- Page 1 The Air Mover INSTRUCTION MANUAL & INSTALLATION GUIDE Model : Z 425 L / Z475 L...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ITEMS PAGE No. 1. Important Safety Instructions………………………………………………………1 2. Parts & Accessories…………………………………………………………………2 3. Installation Guide……………………………………………………………………3-5 4. Remote Control & Operation……………………………………………………….6 4. Electrical Connection ……………………………………………………………….7 5. Circuit Diagram………………………………………………………………………8 6. Maintenance & Troubleshooting……..…………………………………………….9 7. Technical Specification ……………………………………………………………..10 8. Customer Service Contact …………………………………………………………10... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read Carefully and save this instruction prior to installation, operating your ceiling fan, maintenance and troubleshooting information. If you have further questions, please contact your nearest Le Vent dealers. CAUTION: Please observe the following to reduce the risk of fire, electrical shock, and serious bodily injuries to a person: - Installation and electrical wiring must be carried out by qualified person in accordance to all applicable codes and standards. -
Page 4: Parts & Accessories
PARTS & ACCESSORIES CONCRETE CEILING 220Vac,50Hz Power Wire Fan Blade Remote Balancing control with wall plug & Wire Cap Ceiling fan Blade x5 Upper & Lower Upper & Lower Canopy (Aria Model) Canopy (Gello Model) Motor, RF receiver, Screw & Spring Washer for Light &... -
Page 5: Installation Guide
INSTALLATION GUIDE WARNING: TURN OFF THE MAIN SWITCH AT THE DB (ELECTRICAL DISTRIBUTION BOX) STEP1: Mounting the Blades Align the holes to the motor. Fasten it with screws and washer provided. (As shown in Figure 1) Figure 1 STEP 2: a) Fixing the Ceiling fan to the ceiling hook (U Hook). - Page 6 b) Connect the Power wires to ceiling fan Power wire using the wiring cap Connect the Power cord’s Blue wire to N (Neutral), Brown wire to L (Live) and Yellow/Green wire to E (Earth) using the wiring cap provided. Make sure all the wires color is same as the other side of the. (As shown in Figure 3) CONCRETE CEILING 220Vac,50Hz Power Wire...
- Page 7 STEP 5: Install Decorative cover Gently place the two decorative cover together as shown in FIGURE 5, and adjust the height accordingly WARNING: Make sure both the decorative covers are place together firmly Figure 4...
-
Page 8: Remote Control & Operation
REMOTE CONTROL & OPERATION Pairing the remote control: 1、Turn on the power supply 2、Within 10 seconds, continue pressing the “FAN ON” button on the remote control until you hear a “BEEP” sound from the ceiling fan. 3、It is now paired and ready to use. 4、If you do not hear any “BEEP”... -
Page 9: Electrical Connection
ELECTRICAL CONNECTION WARNING: Do not use DIMMER or POWER REGULATOR to control this fan. -
Page 10: Circuit Diagram
CIRCUIT DIAGRAM PERIODICAL MAINTENANCE For preventive maintenance, please spend some times to inspect the fan annually to ensure it is safe and operating efficiently. - Check the safety cable; make sure it is still securely fastened. - Make sure all the mounting screws are securely fastened. - Make sure that the screw securing the fan blades and the motor are securely fastened. -
Page 11: Maintenance & Troubleshooting
TROUBLE SHOOTING Symptom Possible Solution Wobbles - Make sure that all the screws securing the blades are securely fasten - Make sure that all the blades are align properly - If you installed more than one fan, make sure that they are not too close to each other (minimum 2 meters apart) - If the blade is damaged, call up the service center for a replacement but there will be charges incur if found not due to manufacturing fault... -
Page 12: Technical Specification
TECHNICAL SPECIFICATIONS MODEL 425B1L 425B1N 475B1L 475B1N 425B2L 425B2N 475B2L 475B2NL Number of Blades Number of Speeds Blade Sweep (mm) 1067 1067 1194 1194 1067 1067 1194 1194 Motor Type Voltage (V/Hz) 170 - 240/50 - 60 Power (LED) W Power (Motor) W TECHNICAL SPECIFICATIONS MODEL...
