- Page 1 TF - P2 Carport Assembly Please Read Before Installation www.tfsem.com...
- Page 2 IMPORTANT Please read these instructions carefully before you start to assemble this carport. PREPARATION OF GROUND Please carry out the steps in the order set out in these instructions. Keep these instructions in a safe place for future reference. Before Starting Assembly Care and Safety advice This carport must be assembled on a solid base, * Please follow the instructions as listed in this manual.
- Page 3 1 Preparation of the assembly ground area 2 4 0 0 Prepare the fixing hole to the ground 50x50x50 cm Once you have gauged fill with concrete the holes...
- Page 4 2 - Installation of bearing arms Fix the bearing arm to the reinforcement angle part. Screw the reinforcement angle part with V13.
- Page 5 Screwing the carrier arms 4 Carriers cover installation Screw the reinforcement angle part with V13. Screw the reinforcement angle part with V5.
- Page 6 Installation of the roof support profiles 6 Installation of the roof carrier profiles...
- Page 7 Place and slide the roof sheets , Compress the rubber seal and stabilize the roof sheets from under side . Drive the rain gutter profile to the gutter support After the installations of rain gutter, silicone the end cap of gutter (GC)
- Page 8 Connect the water chute bracket 10 - Installations of end cup covers Connect the water pipe to the post profile...
- Page 9 CONNECTION OF M JOİNT CONNECTION OF M JOİNT upper stabilization plate After the correct installation of carports, place the upper stabilization plate and drill with a drill bit of 9 mm from both side M Joint is formed by two single combinations Place the rain cover profile holder between Place the rain cover profile between the carports...
- Page 10 CONNECTION OF Y JOİNT stabilization plate After the correct installation of carports, place the side stabilization plate and drill with a drill bit of 9 mm from both side Place the screws to the holes and tighten the nut form both side Place the T profile between the rain gutter...
