Summary of Contents for HCC Technology POS80B
- Page 1 Thermal Printer Technical Manual POS80B Thermal Printer Technical Manual V 1.02 Shenzhen HCC Technology Co., Ltd. - 1 -...
-
Page 2: Table Of Contents
Thermal Printer Technical Manual Overview ........................... 5 Command format ........................5 Explanation of terms ......................... 5 ESC/POS Command Details ....................... 7 LF Print and feed one line ....................7 FF Print and feed paper to a black mark ................ 7 ESC FF Print data in buffer in page mode ............... - Page 3 Thermal Printer Technical Manual ①GS V m ②GS V m n Select cut mode and cut paper ..........40 DLE ENQ n Real-time request to printer ............... 41 DLE DC4 fn m t (fn=1) Generate pulse at real-time ............41 ESC = n Set peripheral device ..................
- Page 4 Thermal Printer Technical Manual Appendix B:Pre-printed black mark Description ..............70...
-
Page 5: Overview
Thermal Printer Technical Manual 1. Overview This manual contains all the general control commands for the below thermal printer models. It is about the use of various control commands and notes. However, different models have different specific parameters and functions, in this manual may not contain all of them. So please contact Our technical team if there were any questions or supports required. - Page 6 Thermal Printer Technical Manual Effective printing width It refers to the maximum printing width of the printer which depends on the printer itself. For example: for a 80mm paper width printer, its printing width is 72mm(576 dots), but for a 58mm paper width printer, the printing width can be 48mm(384 dots).
-
Page 7: Esc/Pos Command Details
Thermal Printer Technical Manual ESC/POS Command Details LF Print and feed one line [Name] Print and feed one line [Format] ASCII Decimal [Description] Prints the data in the print buffer and feeds one line, based on the current line spacing. [Notes] The command set the current position at the beginning of a line. -
Page 8: Cr Print And Carriage Return
Thermal Printer Technical Manual CR Print and carriage return [Name] Print and carriage return [Format] ASCII Decimal [Description] When the command is enabled, this command functions the same as LF; when disabled, this command is ignored. [Notes] Set the print starting position to the beginning of the line. The command is ignored with a serial interface model. -
Page 9: Esc L Select
Thermal Printer Technical Manual the horizontal motion unit (x) is used. Maximum paper feed amount is 1016 mm (40 inches). If you exceed this distance, using the maximum distance. [Reference] GS P [Example] char SendStr[10] = {0x31,0x32,0x33,0x1B,0x4A,0x60,0x34,0x35,0x36,0x0A}; SendData(SendStr, 10); ESC L Select page mode [Name] Select page mode [Format]... -
Page 10: Esc 3 N Set Line Height
Thermal Printer Technical Manual Decimal [Description] [Notes] Line height is independent in standard mode and page mode. [Reference] ESC 3 ESC 3 n Set line height [Name] Set line height [Format] ASCII Decimal [Range] 0 ≤ n ≤ 255 [Description] Set the line height to [n ×(vertical or horizontal motion unit)]. [Notes] Maximum amount is 1016 mm (40’’). -
Page 11: Esc % N Select/Cancel User-Defined Character Set
Thermal Printer Technical Manual Decimal [Range] 0 ≤ n ≤ 255 [Description] Select print mode(s) using n as follows: Decimal Function Standard ASCII font A (12 × 24) Compressed ASCII font B (9 × 17) Undefined. Emphasized mode not selected. Emphasized mode selected. -
Page 12: Esc & Y C1 C2 [X1 D1
Thermal Printer Technical Manual Decimal [Range] 0 ≤ n ≤ 255 [Description] Select or cancel the user-defined character set. When the LSB of n is 0, the user-defined character set is canceled. When the LSB of n is 1, the user-defined character set is selected. [Notes] When the user-defined character set is canceled, the internal character set is automatically selected. - Page 13 Thermal Printer Technical Manual When font B (9 ×17) is selected.
-
Page 14: Esc - N Turn Underline Mode On/Off
Thermal Printer Technical Manual ESC - n Turn underline mode on/off [Name] Turn underline mode on/off [Format] ASCII ESC - Decimal... -
Page 15: Esc ? N Cancel User-Defined Characters
Thermal Printer Technical Manual [Range] 0 ≤ n ≤2, 48 ≤ n ≤ 50 [Description] Turn underline mode on or off, based on the following values of n: Function 0, 48 Turns off underline mode 1, 49 Turns on underline mode (1-dot thick) 2, 50 Turns on underline mode (2-dots thick) [Notes]... -
Page 16: Esc G N Turn On/Off Double-Strike Mode
Thermal Printer Technical Manual [Range] 0 ≤ n ≤ 255 [Description] Turn emphasized mode on or off. When the LSB of n is 0, emphasized mode is turned off. When the LSB of n is 1, emphasized mode is turned on. Only the least significant bit of n is enabled. -
Page 17: Esc R N Select An International Character Set
Thermal Printer Technical Manual [Range] n = 0, 1, 48, 49 [Description] Select character fonts. Function 0,48 Select Standard ASCII Font (12 × 24) ,Chinese Font (24 × 24) 1,49 Select Compressed ASCII Font (9 × 17) , Chinese Font (16 × 16) [Default] n = 0 [Example]... -
Page 18: Esc T N Select Character Code Table
Thermal Printer Technical Manual [Format] ASCII Decimal [Range] 0 ≤ n ≤ 2, 48 ≤ n ≤ 50 [Description] Turns 90°clockwise rotation mode on/off .n is used as follows: Function 0,48 Turns off 90° clockwise rotation mode 1,49 Turns on 90° clockwise rotation mode 2,50 [Notes] This command is only valid in standard mode. -
Page 19: Esc { N Turn Upside-Down Print Mode On/Off
Thermal Printer Technical Manual reserve CP862 [Hebrew] ＷCP1252 Latin I WCP1253 [Greek] CP852 [Latina 2] CP858 Multilingual Latin Ⅰ+Euro) Iran II Latvian CP864 [Arabic] ISO-8859-1 [West Europe] CP737 [Greek] WCP1257 [Baltic] Thai 1 CP720[Arabic] CP855 CP857[Turkish] WCP1250[Central Eurpoe] CP775 WCP1254[Turkish] WCP1255[Hebrew] WCP1256[Arabic] WCP1258[Vietnam]... -
Page 20: Gs ! N Select Character Size
Thermal Printer Technical Manual When the LSB of n is 1, upside-down print mode is turned on. [Notes] Only the lowest bit of n is valid. This command is enabled only when processed at the beginning of a line in standard mode. When this command is input in page mode, the printer performs only internal flag operations. -
Page 21: Gs B N Turn White/Black Reverse Printing Mode
Thermal Printer Technical Manual This command is effective for all characters (ASCII and Chinese) except for HRI characters. If n is outside of the defined range, this command is ignored. In standard mode, the vertical direction is the paper feed direction, and the horizontal direction is perpendicular to the paper feed direction. -
Page 22: Esc C 5 N Enable/Disable Panel Buttons
Thermal Printer Technical Manual 哈哈哈 ESC c 5 n Enable/disable panel buttons [Name] Enable/disable panel buttons [Format] ASCII ESC c Decimal [Range] 0 ≤ n ≤ 255 [Description] Enable or disable the panel buttons. When the LSB of n is 0, the panel buttons are enabled. When the LSB of n is 1, the panel buttons are disabled. -
Page 23: Esc C 4 N Select Paper Sensor(S) To Stop Printing
Thermal Printer Technical Manual The command is available only with a parallel interface and is ignored with any other interfaces. Sensor is switched when executing this command. The paper end signal switching be delayed depending on the receive buffer state. If either bit 0 or bit 1 for n is on, the paper near-end sensor is selected as the paper sensor outputting paper-end signals If either bit 2 or bit 3 for n is on, the paper end sensor is selected as the paper sensor outputting... -
Page 24: Esc $ Nl Nh Set Absolute Print Position
Thermal Printer Technical Manual In standard mode, the printer prints the contents of the current line and places the print position at the beginning of the next line. In page mode, the printer will feed line and places the print position at the beginning of the next line. -
Page 25: Esc \ Nl Nh Set Relative Print Position
Thermal Printer Technical Manual ESC \ nL nH Set relative print position [Name] Set relative print position [Format] ASCII nL nH nL nH Decimal nL nH [Range] 0 ≤ nL ≤ 255 0 ≤ nH ≤ 255 [Description] • Moves the print position to [(the current position. •... -
Page 26: Gs L Nl Nh Set Left Margin
Thermal Printer Technical Manual This command executes justification in the printing area. This command justifies the space area according to HT, ESC $ or ESC \. [Default] n = 0 [Example] GS L nL nH Set left margin [Name] Set left margin [Format] ASCII nL nH... -
Page 27: Esc W Xl Xh Yl Yh Dxl Dxh Dyl Dyh Set Printing Area In Page Mode
Thermal Printer Technical Manual [Notes] This command is effective only when processed at the beginning of the line. In page mode, the printer performs only internal flag operations. This command does not affect printing in page mode. If the [leftmargin + printing area width] exceeds the printable area, the printer uses [Printable area width - left margin]. -
Page 28: Gs \ Nl Nh Set Relative Vertical Print Position In Page Mode
Thermal Printer Technical Manual If (horizontal starting position + printing area width) exceeds the printable area, the printing area width is automatically set to (horizontal printable area -horizontal starting position). If (vertical starting position + printing area height) exceeds the printable area,the printing area height is automatically set to (vertical printable area –... -
Page 29: Gs $ Nl Nh Set Absolute Vertical Print Position In Page Mode
Thermal Printer Technical Manual This command is ignored unless page mode is selected. When the movement downward: nL + nH x 256 = N When the movement upward: nL + nH x 256 = 65536 - N Any setting that exceeds the specified printing area is ignored. [Reference] ESC $, ESC T, ESC W, ESC \, GS $ GS $ nL nH Set absolute vertical print position in page mode [Name]... -
Page 30: Esc * M Nl Nh D1
Thermal Printer Technical Manual [Format] ASCII Decimal [Range] 0 ≤ n≤ 3, 48 ≤ n ≤ 51 [Description] Selects the print direction and starting position in page mode. n specifies the print direction and starting position as follows: [Notes] When the command is input in standard mode, the printer executes only internal flag operation. This command does not affect printing in standard mode. - Page 31 Thermal Printer Technical Manual Mode Vertical Direction Horizontal Direction Number Dot Density Number of Data Density Dots 8-dot 68 DPI 101 DPI nL + nH × 256 single-density 8-dot 68 DPI 203 DPI nL + nH × 256 double-density 24-dot 203 DPI 101 DPI ( nL + nH ×...
-
Page 32: Gs * X Y D1
Thermal Printer Technical Manual GS * x y d1...d(x × y × 8) Define downloaded bit image [Name] Define downloaded bit image [Format] ASCII d1...dk d1...dk Decimal d1...dk [Range] 1 ≤ x ≤ 255 1 ≤ y ≤ 48 x × y ≤ 800 0 ≤... -
Page 33: Gs / M Print Downloaded Bit Image
Thermal Printer Technical Manual [Reference] GS / GS / m Print downloaded bit image [Name] Print downloaded bit image [Format] ASCII Decimal [Range] 0 ≤ m ≤ 3, 48 ≤ m ≤ 51 [Description] Print a downloaded bit image using the mode specified by m. m selects a mode from the table below: Mode Vertical Dot Density (DPI) -
Page 34: Gs V 0 M Xl Xh Yl Yh D1
Thermal Printer Technical Manual [Description] This command is used to print the binary bit image which is specified by n and preloaded in the printer’s non-volatile memory. The binary bit image can be created and downloaded by tools on the PC. The printer nonvolatile memory bit image can be generated through a dedicated tool on the PC and writes, the maximum width of the bit image depends on the maximum width of the corresponding printer, bit image size is up to 64KB. -
Page 35: Dle Eot N Real-Time Status Transmission
Thermal Printer Technical Manual ESC a (Select justification) is also effective for raster bit images. d indicates the bit-image data. Setting bit to 1 for each byte means print this dot and setting it to 0 means do not print. [Example] When xL+xH´... - Page 36 Thermal Printer Technical Manual Fixed value is 0 Fixed value is 1 Drawer open/close signal is LOW (connector pin Drawer open/close signal is HIGH (connector pin On-line. Off-line. Fixed value is 1 Undefined. Fixed value is 0 n = 2: Off-line status Decimal Function Fixed value is 0...
-
Page 37: Gs A N Enable/Disable Automatic Status Back (Asb)
Thermal Printer Technical Manual [Reference] DLE ENQ, GS a, GS r GS a n Enable/Disable Automatic Status Back (ASB) [Name] Enable/Disable Automatic Status Back (ASB) [Format] ASCII Decimal [Range] 0 ≤ n ≤ 255 [Description] Enable or disable ASB and specifies the status items to include, using n as follows: Decimal Status for ASB Drawer kick-out connector pin 3 status... -
Page 38: Gs R N Transmit Status
Thermal Printer Technical Manual button. Fixed value is 0 Second byte (printer information) Decimal Printer Status Undefined. Undefined. Undefined. No auto cutter error. Auto cutter error occurred. Fixed value is 0 No unrecoverable error. Unrecoverable error occurred. No automatically recoverable error. Automatically recoverable error occurred. -
Page 39: Gs : Start/End Macro Definition
Thermal Printer Technical Manual [Range] n = 1, 2, 49, 50 [Description] Transmit the status specified by n as follows: Function 1, 49 Transmit paper sensor status 2, 50 Transmit drawer kick-out connector status Paper sensor status (n = 1, 49): Decimal Status 0, 1... -
Page 40: Gs ^ R T M Execute Macro
Thermal Printer Technical Manual definition. Macro is not defined when the power is turned on. The defined contents of the macro are not cleared by ESC @. Therefore,ESC @ can be included in the contents of the macro definition. If the printer receives GS : again immediately after previously receiving GS : the printer remains in the macro undefined state. -
Page 41: Dle Enq N Real-Time Request To Printer
Thermal Printer Technical Manual 1, 49 Partial cut ② Feed paper (cutting position + [n ´ (vertical motion unit)]) and full cut Feed paper (cutting position + [n ´ (vertical motion unit)]) and partial [Notes for ①and②] Cutting status is different, depending on the installed auto cutter type. This command is effective only when processed at the beginning of a line. -
Page 42: Esc = N Set Peripheral Device
Thermal Printer Technical Manual 1 ≤ t ≤ 8 [Description] Outputs the pulse specified by t to connector pin m as follows: Connector pin Drawer kick-out connector pin 2. Drawer kick-out connector pin 5. The pulse ON time is [t × 100 ms] and the OFF time is [t × 100 ms]. [Notes] When the printer is in an error status when this command is processed, this command is ignored. -
Page 43: Esc P M T1 T2 Generate Pulse
Thermal Printer Technical Manual • Contents stored in the NV user memory. • Contents defined for the NV graphics (NV bit image). • Maintenance counter value. • Setting values specified with the customized values (memory switches), GS ( E. ESC p m t1 t2 Generate pulse [Name] Generate pulse [Format]... -
Page 44: Gs P X Y Set Horizontal And Vertical Motion Units
Thermal Printer Technical Manual Not used. Fixed value is 0 Undefined. Undefined. Fixed value is 0 [Notes] When 1 ≤ n ≤ 3 or 49 ≤ n ≤ 51, the printer returns to single-byte ID When 65 ≤ n ≤ 69, return the following format: Header information: Hexadecimal = 5FH / Decimal = 95 (1 byte) Data: Printer Information NUL: Hexadecimal = 00H / Decimal = 0 (1 byte) - Page 45 Thermal Printer Technical Manual GS ( A pL pH n m Execute test print [Name] Execute test print [Format] ASCII pL pH n 41 pL pH n Decimal 65 pL pH n [Range] ( pL+ pH × 256)=2 (pL=2, pH=0) 0 ≤...
-
Page 46: Gs G 0 M Nl Nh Initialize Maintenance Counter
Thermal Printer Technical Manual Function 0, 48 DLE DC4 fn m t (fn = 1): Not processed (disabled). 1, 49 DLE DC4 fn m t (fn = 1): Processed (enabled). 0, 48 DLE DC4 fn a b (fn = 2): Not processed (disabled). 1, 49 DLE DC4 fn a b (fn = 2): Processed (enabled). -
Page 47: Gs G 2 M Nl Nh Transmit Maintenance Counter
Thermal Printer Technical Manual GS g 2 m nL nH Transmit maintenance counter [Name] Transmit maintenance counter [Format] ASCII nL nH 32 m nL nH Decimal 50 m nL nH [Range] m =0 (nL + nH × 256) = 20, 21, 50, 70, 148, 149, 178, 98 (nL = 20, 21, 50, 70, 148, 149, 178, 198 , nH = 0) [Description] Transmit the value of the maintenance counter specified by (nL + nH ×... -
Page 48: Fs & Select Chinese Character Mode
Thermal Printer Technical Manual Double-height mode is OFF. Double-height mode is ON. Undefined. Underline mode is OFF. Underline mode is ON. [Notes] When both double-width and double-height modes are set (including right- and left-side character spacing), quadruple-size characters are printed. The printer can underline all characters (including right- and left-side character spacing), but cannot underline the space set by HT and 90°... -
Page 49: Fs . Cancel Chinese Character Mode
Thermal Printer Technical Manual cannot underline the space set by HT and 90° clockwise-rotated characters. After the underline mode for Chinese characters is turned off by setting n to 0, underline printing is no longer performed, but the previously specified underline thickness is not changed. The default underline thickness is 1 dot. -
Page 50: Fs C N Select Chinese Character Code System
Thermal Printer Technical Manual FS C n Select Chinese character code system [Name] Select Chinese character code system [Format] ASCII Decimal [Range] n=0, 1, 48, 49 [Description] Select Chinese character code system Select Chinese character code system 0, 48 Simplified Chinese (GB2312 or GB18030) 1, 49 Traditional Chinese (BIG5) [Notes]... -
Page 51: Fs S N1 N2 Set Left- And Right-Side Chinese Character Spacing
Thermal Printer Technical Manual n = 1 Traditional Chinese models. FS S n1 n2 Set left- and right-side Chinese character spacing [Name] Set left- and right-side Chinese character spacing [Format] ASCII n1 n2 n1 n2 Decimal n1 n2 [Range] 0 ≤ n1 ≤ 255 0 ≤... -
Page 52: Gs H N Select Printing Position For Hri Characters
Thermal Printer Technical Manual FS ! or GS ! can also select and cancel quadruple-size mode by selecting double-height and double-width modes, and the setting of the last received command is effective. [Default] n = 0 [Reference] FS !, GS ! GS H n Select printing position for HRI characters [Name] Select printing position for HRI characters... -
Page 53: Gs H N Select Bar Code Height
Thermal Printer Technical Manual GS h n Select bar code height [Name] Select bar code height [Format] ASCII Decimal [Range] 1 ≤ n ≤ 255 [Description] Select bar code height n specifies the number of dots in the vertical direction. [Default] n = 60 [Reference]... - Page 54 Thermal Printer Technical Manual When the bar code system used is UPC-A or UPC-E, the printer prints the bar code data after receiving 12 bytes bar code data and processes the following data as normal data. When the bar code system used is JAN13 (EAN13), the printer prints the bar code after receiving 13 bytes bar code data and processes the following data as normal data.
-
Page 55: Gs W N Set Bar Code Width
Thermal Printer Technical Manual Example data for printing "No. 123456" In this example, the printer first prints "No." using CODE B, then prints the following numbers using CODE C. GS k 73 10 123 66 78 111 46 123 67 12 34 56 If the top of the bar code data is not the code set selection character, the printer stops command processing and processes the following data as normal data. -
Page 56: Gs Z N Select 2-D Code Type
Thermal Printer Technical Manual GS Z n Select 2-D code type [Name] Select 2-D code type [Format] ASCII Decimal [Range] 0 ≤n ≤ 2 [Description] Select 2-D code type n = 0 Select PDF417 n = 1 Select DATA MATRIX n = 2 Select QR CODE [Reference] ESC Z... -
Page 57: ①Gs K M V R D1
Thermal Printer Technical Manual ①GS k m v r d1...dn NUL ②GS k m v r nL nH d1...dn Print 2-D bar code [Name] Print 2-D bar code [Format] ①ASCII d1...dn d1...dn Decimal d1...dn ②ASCII GS d1...dn nL nH d1... dn Decimal nL nH d1... -
Page 58: Cpcl Command Details
Thermal Printer Technical Manual SendData(SendStr, 11); 5. CPCL Command Details START commands [Name] Start command ！ {offset} 200 200 {height} {qty} [Format] [Description] {offset}: offset of the whole barcode in horizontal direction 200: horizontal resolution，203dots/inch（8dots/mm） 200: vertical resolution，203dots/inch（8dots/mm） {height}: the max height of barcode, the unit is dot {qty}: the quantity of printed barcode, the most is 1024pcs. -
Page 59: Form Commands
Thermal Printer Technical Manual FORM Commands [Name] Positioning command [Format] {command} [Description] {command}: FORM After using FORM command, the printer will feed paper to the beginning of next label. The printer finds the beginning of next label according to the gap between two labels. -
Page 60: Line Commands
Thermal Printer Technical Manual LINE Commands [Name] Line printing command [Format] {command}LINE（L）{x0} {y0 } {x1} {y1} {width} [Description] {command}:LINE（or L） {x0}: X-coordinate of the top-left corner {y0}: Y-coordinate of the top-left corner {x1}: X-coordinate of: -top right corner for horizontal -bottom left corner for vertical {y1}: Y-coordinate of: -top right corner for horizontal... -
Page 61: Inverse-Text Commands
Thermal Printer Technical Manual SETBOLD 1 TEXT 24 0 0 0 This text is in bold SETBOLD 0 TEXT 24 0 252 0 But this text is normal. PRINT This text is in bold But this text is normal. INVERSE-TEXT Commands [Name] Inverse-text commands [Format]... -
Page 62: Underline-Text Commands
Thermal Printer Technical Manual INVERSE-LINE 0 95 145 95 45 PRINT UNDERLINE-TEXT Commands [Name] Underline-Text Command [Format] {command} {value} [Description] {command}：UNDERLINE -TEXT(or UT) {value} means to print underline or not 1：Print Underline One Dot 2：Print Underline Two Dot 0：Cancel printing underline [Example] ! 0 200 200 210 1 T 24 11 0 10 Normal... -
Page 63: Center Commands
Thermal Printer Technical Manual CENTER Commands [Name] Center Command [Format] {command} [Description] The content in current line to be showed in center LEFT Commands [Name] Left Command [Format] {command} [Description] The content in current line to be showed on the left RIGHT Commands [Name] Right Command... -
Page 64: Barcod-Text Commands
Thermal Printer Technical Manual POSTFEED EXAMPLE BARCOD-TEXT Commands [Name] HRI character command [Format] {command} {font number} {font size} {offset} [Description] {command}：BARCODE-TEXT(or BT) {font number}：HRI character font (Fixed to 12*24) {font size}：HRI character size (Fixed to original size) {offset}：Offset between HRI character and barcode. [Example] ! 0 200 200 210 1 BARCODE-TEXT 24 0 50... -
Page 65: 2D Barcode
Thermal Printer Technical Manual {data}:Barcode data [Example] ! 0 200 200 210 1 BARCODE 128 1 1 50 150 10 HORIZ. TEXT 24 0 210 65 HORIZ. PRINT 2D Barcode PDF417 [Format] {command} {type} {x} {y} {XD n} {YD n} {C n} {S n} {data} <ENDPDF>... -
Page 66: Graphics Commands
Thermal Printer Technical Manual type of the input data could be recognized automatically by printer software or set “manually”. There is a separator (comma) between mode selection symbols and the actual data. {data}format： <Error Correction Level><Mask No.><Data Input Mode (should be “A”)>,<Data character String>... -
Page 67: Appendix A: Code128 Code
Thermal Printer Technical Manual Since this data is character data, however, it can be easier to handle and transmit than binary data. [Example] ! 0 200 200 210 1 EG 2 16 90 45 F0F0F0F0F0F0F0F00F0F0F0F0F0F0F0F F0F0F0F0F0F0F0F00F0F0F0F0F0F0F0F PRINT 6. Appendix A: CODE128 code A.1 CODE128 code CODE 128 code passing alternate character sets A,B character set and character set C,capable of 128 and 100 ASCII characters from 00 to 99 digits, and some special characters are encoded.Each... -
Page 68: A.2 Character Set
Thermal Printer Technical Manual A.2 Character Set Characters of Character Set A Transmit Data Transmit Data Transmit Data Charact Characters Characters Decimal Decimal Decimal NULL & FNC1 7B,3 123,49 FNC2 123,50 < FNC3 7B,3 123,51 FNC4 123,52 > SHIFT 7B,3 123,83 CODEB 123,66... - Page 69 Thermal Printer Technical Manual Characters of Character Set B Transmit Data Transmit Data Transmit Data Charact Charact Charact Decimal Decimal Decimal " & 7B,7B 123,123 — FNC1 7B,31 123,49 FNC2 7B,32 123,50 FNC3 7B,33 123,51 FNC4 7B,34 123,52 SHIFT 7B,53 123,83 CODEA 7B,41...
- Page 70 Thermal Printer Technical Manual Characters of Character Set C Transmit Data Transmit Data Transmit Data Charact Charact Charact Decimal Decimal Decimal FNC1 7B,31 123,49 CODEA 7B,41 123,65 CODEB 7B,42 123,66 7. Appendix B:Pre-printed black mark Description...
- Page 71 Thermal Printer Technical Manual If you use pre-printed black mark to carry bill location, be sure to observe the following guidelines when printing pre-printed black mark,otherwise it may cause the printer does not recognize the black mark.Pre-printed black mark specification: Printing Position:As shown above,the black mark on the left edge of the text to be printed surface.
