SP tools SP61009 User Manual

Battery load tester digital display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
AFTER SALES SUPPORT:
WWW.SPTOOLS.COM
IMPORTANT
ALL PERSONS WHO ARE TO USE THIS EQUIPMENT MUST THOROUGHLY READ
AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO OPERATION.
SP61009
BATTERY LOAD
TESTER
DIGITAL DISPLAY
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO
MANUAL FOR FUTURE
NOTE: Proof of purchase must be retained by
the customer as it will be required in the
event of a claim under warranty.
AUSTRALIA: Visit the website's contact page to get in
touch with your local service department.
INTERNATIONAL: Use the county selector to get in touch
with your service department in your country or region.
REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP61009 and is the answer not in the manual?

Questions and answers

Related Manuals for SP tools SP61009

Summary of Contents for SP tools SP61009

  • Page 1 USER MANUAL SP61009 BATTERY LOAD TESTER DIGITAL DISPLAY RETAIN THESE INSTRUCTIONS AND ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE NOTE: Proof of purchase must be retained by the customer as it will be required in the event of a claim under warranty.

  • Page 2: Table Of Contents

    CONTENTS Introduction Product Function Technical Specifications Intended Use. Scope of Delivery Safety Precautions & Warnings Tool Description. Operating Instructions Voltage Explanation Before Testing Product Set up Battery Test Battery Load Test Cranking Voltage Test Charging Voltage Test Cleaning & Maintenance Disposal &...

  • Page 3: Introduction

    INTRODUCTUCTION Product Function The SP61009 Load Tester / System Analyser Battery Load Test Uses a fixed resistive load (125 Amps) to quickly and accurately evaluate the battery’s ability to crank an engine. The tester draws current from the battery while measuring its voltage drop.

  • Page 4: Intended Use

    User Manual: Instructions on tool operations. • • SP61009 12v Battery Load Tester / Analyser Safety Precautions & Warnings To prevent personal injury or damage to vehicles and/or the Battery Analyser, read this instruction manual first and observe the following safety precautions at a minimum whenever working on a vehicle: Always perform automotive testing in a safe environment.

  • Page 5: Tool Description

    Put transmission in PARK (for automatic transmission) or NEUTRAL (for manual transmission) and make sure the parking break is engaged. Keep a fire extinguisher suitable for petrol / chemical / electrical fires nearby. Don't connect or disconnect any test equipment with ignition on or engine running. 10.

  • Page 6: Operating Instructions

    Operating Instructions If testing batteries of low-frequency use, it is necessary to cycle (charge and discharge) the battery several times before testing, normally 3-5 times will achieve a reliable test result. Only after cycling the battery can the chemical properties of the battery be restored. This is particularly important after long periods of no use.

  • Page 7: Before Testing

    Before Testing Before testing, use a wire brush (not included) and alkaline cleaner (not included) to clean the battery terminals, as any surface resistance on the terminal could adversely affect the test result. Before testing an in-vehicle battery, ensure the ignition key is turned off. Make sure there is no power drain from any other vehicle electronics and keep the car doors closed so interior lights do not illuminate.

  • Page 8: Battery Test

    Battery Tests Tests available with Battery in-Vehicle The SP61009 battery tester 1. Battery Condition Test activates once the clamps have 2. Cranking (starter motor) Test been correctly connected, it will 3. Charging (Alternator / Regulator) Test automatically display the battery voltage.

  • Page 9: Cranking Voltage Test

    Cranking Voltage Test This test identifies excessive starter current draw, which makes starting difficult and shortens battery life. Perform battery load test and proceed if battery is good. ENGINE MUST BE AT NORMAL OPERATING TEMPERATURE. Connect tester clamps to battery as described in Steps 1-2 under Battery Load Test. Disable the ignition so the car will not start.

  • Page 10: Warranty Details

    To the extent permitted by law and subject to this Limited Warranty, and as part of the terms of the sale of the equipment or part thereof: SP Tools shall not be liable for any form of loss, damage, cost, injury or harm of any kind (whether direct, indirect, special or consequential) howsoever arising from the use or supply of the equipment to the purchaser.
