Summary of Contents for AODELAN P12
- Page 1 闪光灯高性能电池盒 High-Performance Battery Pack for Flash User Manual/使用说明书...
- Page 3 With P12, you can shoot faster, miss fewer shots and catch every wonderful moment. Please read this user manual as well as the user manual provided with your flash which works with P12 before use.
-
Page 4: For Your Safety
For your safety Before using your product, please read the following safety precaution carefully to ensure correct and safe use. The battery pack contains high voltage electronic parts. Do not disassemble or attempt to repair it. Keep the product out of the reach of children. Do not use the product in the presence of flammable or explosive gas. - Page 5 FCC Interference Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 6 10. Soft Case *Different version comes with different output plug; the plug shown in the above figure may be inconsistent with the actual plug of P12 you bought. For details, please refer to the description of Output Plug. • 4 •...
-
Page 7: Installing The Batteries
Installing the batteries 1. Install batteries in accordance with the illustrated direction inside the battery slot. 2. Install 12 batteries. 3. Push the battery holder into the unit until it stops with a click. • 5 •... - Page 8 When working with an on-camera flash, please use AA-type Ni-MH rechargeable batteries or AA- type alkaline batteries. (Operating with other types of battery may cause a slow recycling and the P12 to be overheated easily.) • 6 •...
- Page 9 When working with a high-powered flash, please use AA-type Ni-MH rechargeable batteries. (Operating with other types of battery may cause a slow recycling and the P12 to be overheated easily.) Remove the batteries when transporting the P12 or not using it for long periods.
- Page 10 2. Plug the output plug of P12 into the corresponding flash’s external power port. (Canon version shown) * When P12 is working with a Canon® / Nikon® or Sony® flash, it only provides high voltage output when the flash is firing and doesn’t power the flash’s operation and display.
- Page 11 3. Press and hold the power button for 2 seconds, the power level indicators will light red, the P12 is turned 4. Turn on the power of the flash. 5. Set the flash custom function to choose external power as the power source.
- Page 12 Using with the Soft Case 1. Insert the P12 with batteries installed into the soft case. 2. Close the cover. 3. Tie up the soft case to the belt or light stand for convenient use. • 10 •...
- Page 13 Output Plug and Compatibility There are 4 versions for P12 according to its different output plug, please refer to following table for the corresponding plug of each version and the flash models it is compatible with. Verison & Compatiblility Output Plug P12 for Canon®...
- Page 14 High Voltage Output Indicator Light up: The high voltage output is normal; the P12 is powering the connected flash. Off: There is no high voltage output; the P12 will turn off automatically after approx. 30 minutes. Blinks continuously: The protection is activated in the P12, please stop using.
- Page 15 Power Button and Battery Level Indicators Power Button: Press and hold it for 2 seconds to turn on the P12; press and hold it for 2 seconds to turn off the P12. Battery Level Indicators：There are 4 LEDs to indicate P12’s current battery level as shown in following table.
-
Page 16: Specifications
Notes Set the flash to full output. The interval between two flashes is 15 seconds. Use the same type of batteries with both the P12 and the flash. With fresh batteries at normal temperature (25 ℃ ). The performance may vary depending on the battery’s freshness or change of battery... - Page 17 Dimensions (L x W x H): Approx. 86 x 195 x 33 mm (3.4 x 7.7 x 1.3 in.) (Body Only) Weight: Approx. 400g (14.1 oz) (without batteries) Specifications and design are subject to change without notice. Canon®, Nikon®, Sony®, Panasonic® and Maxell® mentioned in the manual are protected trademarks w h i c h d o n o t b e l o n g t o S h e n z h e n A o d e l a n Technology Co., Ltd.
-
Page 18: Troubleshooting
(if this the connected flash option is available). Check whether the protection is activated in the P12 (the High Voltage Output Indicator blinks continuously) or any protection is activated in the flash itself. • 16 •...
