ............13 ROADSIDE OPERATION ADVISORY........14 OPERATION ................15 USING CART STOPS (IF EQUIPPED) ........21...
Page 3: Summary Of Changes: M-16-34 Rev C
ÍNDICE SUMMARY OF CHANGES: M-16-34 REV C PAGE DESCRIPTION OF CHANGE Cover Updated revison, date & copyright statement. Deleted references to TE-15 throughout manual.
Page 4: Warnings
ADVERTENCIA 1. Incorrect operation of this Liftgate can result in serious personal injury. Comply with WARNINGS and Liftgate operating instructions in this manual. Do not allow untrained persons or children to operate the Liftgate. If you need to replace an Operation Manual, additional copies are available from: MAXON Lift Corp.
Page 5 LIFTGATE TERMINOLOGY EXTENSION CONTROL PLATE LIFT SWITCH DOCK CYLINDER BUMPER FLEX STEP PLATFORM OPENER PARALLEL PUMP MAIN FRAME WEDGE FLIPOVER PLATFORM TORSION SPRING LIFT FRAME TE-25 OR TE-30 SHOWN FIG. 6-1...
Page 6: Recommended Daily Operation Checks
RECOMMENDED DAILY OPERATION CHECKS NOTE: Before you check the Liftgate, park vehicle on ﬂ at ground and set the parking brake. NOTE: If any of the following operation checks reveal a need to service or repair Liftgate, do not operate the Liftgate until a qualiﬁ...
Page 7 RECOMMENDED DAILY OPERATION CHECKS Check the hydraulic cylinders for leaking seals and hose connections. Follow the hydraulic hoses (or return lines for gravity down Liftgates) from the cylinders to pump box. Make sure all hoses are connected at both ends and there are no cracks, chaﬁ ng, and ﬂ uid leaks. With the platform at vehicle bed height and no load on platform, outboard edge of platform must...
Page 8 RECOMMENDED DAILY OPERATION CHECKS With the platform unfolded and on the ground, check if the shack- les and the tip of platform touch the ground at the same time as shown in the YES illustration SHACKLE (FIG. 9-1). If the platform looks TIP OF like the YES illustration, you FLIPOVER...
Page 9: Decals
DECALS NOTE: Ensure there is no residue, dirt or corrosion where decals are attached. If necessary, clean surface before attaching decals. NOTE: Preferred decal layout is shown, Decals on the Liftgate are attached at the factory. If vehicle does not permit this layout, decals in the manual and decal kit must be applied so that they are easily visible when approaching vehicle to operate Liftgate.
Page 10 DECALS SERIAL PLATE (REF) PARTS QR CODE DECAL P/N 299348-01 (TE-20) P/N 299348-02 (TE-25,TE-30) MAXON 24/7 SUPPORT DECAL P/N 298634-01 DECAL “F” DECAL “B” DECAL “A” FIG. 11-1 DECAL “C”...
Page 11 DECALS DECAL SHEET P/N 282522-01 FIG. 12-1 MODEL DECAL P/N CAPACITY TE-20 220387 2000 POUNDS (907 KG) TE-25 220382 2500 POUNDS [1134 KG] TE-30 220388 3000 POUNDS [1360 KG] CAPACITY DECALS TABLE 12-1...
Page 12: Forklift Advisory
FORKLIFT ADVISORY WARNING Keep Forklift OFF of Platform. FIG. 13-1...
Page 13: Roadside Operation Advisory
ROADSIDE OPERATION ADVISORY WARNING Operating the Liftgate by the side of a busy road with vehicle trafﬁ c increases the chance of personal injury and damage to Liftgate, cargo & vehicle. Making the loading area more visible to passing trafﬁ c can help reduce the chance of injury and damage. NOTE: MAXON recommends placing at least 2 trafﬁ...
Page 14: Operation
OPERATION WARNING Never operate control switch while unfolding (and folding) platform and ﬂ ipover. Always use handle on side of ﬂ ipover to unfold (and fold) ﬂ ipover. Holding the ﬂ ipover any other way can create a hazard and injure operator. 1.
Page 15 OPERATION 3. Unhook (if equipped) and unfold the ﬂ ipover as follows. If equipped with hook, press down on the ﬂ ipover and rotate hook away from the handle (FIGS. 16-1 and 16-1A). Then, use handle (FIG. 16-1B) to unfold the ﬂ ipover. FIG.
Page 16 OPERATION WARNING A load should never extend past the edges of the platform. Do not place unstable loads on platform and do not allow load to exceed the lifting capacity of the Liftgate. If standing on platform, do not allow your feet to extend beyond the inboard edge of the platform. 5.
Page 17 OPERATION WARNING Pulling the load from vehicle to platform can result in a fall from platform and serious injury. When unloading vehicle, always push the load out on the platform. 7. Load the platform at bed INBOARD height (FIG. 18-1) as fol- EDGE lows.
Page 18 OPERATION WARNING Never move the vehicle unless the Liftgate is properly stowed. NOTE: Platform raised off the ground makes it easier to grasp and fold the ﬂ ipover. 9. Before moving the vehicle, prepare the Liftgate as fol- lows. Make sure load is DOWN removed from platform.
Page 19 OPERATION 11. Use handle on bottom of plat- form (FIG. 20-1A) to lift and fold the platform and ﬂ ipover (FIG. 20-1). FIG. 20-1A FOLDING PLATFORM & FLIPOVER FIG. 20-1 12. Stow the platform (FIG. 20-2) by push- ing the toggle switch to the UP posi- tion (FIG.
Page 20: Using Cart Stops (If Equipped)
USING CART STOPS (IF EQQUIPPED) CAUTION To prevent injuries caused by tripping and falling, make sure cart stops are closed before walking on and off outboard end of platform. NOTE: Some Liftgates are equipped with single or dual cart stops. Cart stops prevent loaded carts from rolling off outboard end of platform.
Page 21 USING CART STOPS (IF EQQUIPPED) NOTE: Cart stops are opened by rotating the hook ROTATE TO (FIG. 22-1B). OPEN 2. Open cart stops (FIGS. 22-1 and 22-1A). Next, position cart and stand in the footprint area as shown in FIG. 22-1. HOOK OPENING CART STOPS (RH SIDE OF FLIP OVER)
Page 22 USING CART STOPS (IF EQQUIPPED) WARNING Pulling the load from vehicle to platform can result in a fall from platform and serious injury. When unloading vehicle, always push the load out on the platform. 4. When loading the platform INBOARD EDGE at bed level, make sure cart stops are open (FIG.
