- Page 1 Version 1.19.0 Advanced People Sensor APS-90, APS-180 and APS-90-Outdoor-PoE Installation and configuration manual Installation and configuration manual (original) HAGL-120-00077 HELLA Aglaia People Sensing Technologies people-sensing.com...
- Page 2 +49 30 2000429-109 email: support@people-sensing.com www.people-sensing.com © 2020 HELLA Aglaia Mobile Vision GmbH, Berlin Version 1.19.0 The reproduction, distribution and utilization of this document as well as the communication of its contents to others without 2 / 32 express authorization is prohibited. Offenders will be held liable for the payment of damages.
- Page 3 HELLA Aglaia Mobile Vision GmbH reserves the right to revise or replace this manual at any time and without prior notice. Make sure that you have the appropriate version of this manual for the installed firmware version of the device. If you have any questions, please contact HELLA Aglaia Mobile Vision GmbH.
-
Page 4: Table Of Contents
APS-90E-IO and APS-90-IO ........ - Page 5 APS-90, APS-180 and APS-90-Outdoor-PoE Table of contents Cleaning, maintenance and troubleshooting ..22 Cleaning ............22 Maintenance .
-
Page 6: Overview
APS-90, APS-180 and APS-90-Outdoor-PoE Overview Overview The Advanced People Sensor (APS) counts persons within the configured area/monitored area based on stereoscopic imaging and image processing. The counting data is stored internally and can be transferred via different interfaces for external processing. -
Page 7: General Information
APS-90, APS-180 and APS-90-Outdoor-PoE General information General information About this document This manual provides information for optimal configuration and efficient operation of the device. Personnel must carefully read and fully understand this manual before performing any installation or configuration tasks. -
Page 8: About The Manufacturer
The obligations agreed upon in the delivery contract, General terms and conditions and delivery conditions of HELLA Aglaia as well as any legal regulations applicable at the time of the contract conclusion apply. -
Page 9: Use Of The Advanced People Sensor
APS-90, APS-180 and APS-90-Outdoor-PoE General information Use of the Advanced People Sensor Intended use The Advanced People Sensor is a sensor assembly, which must be integrated into other systems. The Advanced People Sensor is intended for automatically counting persons in the config- ured monitored area. - Page 10 APS-90, APS-180 and APS-90-Outdoor-PoE General information Changing linux passwords APS9029B6 login: root Password: counter ~ # passwd customer Changing password for customer New password: new123password Retype password: new123password passwd: password for customer changed by root ~ # passwd hagl Changing password for hagl...
-
Page 11: Technical Data
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Technical data Mechanical data 3.1.1 APS-90 Category Description Dimensions 159.5 mm x 159.5 mm x 41.4 mm (6.3 in x 6.3 in x 1.7 in) Weight 430 g (14 oz) Material Plastic & Aluminum (ADC12) Fig. -
Page 12: Aps-180
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data 3.1.2 APS-180 Category Description Dimensions 237.5 mm x 99.2 mm x 36.7 mm (9.3 in x 3.9 in x 1.5 in) Weight 600 g (21 oz) Material Aluminum (ADC12) Fig. 3: APS-180 dimensions Version 1.19.0... -
Page 13: Aps-90-Outdoor-Poe
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data 3.1.3 APS-90-Outdoor-PoE Category Description Dimensions 140.8 mm x 98.2 mm x 35.0 mm (5.54 in x 3.87 in x 1.38 in) Weight 440 g (15.17 oz) Material Aluminum (ADC12) Fig. 4: APS-90-Outdoor-PoE dimensions Hardware interface specifications 3.2.1... -
Page 14: Aps-90-Outdoor-Poe
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Pin allocation on device Pin no. Name Ethernet mode A mode B TxRx A + Transmit/Receive A (positive DC + polarity) TxRx A − Transmit/Receive A (negative DC + Fig. 5: RJ-45 Ethernet polarity) interface (arrow "A": optics orientation) -
Page 15: I/O Port
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Pin allocation on device Pin no. Name Description Transmit data + Receive data + Transmit data - Receive data - Shield Fig. 6: M12 Ethernet interface ("A": optics orientation) Compatibility of APS-90-Out- APS-90-Outdoor-PoE door-PoE and PoE switches... -
Page 16: Aps-180E-Io And Aps-180-Io
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Pin no. Name Description PWRIN- DC voltage supply - (alternative to PoE, 18 ... 29 V) IN1- Programmable input - IN2- Programmable input - IN3- Programmable input - OUT1- Programmable output - OUT2- Programmable output -... -
Page 17: Aps-90-Outdoor-Poe
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Pin no. Name Description IN2+ Programmable input + IN1- Programmable input - IN1+ Programmable input + PWRIN- DC voltage supply - (alternative to PoE, 18 ... 29 V) PWRIN+ DC voltage supply + (alternative to PoE, 18 ... 29 V) -
Page 18: Usb
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Pin no. Name Description IN2 - Programmable input -, potential-free DID4 B Code jumper 4 DID3 B Code jumper 3 DID2 B Code jumper 2 DID1 B Code jumper 1 3.2.3 Characteristics This USB 2.0 interface (Hi-Speed, max. 480 MBit/s) is intended for connecting storage media and other devices. -
Page 19: Optical Data
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data APS-90 APS-90-Outdoor- APS-180 USB type USB 2.0 type host Connector type (APS/PC) Type-A Optical data Category Description Image resolution 640 x 480 px, color Aperture Focal length 2.6 mm (0.10 in) Angle of view 110°... -
Page 20: Product Labels
APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Category APS-180E APS-90 APS-90-Out- door-PoE APS-180 Illuminance, minimum 3 lx Product labels Identification Label Fig. 12: Identification label The identification plate contains the following information: Manufacturer name Production country Production date Serial number / MAC address Certification markings (e.g. - Page 21 APS-90, APS-180 and APS-90-Outdoor-PoE Technical data Do Not Open Label The small label with the warning "DO NOT OPEN DEVICE!" at the side of the device with data matrix code (Fig. 13 /1) provides the serial number/MAC address (Fig. 13 /2) and some production information in encoded form.
-
Page 22: Cleaning, Maintenance And Troubleshooting
APS-90, APS-180 and APS-90-Outdoor-PoE Cleaning, maintenance and troubleshooting Cleaning, maintenance and trouble- shooting Cleaning Material: Lint-free cloth Commonly available neutral cleaners diluted with water Optimal counting accuracy can be achieved only if the view of the cameras is not obstructed. - Page 23 APS-90, APS-180 and APS-90-Outdoor-PoE Cleaning, maintenance and troubleshooting Fault description Cause Remedy Status LED blinks permanently Device is in DHCP mode and receives Check the DHCP server in the network. yellow no IP address. Device has no connection to the Power supply interrupted Check power supply.
- Page 24 APS-90, APS-180 and APS-90-Outdoor-PoE Cleaning, maintenance and troubleshooting Fault description Cause Remedy If checks are negative, reconfigure the device. Modified mounting position Check in the user interface: If the adjusted pitch and yaw angle still ■ correspond to the values measured on the device.
-
Page 25: Disposal
APS-90, APS-180 and APS-90-Outdoor-PoE Disposal Disposal After decommissioning, the product shall be recycled as electronic waste in an environ- mentally safe way. In the European Union, the WEEE Directive 2012/19/EU applies. HELLA Aglaia will recollect its own electronic products free of charge and take care of the further processing. -
Page 26: Appendix
APS-90, APS-180 and APS-90-Outdoor-PoE Appendix Appendix 030001 CE Declaration of Conformity, 2, en_US EU Konformitätserklärung / EU Declaration of Conformity (DoC) Wir/ HeHa Aglaia Mobile Vision GmbH ( Name des Herstellers/ seines Vertreters manufacturer authorised representative) Ullsteinstraße 140, 12109 Berlin, Deutschland... - Page 27 APS-90, APS-180 and APS-90-Outdoor-PoE Appendix Fig. 15: APS-180E CE declaration Version 1.19.0 The reproduction, distribution and utilization of this document as well as the communication of its contents to others without 27 / 32 express authorization is prohibited. Offenders will be held liable for the payment of damages.
-
Page 28: Federal Communications Commission (Fcc) Statement
APS-90, APS-180 and APS-90-Outdoor-PoE Appendix Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. -
Page 29: Glossary And Abbreviations
APS-90, APS-180 and APS-90-Outdoor-PoE Glossary and abbreviations Glossary and abbreviations Advanced People Sensor Second generation people sensor, successor of the APC. DHCP Dynamic Host Configuration Protocol Protocol and service dynamically distributing network configuration parameters, such as IP address and servers. -
Page 30: Index
APS-90 ........ - Page 31 APS-90, APS-180 and APS-90-Outdoor-PoE Index Warranty information ....... . 8 Waste .
- Page 32 CONTAC T US HELLA Aglaia Mobile Vision GmbH A member of the HELLA group Ullsteinstraße 140 12109 Berlin Germany phone +49 (0) 30 2000 429-625 +49 (0) 30 2000 429-149 mail info@people-sensing.com www.people-sensing.com...
