- Page 1 Wall Mountable UVC Air Purifier and HEPA Filter SKU: 201075 INSTRUCTION MANUAL DEVICE SPECIFICATIONS SIZE 13.1" x 5.1" x 11.7" WEIGHT 5.5 lbs POWER SUPPLY Plug and play hub 120V, 60 Hz POWER WATTAGE 8.5 W NOISE INDEX 53 dB APPLICATION AREA 107.6 –...
- Page 2 FEATURES Remote control. Smart tech features o Automatic air detection sensors o Double fan system o Time sleep function o Multi-layered filtration systems Fragrance box to insert fragrance of choice SAFETY PRECAUTIONS 1. Product is designed for use in houses or similar environments. Do not use outdoors. 2.
- Page 3 HOW TO WORK THE DEVICE DISPLAY PANEL This display is touch sensitive, so it only requires a light touch. As can be seen for the image above the setting that is selecting is illuminated. Start Up After connecting the power cord to the device and plugging into outlet, lightly press the On/Off button on the top left of the panel, to start the purifier To control air speed...
- Page 4 Remote Control The device also has a remote control that functions similarly to the panel. To remove the filter Disassemble the front panel 1. Hold the top of the panel with you left hand. 2. Place you right hand and the top edge of the front panel and pull the panel out to a 45- degree angle 3.
- Page 5 To Replace the Filter 1. Align the filter back into the slot. 2. Make sure the tabs on the filter are to the front. 3. Push the filter back into place. 4. Replace front panel into bottom tabs and press to close. PRODUCT MAINTENANCE PROBLEM POSSIBLE CAUSE...
