- Page 1 QUICK START GUIDE www.electricbikecompany.com...
- Page 2 After you have unpacked your bike, please follow these steps to start using your Electric Bike Company Bicycle. Reminder: Before riding your bike, please read entire user manual. Locate the stem of the bike as shown in figure 1, which is near the handlebars and take off the stem bolt cap.
- Page 3 Locate the back of the handlebar clamp and loosen the 4 bolts as shown in figure 2. Use the 5 mm Allen key that came with your bike to loosen the bolts. Once the bolts are loosened, you will be able to set your handlebars to your desired position.
- Page 5 (Optional). If you wish to adjust the stem angle setting, locate the stem angle bolt as shown in figure 3. Use the 5 mm Allen key that came with your bike to loosen the bolt. Once loosened, you will be able to adjust the angle to your preference.
- Page 6 Turn the master switch on as shown in figures 5 - 7. Model C & S Model Y & M Model X...
- Page 7 Hold down the power button as shown in figure 8 for approximately 3 seconds to turn on the LCD screen conrtoller. The power button is located on the left side of the handlebars. Note: Remember the throttle is now live! Troubleshooting: Sleep Mode If battery has been left for a while it will automatically go into “sleep mode”.
- Page 8 X, and figure 12 for the Model R. The LED lights will turn red while charging and green once charging is complete. Note: You can remove the battery from the bike frame of the X & R models to charge it.
- Page 9 Model Y & M Model X Model R...
- Page 10 Method 1 to charge C & S models Locate the power cord on the left side of the rear rack battery case and extend it to plug into a 3-prong power outlet. Method 2 to charge C & S models Purchase the 3.5 amp supercharger to charge your bike.
- Page 11 Activateing Head and Tail Lights: To turn On and Off the head and tail lights, simply press and hold the Up arrow as shown in figure 8 for approximately 3 seconds until you see the display light up. Note: Nm stands for “Newton Metre”. Please use a torque wrench to fasten the bolts to the recommended Nm adjustment.
- Page 12 Thank You For Your Purchase Leave us a review at https://g.page/electricbikecompany/review?gm and earn a $25 gift certificate by sending a link to your review at info@electricbikecompany.com Send us your personalized referral code at info@electricbikecompany.com and earn a $50 check every time a person uses your referral code Quick Start Guide https://youtu.be/V6GH7EFrXwQ Watch the video above to get a brief overview of how to...
