- Page 1 REVELATION-40 LONG RANGE THERMAL IMAGING MONOCULAR OPERATION MANUAL Versions 10.0.26 / 13.0.27 / 13.0.28 IMPORTANT: Please read this manual in its entirety PRIOR to using this device!
-
Page 2: Thermal Imaging
WARNING: NEVER POINT THIS DEVICE DIRECTLY AT THE SUN OR ANY FIRE / HEAT SOURCE WITH TEMPERATURE OF OVER 500C/930F! DOING SO WILL PERMANENTLY DAMAGE THE THERMAL SENSOR AND WILL VOID ANY WARRANTY CLAIMS! SEE PAGE-14 FOR MORE DETAILS AND FOR VERY IMPORTANT CARE WARNINGS! THERMAL IMAGING: Let’s try to understand how this device works and what it can... -
Page 3: Operation
OPERATION: REVELATION-40 MONOCULAR... -
Page 4: Installing The Batteries
Glossary: 1 – Laser Rangefinder Lens 2 – Germanium Objective Lens (Protective Lens Cover) 3 – Distance Focusing Wheel 4 – Laser Rangefinder ON / Range Button 5 – Invert Button 6 – Zoom Button 7 – Micro-USB Connector (Protective Cover) 8 –... - Page 5 again, until the image is sharp and clear. Once the clear image is obtained, you no longer need to adjust the Ocular Ring, just rotate the Distance Focusing Wheel to adjust the distance to the object you are viewing. SUPER CONTROLLER FUNCTIONS: Your thermal monocular comes with a unique Super Controller (14), which allows for nearly instant image adjustment to the best possible brightness and clarity without having to enter the menu settings.
- Page 6 useful during high humidity, where normally level of image detail is poor. It is also useful when observing object at long distances and when utilizing Zoom function. DEVICE MENU NAVIGATION – IMPORTANT! 1. When long-pressed, the Super Controller activates the Main Menu 2.
- Page 7 See page-5 for GAIN adjustment. NOTE: this function is available via Super Controller and is normally adjusted without getting into Menu. 4. Display Brightness See page-5 for BRGT adjustment. NOTE: this function is available via Super Controller and is normally adjusted without getting into Menu.
- Page 8 1. Normal start – the video recording module is completely off until you press REC button (8), then the module starts, taking approximately 15-20sec between pressing the REC button and actual start of video recording. This mode allows you to save the batteries when video recording is not desired, such as simple terrain orientation.
- Page 9 17. LRF Reading Position This setting allows user to select where on screen the Laser Rangefinder reading is displayed. Two positions are available: Up and Down. 18. Distance Unit This setting allows user to select meters or yards as a distance measurement unit for rangefinder 19.
- Page 10 the same for day. Once day is adjusted, short-pressing the Controller returns to the main menu. 25. Time Set This setting allows the user to set the time, as it would appear on the video recording stamp. Switch between HH:MM:SS by short- pressing the Super Controller and adjust the time by rotating the Super Controller.
-
Page 11: Video Recording
white or light color with most of the background appearing in black or dark color. You may switch (invert) this setting by pressing the INVERT Button (5) once and then heat signatures will appear in dark color “BLACK HOT” on otherwise light color background. In addition, the unit also has options of 10 color palettes, each with invert option, which highlight heat signatures in various colors. -
Page 12: External Power Supply
expect batteries to discharge faster during active recording. If you plan to do extensive video recording during operation, it is advised to use an external 5V power bank with large capacity (over 10,000mA) and each USB output rated at least at 2V. Should the battery power get too low the video recording will automatically stop and warning message will appear advising that battery power is too low for video recording. - Page 13 next time you start the scope. NOTE: newer models may come with Automatic Bad Pixel Correction function, which does the process automatically. USB TRANSFER MODE: Pease read carefully! 1. Power the monocular. 2. Enter the main menu and select “USB Transfer Mode” (see also page- 7) –...
-
Page 14: Troubleshooting
be engraved on your device, but the number will match the serial number of your device). b) Enter default password: 12345678 c) Make sure your mobile device is disconnected from the usual Wi-Fi signal (such as home or office), which it normally connects automatically, as it may cause interruptions in video stream. - Page 15 THERMAL DEVICES ARE UNABLE TO SEE HEAT SIGNATURES IF THE OBJECT IS BEHIND ANY BARRIER THAT HAS REFLECTIVE NATURE, SUCH AS GLASS, THEREFORE YOU WILL NOT BE ABLE TO SPOT PEOPLE INSIDE A VEHICLE UNLESS THE WINDOWS ARE LOWERED DOWN, OR A PERSON STANDING BEHIND THE WINDOW IN A HOUSE OR IN SIMILAR SITUATIONS.
- Page 16 5. NEVER submerse the unit into water or use during heavy rain. TECHNICAL SPECIFICATIONS: Revelation-40 Imaging Sensor______ Hybrid Resolution 17µm with Image Enhancement Frame Rate ____________________________ 50 Hz Shutter-free / NUC-free Spectral Response _______________________________________ 8-14µm...
