hygn.me Station 3 Assembly Instruction

hy there! let's
assemble
assembly instruction
1
Unpack the station and place it on it's
back on a table.
4
Use the provided screws and TORX-Key to
attach the base to the column.
7
Fill the canister with disinfectant and
insert the batteries. Close the lid and turn
the dispenser on, using the switch on the
right side.
WSP Wagner-Service-Partner GmbH & Co. KG . Niederlassung Berlin . Waisenstraße 30 . 10179 Berlin
Station 3 desk
2
Let the buttom hang over the edge. Insert
the wooden dowels into the middle holes.
5
Fasten the screws by turning clockwise.
Beware not to overtighten.
8
Attach the metal hood to the column and
place the melamine tray in the slot.
Fon +49 30 255 58 11 66 . beratung@hygn.me . hygn.me
3
Unpack the base and attach by aligning
the holes with the dowels.
6
Place the assembled column on the table
and attach the dispenser.
9
www.hygn.me/service
