Kaos Kit Build Instructions
Thank-you for your purchase of the new Kaos kit, the following instructions are meant to
Advanced builders may find they need to make slight deviations in order to better suite
As always due to the type of wood used slight bends or warping to the wood may occur
Parts
1 – Fuselage Bottom
2 – Fuselage Sides
1 – Motor Mount
1 – Center Fuse Former
1 – Rear Servo Mount
10 – Main Ribs
2 – Wing Tip Ribs (3 slots within the rib)
2 – Fuselage Doubler Ribs (notch at top)
2 – Elevons
2 – ¼ x ¼ Hardwood Leading Edge
2 – Main Spars
1/16
4 –
trailing edge pieces
©Direct Connection RC
guide you in assembling your plane.
their abilities and desired plane outcome.
but should not affect the overall stru cture.
Each Kit Contains:
1 – Fuselage Motor Mount Top piece
1 – Battery hatch cover (3 pieces to assemble)
2 – Pieces of Top fuselage sheeting
2 – Half Ribs
4 – Wing Tip Supports
1 – sheet of Trailing edge Spacers
2 – Trailing Edge Tips
2 – Fins (4 pieces to assemble)
2 – Sets of Decal
